Swann Advanced Quad Processor Manual de usuario
Advanced Color Quad Processor
4 Channel Quad with Remote Control
Swann Technical Support
All Countries E-mail: [email protected]
Telephone Helpdesk
UNITED STATES toll free
877-274-3695
(Sun-Thurs, 2pm-10.30pm PST)
800-627-2799
(Mon-Fri, 9am-1pm PST)
USA Exchange & Repairs
562-777-2551
(Mon-Fri, 9am-5pm PST)
AUSTRALIA toll free
1300 13 8324
(Mon-Fri, 9am-5.30pm Aus EST)
International
+61 3 8412 4610
(Mon-Fri, 9am-5.30pm Aus EST)
See http://www.worldtimeserver.com for information on different time zones
and the time in Melbourne Australia compare to your local time.
Swann Communications warrants this product against defects in workmanship and material for
a period of one (1) year from it’s original purchase date. You must present your receipt as
proof of date of purchase for warranty validation. Any unit which proves defective during the
stated period will be repaired without charge for parts or labour or replaced at the sole
discretion of Swann. The repair or replacement will be warranted for either ninety days or the
remainder of the original one year warranty period, whichever is longer. The end user is
responsible for all freight charges incurred to send the to Swann’s repair centres.
shipping from and to any country
other than the country of origin. The warranty does not cover any incidental, accidental or
consequential damages arising from the use of or the inability to use this . Any costs
associated with the fitting or removal of this product by a tradesman or other person or any
other costs associated with its use are the responsibility of the end user. This warranty applies
to the original purchaser of the only and is not transferrable to any third party.
Unauthorised end user or third party modifications to any component or evidence of misuse or
abuse of the device will render all warranties void.
product The
end user is responsible for all shipping costs incurred when
product
product
Help Desk / Support Details
Warranty Information
www.swannsecurity.com
8
If this device does not work when you first plug it in,
do not take it back to the store.
Contact the Swann Helpdesk using our fast e-mail service
[email protected] or call us on one of the Toll-Free
numbers shown on the back cover of this booklet.
Most problems can be quickly and easily fixed with a simple
e-mail or a quick chat with one of our friendly technical staff.
(Toll-Free available in the US and Australia only)
Installation Guide
English
27
CONTENTS
Introduction
Your Color Quad package comes with
Simple Connection Instructions
Operation - Front Panel
Operation - Rear Panel
Menu Screens
Technical Specifications
Warranty Information
Help Desk / Support Details
2
2
3
4
5
6
7
Back Cover
Back Cover
2
2
3
4
5
6
7
Back Cover
Back Cover
The Swann Quad Processor is a low cost, convenient security solution for
monitoring up to four areas in your home or business at once. Simply connect
up to four security cameras to the Swann Quad Processor and view them on
any A/V TV, VCR or Swann security monitor and you can keep an eye on all the
important areas from one central location!
Choose between a quad screen (4 cameras at once), split screen, picture in
picture or see each camera view individually in full screen. The Swann Quad
Processor also features an auto-switch function allowing you to scan between all
camera views (including the split screen) with a user definable pause on each
screen.
INTRODUCTION
INSTALLATION
• 1 x Color Quad Processor
• 1 x 12Volt Power Adaptor (design may vary between countries)
• 5 x BNC Male to RCA Female adaptors
• 1 x IR Remote Control
• 1 x Video Cable
• This Instruction Sheet
If any of these items are missing, please contact your retailer.
Refresh Rate NTSC/60frames/sec, PAL/50 frames/sec
Resolution NTSC: 720 x 480, PAL: 720 x 576
Video System PAL or NTSC switchable
Video Input 1.0Vp-p/75 ohms
Video Output 1.0Vp-p/75 ohms
Power Source 12Volt
Operation Temperature 14°F ~ 122°F / -10°C ~ 50°C
Dimensions (H x W x D) 1.29 x 5.7 x 4.72 (inches) / 33 x 145 x 120 (mm)
Weight 0.88 pounds / 400 grams
Ports Camera In x 4 - BNC Female
VCR In x 1 - BNC Female
VCR Out x 1 - BNC Female
Monitor Out x 1 - BNC Female
FCC Notice
We, Swann Communications of 10612 Shoemaker Avenue, Bldg A, Santa Fe Springs, CA
90670 USA, declare under our sole responsibility that the product:
SW247-QP4
This product meets the requirements specified in Part 15 of FCC Regulation. Operation rests
with the following two conditions:
(1) The equipment should not cause any harmful interference;
(2) The equipment must receive and process any interference, including any possible
interference caused by operation mistakes. After testing the product, we confirm that it complies
with the provision for class C digital equipment in the 15th part in FCC regulation; and the
receiver complies with the limitations for class B digital equipment in Part 15 of FCC regulation.
