Swisher LS10534D Manual de usuario

LOG

SPLITTER

OWNER’S

MANUAL

1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093 PHONE 660-747-8183

FAX 660-747-8650

MODEL NO.

LS622

LS826

LS934

LS10534D

Manufacturing quality lawn care equipment since 1945

Safety

Assembly

Operation

Service and Adjustment

Repair Parts

Made In The

USA

Rev.07.04.2001

Read and follow all Safety

Precautions and Instructions

before operating this

equipment.

IMPORTANT

swisherinc.com

OD12 – HYDRAULIC FILL PLUG

DECAL

OD09 – DANGER/POSITION LOCK

DECAL

OD08 – OPERATOR INSTRUCTION

DECAL

OD16 – FUEL SHUT OFF DECAL OD07 – COLD WEATHER DECAL

SAFETY DECALS

Replace decals immediately if damaged.

OD22 – POSITION LOCK DECAL

OD23 – TOW POSITION DECAL

ASSEMBLY DETAIL

LS622, LS826, LS934 MODELS

SEE DETAIL

21 23

2627

33 3432

35 36

51 55

SEE DETAIL

NOT ALL PARTS ARE ON ALL MODELS

FENDERS ONLY ON

LS934 MODEL

SERVICE PARTS

Please have Model and Serial Numbers ready when ordering parts.

Color cannot be guaranteed upon service parts.

ITEM NUMBER DESCRIPTION PART NUMBER

1RETURN HOSE 54" 7290

2PRESSURE HOSE 48" 7289

3#12 HOSE CLAMP LS5001

4HYDRAULIC RESERVOIR 7319

51/2-13 X 3 1/2 GR5 BOLT NB577

61/2-13 NYLOCK NUT NB281

7RESERVOIR VENT PLUG 7379

83/8-16 X 1 GR5 BOLT NB604

91/2 X 3 1/2 HITCH PIN W/ HAIR PIN NB648

10 SUCTION HOSE 18" 7346

11 #16 HOSE CLAMP LS4999

12 RETURN LINE FITTING 7329

13 FILTER HEAD LS1112

14 FILTER ELEMENT LS1113

15 1/2-13 X 1 1/4 GR5 BOLT NB647

16 3/8-16 2-WAY LOCK NUT NB280

17 TANK BRACE 7352

18 3/8-16 NYLOCK NUT NB182

19 TRAILER JACK/ SNAP RING 7367/7367SR

20 HYDRAULIC PUMP - LS622 MODEL LS2001H

HYDRAULIC PUMP - LS826 & LS934 MODELS LS2002B

21 1/8 X 1/2 #3 WOODRUFF KEY 7440

22 5/16-18 2-WAY LOCK NUT NB558

23 PUMP PULLEY 7306

24 SET SCREW W/ NYLOCK NB312

25 5/16-18 X 3/4 GR2 BOLT NB143

26 FENDER BRACKET - RIGHT SIDE - LS934 ONLY 7417

FENDER BRACKET - LEFT SIDE - LS934 ONLY 7418

27 FENDER - LS934 ONLY 7401

28 KICKSTAND 7398

SERVICE PARTS

Pleas have Model and Serial Numbers ready when ordering parts.

ITEM NUMBER DESCRIPTION PART NUMBER

29 MOTOR BASE / AXLE 7297

30 TIRE / WHEEL 7296

31 COTTER PIN NB633

32 WHEEL DUST COVER 2203DC

33 CASTLE NUT 2203CN

34 WASHER 2203W

35 TAPERED BEARING 2203B

36 BEARING SEAL 2203S

37 BELT 644

38 IDLER ARM 6681TK

39 CLUTCH LEVER 7358

40 SPRING 682S

41 3/8-16 JAM NUT NB174

42 HARDENED WASHER NB196

43 3/8-16 X 2 1/2 GR5 BOLT NB221

44 5/16-18 FLANGE NUT NB170

45 IDLER SPRING MOUNT 2046

46 WIRE LINK FOR IDLER SPRING BRS6H

47 SHOULDER BOLT NB220

48 IDLER PULLEY B527

49 WASHER NB272

50 BELT COVER 7321

51 #14 x 3/4 SELF-TAPPING SCREW NB161

52 SAFETY CLIP PIN H11

53 TOWING TONUGE 7343

TOWING TONGUE - LS934 & LS10534D 7405

54 TRAVEL LOCK 7441

55 SAFETY CHAIN W/ HOOK 7366

56 2" BALL COUPLER 7365

57 3/8-16 X 3 GR5 BOLT NB164

58 3/8-16 X 3 1/2 GR5 BOLT NB649

Color cannot be guaranteed upon service parts.

