L5 Digital LumaMax™ LED Flashlight
Digitally-Controlled
Five-Watt LED Flashlight
Operator’s Manual
Revision A 7-1-2004
L5 LumaMax LED
Introduction
The L5 LumaMaxTM is fitted with a five-watt,
white LED module. Powered by two 3-volt
lithium batteries, the L5 features digital current
regulation circuitry that matches the LED’s
current requirements to the batteries’ output to
achieve a consistent level of light output for the
useable life of the batteries. The L5 LumaMax
features a click-on/click-off tailcap pushbutton
switch.
Light Activation
Partially depress the tailcap pushbutton switch for
momentary activation. Note: If light fails to
function, the tailcap may be in the lock-out
position; tighten the tailcap by rotating clockwise.
For constant light, fully depress the tailcap
pushbutton switch to the “click-on” position.
CAUTION: The L5 LumaMax is a high-output
lighting device and should not be left on
unattended. External surface temperature will rise
during prolonged operation; this is a normal
operating phenomenon.
Lock-out Tailcap
The lock-out position disables the click switch
and is suggested to avoid accidental light
activation during storage. From the momentary-
on position, rotate the tailcap approximately one
and one half turns counter-clockwise to lock the
light in the off position.
Operation
Battery Replacement
Unscrew the bezel and insert new batteries with
positive ends towards LED assembly. Replace
bezel and hand tighten. Depress tailcap
pushbutton switch to test. Note: If batteries are
inserted with positive ends towards the tailcap,
the unit will not light. Damage will not occur.
Reinsert batteries with positive ends towards the
LED assembly.
WARNING: Lithium batteries can explode or
cause burns if disassembled, shorted, recharged.
exposed to water, fire, or high temperatures. Do
not place loose batteries in a pocket, purse or
other container containing metal objects, mix
with used or other battery types, or store with
hazardous or combustible materials. Store in
cool, dry, ventilated area. Follow applicable laws
and regulations for disposal.
Maintenance
Clean and lubricate threads with a clean cloth and
apply thin coat of silicon-based lubricant to
rubber O-rings. Note: Do not use petroleum-
based lubrication on SureFire O-rings. After
prolonged exposure to moisture, the bezel and
batteries should be removed, inspected, and dried
if necessary.
This unit has approval
SureFire®
LED ASSEMBLY
FLASHLIGHT BODY
SF123A
BATTERY
CLICK ON/OFF TAILCAP
L5 LumaMax LED
Output & Runtime
Accurately specifying light output (lumens) and
runtime is more complicated for LED flashlights
than for tungsten lamp flashlights due to slight
variation in LEDs and LED output characteristics.
The light output of the L5 exceeds that of
comparable SureFire tungsten lamp flashlights
(6P, C2, E2e, etc.), and runtime is longer than the
one hour specified for these tungsten lamp
flashlights.
The curve on the Beam Lumen Output
graph indicates a drop in output after 65
minutes, however usable light is available
for more than 15 hours.
All beam lumen output curves were
measured using an integrating sphere with a
photopic detector.
SureFire KL5
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
L5 LumaMax LED
Warranty Claims
For repair or replacement contact Customer
Service at 800-828-8809 (toll free) or 714-
545-9444 and obtain a Return Merchandise
Authorization number (RMA#). Then
package the unit carefully and return (no
COD’s please) to:
SureFire
Repairs Department, RA#___
17680 Newhope Street, Suite B
Fountain Valley, CA 92708-6122
SureFire will pay any reasonable shipping
costs to return the unit to you.
Warranty
SureFire®warrants its products to be free
from defects in materials and workmanship.
SureFire will repair or replace, at its option
without charge, any product or part which is
found to be defective under normal use and
service. Such repair or replacement shall be
the purchaser’s sole and exclusive remedy
under this warranty. This warranty does not
include normal maintenance and services
and does not apply to any products or parts
that have been subjected to modification,
misuse, negligence, accident, improper
maintenance or repair by anyone other than
SureFire.
Warranty Limitation
There is no other express warranty.
SureFire®hereby disclaims any and all
implied warranties, including but not limited
to fitness for a particular purpose. SureFire
shall not be liable for incidental,
consequential, or special damages arising
out of, or in connection with, product use or
performance.
UM_L5
71-01-625
18300 Mt. Baldy Circle, Fountain Valley, CA 92708-6122
www.surefire.com 800-828-8809