The product generates, applies and emits radio waves. It might cause harmful interferences to
wireless communication if not be installed and used following the description of the manual. The
product may cause interference in residential area, and the customer should take remedies to
eliminate the interference at their own costs. If the product causes any harmful interference to
wireless equipment or disturbs the receiving of TV signals (it can be identified by turning on and
off the product), you can solve the trouble by following methods:
(1) Re-adjust the product or put it in another place;
(2) Extend the distance between the equipment interfered and the product; and
(3) Refer to dealers or experienced radio electrician for help.
CE Notice
This product complies with standards including Low Voltage Device Directive 73/23/EEC; EMC
Directive 89/336/EEC and R&TTE Directive 1999/5/EC. It passed the subject tests by the
authority concerned and is authorized to bear CE mark.
TECHNICAL SPECIFICATIONS
Contents Technical Specifications
Introduction
Your Color Quad package comes with
FCC NOTICE
This device complies with Part 15 of FCC Rules.
Operation is subject to the following conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
Including interference that may cause undesired operation.
3
6
CAM1 CAM2 CAM3
VCR
IN
VCR
OUT
MONITOR
OUT
CAM4 DC 12V
Please refer to the connection and panel diagrams below and over the page
for more information:
Connect the cable from the DC 12Volt power supply(a) to the DC 12Volt
socket(b) on the rear of the unit.
Connect your cameras to the Video In sockets (CAM1 - CAM4) on the rear
panel of the unit. If your camera has RCA male plugs, you will first need to fit the
supplied BNC to RCA adaptors to the Video In sockets and connect your
camera(s) to each of these.
Connect the BNC to RCA Cable (c) (*only one supplied) to the Monitor Out
connector. Connect the other end of the RCA cable to your TV or Security
Monitor’s Video In socket. Turn on the mains power to the 12Volt power
supply(a) and follow the instructions in the operation section below on the
following pages.
If you have an A/V TV with RCA sockets you will need to switch the TV to the
AV channel to view the quad processor.
To view the quad processor connected to your VCR, you will need to select the
AV input you have connect the quad processor to on the VCR, turn your TV
onto the channel you would normally use to view a tape or movie on your
VCR. This channel may be activated by a button on your remote that is marked
with this symbol , or L1 or L2 or possibly AV1 or Av2.
MAINS
WALL SOCKET
U
OT
IN
E
V O
DI
O
VE
ID
D
AIO
U
O
AUDI
MONITOR
OR TV
U
OT
NI
E
VO
ID
O
VEID
ADIO
U
O
AUDI
VCR
BNC to RCA
cable*
CAMERA(S)
(c)
(b) (a)
*Please note: Only one BNC to RCA cable for
connecting the Quad Processor to your TV, VCR or AV
Monitor is supplied.
Please see your local electronics retailer for
information on purchasing additional suitable cables.
System Setup: Use the up down buttons to highlight the setting you wish to
change, then use the left and right buttons to change the setting.
Date: Adjust the date format and set the date.
Time: Adjust the current time in 24hour format (military time).
System Format: Set the TV signal to be PAL or NTSC. Default is set to TV
standard of country of sale.
System ID Number: Feature not used.
Key Lock: Lock all Buttons except Menu Button.
Factory Reset: Reset all settings to Factory Default.
Display Setup:
Display on Screen: Place a tick to display each of these ~
Screen Position: Move the image on your screen left or right.
Border Color: Change the color of the border between the screens.
Auto Sequence:
Page A: Set the length of time (in seconds) the screen pauses.
Page B: Set all cameras to SKIP. *
Camera Setup:
Camera: Select the camera that you are going to modify the settings on
Title: Change the name of the camera on the main screen.
Brightness - Contrast - Saturation - Hue - Sharpness: Change the settings for
the image produced by the selected camera.
