Supermicro X13SAE Manual de usuario

X13SAE

X13SAE-F

ENGLISH

繁體中文

简体中文

日本語

(

한국어

QUICK REFERENCE GUIDE

Revision 1.0a

Standardized Warning Statements

Motherboards

About Standardized Warning Statements

The following statements are industry standard warnings, provided to warn the user of situations where bodily injury

might occur. Should you have questions or experience di󰀩culty, contact Supermicro's Technical Support Department

for assistance. Only certied technicians should attempt to install or congure components.

Read this section in its entirety before installing or conguring components in the Supermicro chassis.

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

Battery Handling

Warning!

There is a danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or an equiva-

lent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.

警告

電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有電池。請按照製造商的說明指示處理

廢棄舊電池。

警告

电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更换原有电池。请按制造商的说明处理

废旧电池。

電池の取り扱い

電池交換が正しく行われなかった場合、破裂の危険性があります。交換する電池はメーカーが推奨する型、または同等のもの

を使用下さい。使用済電池は製造元の指示に従って処分して下さい。

경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제조사에서 권장하는 동등한

종류의 배터리로만 교체해야 합니다. 제조사의 안내에 따라 사용된 배터리를 처리하여 주십시오.









Note: For complete product safety information, refer to http://www.supermicro.com/about/policies/safety_information.cfm.

X13SAE/X13SAE-F QUICK REFERENCE GUIDE Product Safety Information

X13SAE/X13SAE-F QUICK REFERENCE GUIDE 限用物質含有情況標示聲明書

限

用

物

質

含

有

情

況

標

示

聲

明

書

設備名稱：主機板

Motherboard

型號（型式）：

X13SAE, X13SAE-F

單元Ｕnit

限用物質及其化學符號

鉛Lead

(Pb) 汞Mercury

(Hg) 鎘Cadmium

(Cd)

六價鉻

Hexavalent

chromium

(Cr+6)

多溴聯苯

Polybrominated

biphenyls

(PBB)

多溴二苯醚

Polybrominated

diphenyl ethers

(PBDE)

主機板

(Motherboard)

－○○○○○

備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準

值。

備考2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。

備考3.〝－〞係指該項限用物質為排除項目。

Equipment name

Type designation (Type)

Restricted substances and its chemical symbols

Declaration of the Presence Condition of the Restricted Substances Marking

Note 1：“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the

reference percentage value of presence condition.

Note 2：“○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence.

Note 3：The “−” indicates that the restricted substance corresponds to the exemption.

AMI BIOS POST Codes

About AMI BIOS POST Codes

The table below lists some of AMI BIOS POST codes for this motherboard. For more information, refer to https://www.

supermicro.com/manuals/other/AMI_AptioV_BIOS_POST_Codes_for_SM_Motherboards.pdf.

Code Description

0x32 CPU post-memory initialization is started

0x55 No Memory detected or memory failed

0x63 CPU DXE initialization is started

0x69 North Bridge DXE initialization is started

0x70 South Bridge DXE initialization is started

0x92 PCI Bus initialization is started

0x99 Super IO Initialization

0x9A USB initialization is started

0xA0 IDE initialization is started

0xA9 Boot into BIOS setup menu

0xAE Legacy Boot event

0xB2 Legacy Option ROM Initialization

0xB4 USB hot plug

0xD6 No console output devices are found

0xD7 No console input devices are found

0xF2 Recovery process started

0xF9 Recovery capsule is not found

X13SAE/X13SAE-F QUICK REFERENCE GUIDE BIOS POST Codes

M.2 Device Installation Instructions

M.2 Device Installation

DIMMA1

DIMMA2

DIMMB1

DIMMB2

BMC

BIOS LICENSE

X13SAE-F

DESIGNED IN USA

REV:1.00

PCH

2280

This motherboard has three PCIe 4.0 M.2

M-key sockets that support the M.2 2280

module. One stando󰀨 is pre-installed into

the position of 2280 mounting hole. Refer

to the illustration on the right for the loca-

tions of M.2 sockets and mounting holes.

Follow the steps below to install the M.2

device.

1. Locate the pre-installed stando󰀨 and

screw. Remove the screw and set it

aside.

2. Carefully insert the M.2 device into

the M.2 socket and lower the semi-

circle notched end onto the stando󰀨.

3. Tighten the stando󰀨 screw to secure

the M.2 device into place. Do not

overtighten so as to avoid damaging

the M.2 device.