127

113

126

112

111

129

107

124

108

127

111

114

110

107

126

124

109

122

124

128 110

134

130

146

128 128

131

112

117

125

131

128

145

131

149

116

128

147

124

148

115

129

118

129

123

119 133 132

129

121

120 123

135

136

137

138

140 139

142

151

150

144

143

141

See Detail

152 153

154

155

156

157 156 158

159

160

161

166

164

162

165

163

167

168

169

170

169

See Detail

ASSEMBLY DETAIL

MODEL LS10534D

171

NOT ALL PARTS ARE ON ALL MODELS

173

172

ITEM NUMBER DESCRIPTION PART NUMBER

107 3/8-16 X 3 1/2 GR5 BOLT NB649

108 3/8-16 X 3 GR5 BOLT NB164

109 1/2-13 X 3 1/2 GR5 BOLT NB577

110 1/2-13 X 1 1/4 GR5 BOLT NB647

111 1/2-13 X 1 1/4 GR5 BOLT NB646

112 3/8-16 X 1 GR5 BOLT NB604

113 5/16-18 X 1 GR5 BOLT NB501

114 5/16-18 X 3/4 FLANGE BOLT NB596

115 #14X 3/4 SELF TAPPING SCREW NB161

116 SHOULDER BOLT NB220

117 3/8-16 X 2 1/2 GR5 BOLT NB221

118 5/16-18 X 3/4 GR2 BOLT NB143

119 3/4-10 X 7 1/2 GR5 BOLT NB655

120 1/4-20 X 1 GR5 BOLT NB102

121 5/16-18 X 4 GR5 BOLT NB513

122 SAFETY CLIP PIN H11

123 1/2 X 2 1/2 BALL LOCK PIN NB651

124 WASHER NB272

125 HARDENED WASHER NB196

126 3/8-16 NYLOC NUT NB182

127 1/2-13 NYLOC NUT NB281

128 3/8-16 2 WAY LOCK NUT NB280

129 5/16-18 2 WAY LOCK NUT NB558

130 5/16-18 NYLOC NUT NB181

131 3/8-16 JAM NUT NB174

132 1/4-20 NYLOC NUT NB180

133 3/4-10 NYLOC NUT NB609

134 SET SCREW W/ NYLOC NB312

135 SAFETY CHAIN W/ HOOK 7366

136 2" BALL COUPLER 7365

137 TONGUE 7405

138 TUBE RECIEVER 7362

139 KICKSTAND 7386

140 KICKSTAND BRACKET 7385

141 HYDRAULIC PUMP LS2001H

SERVICE PARTS

Please have Model and Serial Numbers ready when ordering parts.

Color cannot be guaranteed upon service parts.

ITEM NUMBER DESCRIPTION PART NUMBER

142 HYDRAULIC ELBOW 7291

143 PUMP PULLEY 7306

144 MOTOR BASE 7399

145 BELT 32.5 7345

146 IDLER ARM 6681

147 IDLER PULLEY B527

148 CLUTCH LEVER 7358

149 SPRING 682S

150 BOTTOM COVER 7336

151 MOTOR BASE SUPPORT ARM 7375

152 DUST COVER 2203DC

153 COTTER PIN 2203CP

154 CASTLE NUT 2203CN

155 WASHER 2203W

156 TAPERED BEARING 2203B

157 TIRE & WHEEL 7296

158 BEARING SEAL 2203S

159 FENDER 7428

160 DELUXE TANK WELDMENT 7400

161 RESERVOIR VENT PLUG 7379

162 14" SUCTION HOSE 7419

163 #16 HOSE CLAMP LS4999

164 FILTER ELEMENT LS1113

165 FILTER HEAD LS1112

166 FITTING RETURN LINE 7329

167 82" RETURN HOSE 7326

168 90" PRESSURE HOSE 7325

169 #12 HOSE CLAMP LS5001

170 PIVOT 7402

171 TRAILER JACK/ SNAP RING 7367/7367SR

172 ROPE GUIDE 2046

173 5/16-18 FLANGE NUT NB170

NOT SHOWN BEAM LOCK 7439

NOT SHOWN COMPRESSION SPRING 7429

NOT SHOWN 1/8X 3/4 COTTER PIN NB125

SERVICE PARTS

Please have Model and Serial Numbers ready when ordering parts.

Color cannot be guaranteed upon service parts.

ITEM NUMBER DESCRIPTION PART NUMBER

59 CLIP PIN NB642

60 STEEL PIN 7293

61 HYDRAULIC FITTING 7291

62 STATIONARY LINE ASSEMBLY 7288

63 RAM CYLINDER - LS622 MODEL 7284

RAM CYLINDER - LS826 MODEL 7354

RAM CYLINDER - LS934 & LS10534 MODELS 7355

64 1/2-13 X 3 GR5 BOLT NB131

65 SPLITTING WEDGE 7233

66 1/2-13 X 2 1/2 GR5 CARRIAGE BOLT NB643

67 RETURN LINE FITTING 7329

68 1/2-13 JAM 2-WAY LOCK NUT NB121

69 2-WAY PIPE NIPPLE 7292

70 MASTER CHAIN LINK 7424

71 COTTER PIN NB597

72 VALVE INLET FITTING 7387

73 VALVE CONTROL W/ LEVER 7287

74 BEAM WELDMENT 7282

BEAM WELDMENT - DELUXE MODELS 7384

75 1/4 X 1 CLEVIS PIN NB522

76 1/2-13 NUT NB213Z

77 VALVE LEVER & GRIP 7423/7425

78 THIN GIB PLATE 7388

79 THICK GIB PLATE 7237

80 BOTTOM GIB PLATE 7333

81 LOCK WASHER NB508

81A FLAT WASHER NB555

BEAM DETAIL

ALL MODELS

NOT ALL PARTS ARE ON ALL MODELS

81A

ENGINE DETAIL

LS826, LS934, LS10534D MODELS

ENGINE DETAIL

LS622 MODEL

ITEM # DESCRIPTION PART #

82 BLACK PLASTIC KNOB 686K

83 THROTTLE & CABLE(NOT SHOWN) 686N

84 ON - OFF KEY SWITCH KSM

85 GOLDEN LOCK WASHER 9088

86 GOLDEN KEY SWITCH NUT 9087

87 EXISTING ENGINE HARDWARE N/A

88 KEY SWITCH PLATE 7415

89 ENGINE N/A

90 5/16-18 X 1 1/4 GR5 BOLT NB504

91 5/16-18 2-WAY LOCK NUT NB558

92 UPPER SPACER BB105SL

93 ENGINE PULLEY BB105

94 LOWER SPACER BB105S

95 BELLEVILLE WASHER 699

96 7/16-20 X 1 GR5 BOLT W/ NYLOCK NB452N

106 KEYSTOCK 9031

NOTSHOWN WIRING HARNESS 9416

NOTSHOWN THROTTLE PLATE/ SCREWS 686P/NB137

ITEM # DESCRIPTION PART #

97 ENGINE N/A

98 5/16-18 X 2 1/2 GR5 BOLT NB138

99 5/16-18 2-WAY LOCK NUT NB558

100 5/16-18 X 1 1/4 GR5 BOLT NB504

101 KEYSTOCK 9030

102 SET SCREW W/ NYLOCK NB312

103 ENGINE PULLEY - LS622 7323

104 BELLEVILLE WASHER 699

105 3/8-24 X 1 BOLT W/ NYLOCK NB238N

100

98 97

101

105

102

104 103

106