Mirroring: Flip the image horizontally (text will appear reversed).
Motion Setup:
Detection Time: Set the operating time for motion detection.
Sensitivity - Velocity: Set the amount and speed of movement to trigger event.
Masking Area: Select the area of the image to be monitored for movement.
Event Setup:
Buzzer/Report Control: Set whether the buzzer activates for these events.
Buzzer Hold Time: Set the duration of the beeper sound for each event.
Report Hold Time: Set the time the camera remains on screen after an alarm.
Alarm Polarity: Set for input polarity of alarm connected to alarm port.
Event Report:
x/6 PAGE: Select page of event report to view.
List Clear: Clear entire list of event reports.
Title - Date - Time.
Not used on this model
Camera: Select the camera that you are going to modify the settings on.
* Not used on this model
Menu Screens Simple Connection Instructions
45
1
239
78
Color Quad Processor
4 5 6 11
10
CAM1 CAM2 CAM3
VCR
IN
VCR
OUT
MONITOR
OUT
CAM4 DC 12V
Please refer to the panel diagram above for additional information.
(1) Power Switch - to turn the unit on.
. Press the button
for less than 1 second twice to turn Auto Mode off, or press the Menu Button to
return to the normal view.
Press
(2) Zoom/Mode Button - Press this button for less than 1 second to switch
through the different screen modes ~ 8 screens - 2 x Picture in Picture - 1 x
Picture in Picture - Split Screen. When in Picture in Picture or Split Screen mode,
press the Enter Button to enable configuration mode. Once in configuration
mode press the Up and Down buttons to select one of the channels you are
viewing, then press the Left or Right button to make changes. You can change
which camera appears in which box, and also where the PiP boxes appear on
the screen. Press the Enter button again to save your settings when you have
finished. To enter & exit the ZOOM mode, press this button for longer than 1
second. Once in configuration, use the UP/DOWN & LEFT/RIGHT buttons to
move the zoom box, then press ENTER button to view zoomed area.
(3) Channel 1, 2, 3 and 4 (Left, Right, Down and up) Buttons - Press the
Channel Buttons to view each camera independently in full screen mode. Use
the UP/Down buttons to navigate the Configuration Menu and the Left/Right
buttons to change the highlighted setting.
(4) Enter/PB Button - Press this button for longer than 1 sec to switch to VCR
Playback mode. To use VCR Playback mode effectively you must have a cable
connected from your VCRs Video Out to the VCR In Socket (8) and the VCRs
Video In to the VCR Out Socket. While in VCR Playback mode, press Play on
your VCR to see the recorded footage play on your TV or Monitor. Press any of
the channel Buttons to show that channel in full screen mode.
(5) Freeze/Auto Button - Press this button for less than 1 second to Freeze the
current image on screen. Press for longer than 1 second to start automatically
switching between Quad Screen and Individual camera views
(6) Menu Button - Press this button for less than 1 second to change back to
quad screen mode from any other display mode. Press for longer than 1 second
to enter and exit the configuration menu.
(7) Channel 1, 2, 3 and 4 Video Input Sockets - Connect the BNC to RCA
adaptor to each socket to which you will connect a camera that uses a Male
RCA plug on the end of it’s cable. If you are using a camera that comes with a
cable that uses BNC connectors then you do not need to use the BNC to RCA
adaptor for that camera socket.
(8) VCR In Socket - Plug the Video Out socket of your VCR into this socket to
allow you to view individual cameras in Full Screen mode when playing
recorded footage back.
(9) VCR Out Socket - Plug the Video In socket of your VCR into this socket to
allow you to record footage to your VCR while you view the Quad Screen on
your monitor.
(10) Monitor Out Socket - Plug the Video In socket of your TV or Security
Monitor into this socket to allow you to view the video signal generated by the
Quad Processor.
(11) 12Volt DC Power Socket - Connect the supplied Power Adaptor to this
socket to power the Quad Processor. Use of Power Sources other than the one
supplied will void your warranty.
Operation - Front Panel Operation - Rear Panel
MENU
AUTO
ZOOM CH4
CH3
CH2
CH1 ENTER FREEZE
MODE ▲►
▼◄PB
POWER
Este manual sirve para los siguientes modelos
1
Otros manuales de Procesador de Swann