X13SAE/X13SAE-F QUICK REFERENCE GUIDE M.2 Device Installation Instructions

Notes

X13SAE/X13SAE-F QUICK REFERENCE GUIDE Notes

X13SAE / X13SAE-F

Quick RefeRence Guide Rev. 1.0a

SUPERMICR R

Motherboard Layout and Features

=mounting hole

DIMMA1

DIMMA2

DIMMB1

DIMMB2

USB11 (3.2 (20Gb)) USB4/5 (3.2 (5Gb)) USB6 (3.2 (5Gb))

LED4

BMC_HB_LED

UID

HDMI

VGA

DVI

IPMI_LAN

USB0/1

LAN1

USB7 (3.2 (10Gb))

USB10 (3.2 (20Gb))

LAN2

USB8/9 (3.2 (10Gb))

JPL2

JPAC1

PCI-E M.2-M2

PCI-E M.2-M3

PCI-E M.2-M1

JPW1

CPU SLOT7 PCI-E 5.0 X16

CPU SLOT4 PCI-E 5.0 X8 (IN x16)

PCH SLOT5 PCI-E 3.0 X4

PCH SLOT2 PCI-E 3.0 X4

SLOT1 PCI 33MHZ

BMC

BT1

MAC CODE

BMC CODE

BAR CODE

MAC CODE

BIOS LICENSE

X13SAE-F

DESIGNED IN USA

REV:1.00

JPME2

JLED1

JD1

JPG1

I-SATA0

I-SATA1

I-SATA2

I-SATA3

I-SATA4

I-SATA5

I-SATA6

I-SATA7

JWD1

PWR_LED

CATERR_LED

JSTBY1

JL1

JSD1

SYS_FAN3

SYS_FAN2

SYS_FAN1

CPU_FAN2

CPU_FAN1

JPW2

12V_PUMP_PWR1

AUDIO_FP

COM1

USB2/3

JTPM1

SP1

JF1

JBT1

JPI2C1

PCH

AUDIO

JPL1

BACK PANEL I/O

LGA 1700

Package contents

• One Supermicro Motherboard

• Four SATA Cables

• One I/O Shield

• One Quick Reference Guide

Connector Description

12V_PUMP_PWR1 12V 4-pin Power Connector (for CPU liquid cooling pump)

AUDIO Back Panel High Denition Audio Ports

AUDIO_FP Front Panel Audio Header

BT1 Onboard Battery

COM1 COM Header

CPU_FAN1, CPU_FAN2,

SYS_FAN1 - SYS_FAN3

CPU_FAN1, CPU_FAN2: CPU Fan Headers

SYS_FAN1 - SYS_FAN3: System Fan Headers

DP, HDMI Back Panel DisplayPort 1.4a and High Denition Multimedia Interface (HDMI) 2.0b Port

DVI Digital Video Interface (DVI-D)

I-SATA0 - I-SATA7 Intel® Serial ATA (SATA 3.0) Ports (6 Gb/second)

IPMI_LAN Dedicated IPMI LAN Port (X13SAE-F only)

JF1 Front Control Panel Header

JL1 Chassis Intrusion Header

JLED1 3-pin Power LED Header

JPI2C1 Power Supply SMBus I2C Header (X13SAE-F only)

JPW1 24-pin ATX Main Power Connector (Required)

JPW2 +12V 8-pin CPU Power Connector (Required)

JSD1 SATA DOM (Disk-On-Module) Power Connector

JSTBY1 Standby Power Header (5V)

JTPM1 Trusted Platform Module (TPM)/Port 80 Header

LAN1, LAN2 LAN1: RJ45 1 Gb LAN Port. LAN2: RJ45 2.5 Gb LAN Port

MH10, MH14, MH15 M.2 Device Mounting Holes

PCI-E M.2-M1,

PCI-E M.2-M2,

PCI-E M.2-M3

PCIe 4.0 x4 M.2 M-key Sockets (Support 2280 form factor)

* Small form factor devices and other portable devices for high speed NVMe SSDs

SLOT1 PCI 33MHZ PCI Slot (32 Bit/33 MHz with 5V single voltage)

(PCH) SLOT2, (PCH) SLOT5 PCIe 3.0 x4 Slots

(CPU) SLOT4 PCIe 5.0 x8 (IN x16) Slot

(CPU) SLOT7 PCIe 5.0 x16 Slot

SP1 Internal Speaker/Buzzer

UID Unit Identier (UID) Switch (X13SAE-F only)

USB0, USB1 Back Panel USB 2.0 Ports

USB2/3 Front Access USB 2.0 Header

USB4/5 Front Access USB 3.2 Gen. 1 Header (5 Gb)

USB6 Internal USB 3.2 Gen. 1 Connector (5 Gb, vertical Type-A)

USB7, USB8, USB9 Back Panel USB 3.2 Gen. 2x1 Ports (10 Gb, Type-A)

USB10 Back Panel USB 3.2 Gen. 2x2 Port (20 Gb, Type-C)

USB11 Front Access USB 3.2 Gen. 2x2 Header (20 Gb, Type-C)

VGA VGA Port (X13SAE-F only)

Jumpers and Connectors

Jumper Description Default

JBT1 Clear CMOS (Onboard) Short Pads to Clear CMOS

JD1 Speaker/Buzzer Pins 1-4: External Speaker

Pins 3-4: Buzzer (Default)

JPAC1 HD Audio Enable/Disable Pins 1-2 (Enabled)

JPG1 VGA Enable/Disable (X13SAE-F only) Pins 1-2 (Enabled)

JPL1, JPL2 LAN1/LAN2 Enable/Disable Pins 1-2 (Enabled)

JPME2 ME Manufacturing Mode Pins 1-2 (Normal)

JWD1 Watch Dog Function Enable Pins 1-2 (Reset)

Connectors

Jumpers

ContaCt InformatIon

• www.supermicro.com (Email: [email protected])

• Manuals: http://www.supermicro.com/support/manuals

• Drivers & Utilities: https://www.supermicro.com/wdl/driver/

• Safety: http://www.supermicro.com/about/policies/safety_information.cfm

The X13SAE/X13SAE-F motherboard supports a single 12th/13th Generation Intel Core™ i9/i7/i5/i3 series processor, up to 128GB of Unbuffered

(UDIMM) ECC/Non-ECC DDR5 memory with speeds of up to 4400MT/s in four 288-pin memory slots. Populating these DIMM slots with a

pair of memory modules of the same type and size will result in interleaved memory, which will improve memory performance.

