Super Circuits MDVR14-3 Manual de usuario

1www.supercircuits.com LE_MDVR14-3_Player_Q

• In the InstallShield “Welcome to ..” window, click Next.

• In the License window, read the license agreement carefully. If you accept the

terms of the agreement, click:

“I accept the terms of the license agreement.” then click Next.

• In the Ready to Install the Program window, click Install. A window with a

progress bar will open.

• Allow the installation to complete. When the InstallShield Wizard Complete

window opens, click Finish.

Step 2. Playing video les with the Mini DVR Player

• Remove the SD from the MDVR14-3 and insert it into an adapter connected to

your computer.

• Open the Mini DVR Player by double clicking the AKR Player desktop icon. The

player window will open.

Open

File or

Folder

AVI

Convert

File Player

Statistics

File Player

Motion Controls

Continue on back ➥

MDVR14-3 Mini DVR Player

Quick Setup Guide

The Mini DVR Player plays the .SDR formatted (proprietary) video les created by the

MDVR14-3 DVR. It can also convert the les to .AVI format for viewing with other

computer based video players such as Windows Media® Player or Apple® iTunes®.

The Mini DVR Player installation les are provided on the SuperCircuits.com website.

The examples used in this guide are taken from a Microsoft® Windows® XP system.

Step 1. Install the Mini DVR Player

Installation of the Mini DVR Player requires a PC with a Pentium® III 800 MHz CPU or

faster, at least 256 MB RAM, and Microsoft Windows 2000 or Windows XP.

To acquire the Mini DVR Player installation les from SuperCircuits.com:

• Open a browser window on your computer and to go SuperCircuits.com.

• Click the PRODUCTS button at the top of the screen.

In the CCTV PRODUCTS page navigation menu, click:

DIGITAL VIDEO RECORDERS > MICRO DVRS

Find the Mini Digital Video Recorder (MDVR14-3), and click:

View Product

Click the PRODUCT RESOURCES tab to list the available resources.

• Click the Resource Name MDVR14-3 Software and download the le.

• Open the le with a .zip le extractor. Within the extraction, open the MDVR14-3

Mini DVR Player folder.

• In the le list, nd Setup_<nnnn>.exe and double click it. An InstallShield

Wizard window will open. NOTE: “nnnn” represents the revision level of the le;

it may be different from the one shown above.

• In the InstallShield Wizard window, click on the language you prefer to use, then

click Next.

• In the player window click the Open File or Folder button in the lower left

corner, then select Directory Open in the pop-up window.

• Browse to the drive (SD card) where the video les are saved, open the drive,

then nd and highlight (click) the SDR folder. In the example below, the SD card

from the recorder appears as “Removable Disk (E:)” in the browse window.

• Click the OK button on the browse window. The player will load the .sdr les it

nds in SDR and list them in the left frame of the player window.

• To play a video le, double click the le entry in the left frame.

To expand the video image to ll the display area or screen, right click on the

video image and select the preferred size option.

Step 3. Convert SDR le to AVI

The AKR Player can convert les in SDR (proprietary) format to AVI format for playing

in common Windows- and MAC-based AVI players. To use this converter:

• Click the AVI Convert button in the lower left corner of the AKR window. In the

Open window that appears, browse for and click (highlight) the name of the le

you want to convert, then click the Open button.

• In the Save As window, browse to the folder where you want to save the le,

select AVI in the Save as type: eld, specify a le name, then click Save. An

AVIConverter Tool progress bar will appear, then close when the conversion

completes.

For additional information about the Mini DVR (AKR) Player, refer to the le

MDVR14-3_Software_UserManual provided under the Product Resources tab

on the MDVR14-3 product page at SuperCircuits.com.