Notes:1) For memory optimization, use only DIMM modules that have been validated by Supermicro. For the latest memory updates,

please refer to our website at http://www.supermicro.com/products/motherboard.

2) Always connect the power cord last, and always remove it before adding, removing, or changing any hardware components.

DIMM Memory Installation

Memory Population Guidelines

When installing memory modules, the DIMM slots should be populated in the following order: DIMMA2, DIMMB2, DIMMA1,

DIMMB1.

• To optimize memory performance, please use (DDR5) memory of the same type, size, and speed on the motherboard.

• Mixed DIMM speeds can be installed. However, all DIMMs will run at the speed of the slowest DIMM.

• In a given channel, the black slot can be enabled only when the gray slot is populated rst.

LED Indicators

LED Description Color/State

BMC_HB_LED X13SAE: Standby Power LED

X13SAE-F: BMC Heartbeat LED

X13SAE: Solid Green (Standby Power On)

X13SAE-F: Blinking Green (BMC Normal)

CATERR_LED Catastrophic Error LED Solid Orange: System CATERR

LED4 Unit Identier (UID) LED (X13SAE-F, IPMI only) Solid Blue: Unit Identied

PWR_LED Onboard Power LED Solid Green: Power On

CPU and Memory Support

Recommended Population (Balanced)

DIMMA1 DIMMB1 DIMMA2 DIMMB2 Total System Memory

8GB DIMM 8GB DIMM 16GB

8GB DIMM 8GB DIMM 8GB DIMM 8GB DIMM 32GB

16GB DIMM 16GB DIMM 32GB

16GB DIMM 16GB DIMM 16GB DIMM 16GB DIMM 64GB

32GB DIMM 32GB DIMM 64GB

32GB DIMM 32GB DIMM 32GB DIMM 32GB DIMM 128GB

LED Indicators

Towards the CPU

DIMMA2 (Gray Slot)

DIMMA1 (Black Slot)

DIMMB2 (Gray Slot)

DIMMB1 (Black Slot)

Memory Support

Frequency 3600MT/s 4000MT/s 4400MT/s

DIMM A1 2R DIMM 1R DIMM N/A

DIMM A2 2R DIMM 1R DIMM 1R or 2R DIMM

DIMM B1 2R DIMM 1R DIMM N/A

DIMM B2 2R DIMM 1R DIMM 1R or 2R DIMM

Otros manuales para X13SAE

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Servidor de Supermicro

Supermicro

Supermicro A+ Server AS-1124US-TNRP Manual de usuario

Supermicro

Supermicro SuperServer SYS-510P-M Manual de usuario

Supermicro

Supermicro SuperBlade SBS-820H-420P Manual de usuario

Supermicro

Supermicro SuperServer 6048R-TXR Manual de usuario

Supermicro

Supermicro Superserver MicroCloud 5038MA-H24TRF Manual de usuario

Supermicro

Supermicro SUPERSERVER 6015V-T Manual de usuario

Supermicro

Supermicro SuperServer SYS-621H-TN12R Manual de usuario

Supermicro

Supermicro 34140315 Manual de usuario

Supermicro

Supermicro SuperServer 2029BT-HTR Manual de usuario

Supermicro

Supermicro AS-1020A-T Manual de usuario

Supermicro

Supermicro SuperServer SYS-621BT-DNTR Manual de usuario

Supermicro

Supermicro AS-2021M-32R Manual de usuario

Supermicro

Supermicro SuperServer SYS-620TP-HTTR Manual de usuario

Supermicro

Supermicro SuperServer SYS-E200-12A-4C Manual de usuario

Supermicro

Supermicro SUPERSERVER 6013P-8 Plus Manual de usuario

Supermicro

Supermicro SuperServer E300-9D Manual de usuario

Supermicro

Supermicro SuperServer SYS-2029U-E Series Manual de usuario

Supermicro

Supermicro SuperServer SYS-220TP-HTTR Manual de usuario

Supermicro

Supermicro 5025M-4 Manual de usuario

Supermicro

Supermicro SuperServer 1019D-FRN5TP Manual de usuario

Supermicro

Supermicro SuperServer 2029P-C1RT Manual de usuario

Supermicro

Supermicro SUPER SUPERSERVER 2028U Series Manual de usuario

Supermicro

Supermicro SuperStorageSystem SSG-2028R-DN2R24L Manual de usuario

Supermicro

Supermicro SBI-7126T-SH Manual de usuario

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario
