Sunlux XL-9038 Manual de usuario
V8.1
XL-9038
Bluetooth Data Terminal
User’s Manual
CONTENTS
Introduction
Copyright
Responsibility Clause
1. Functions and Buttons
1-1.Functions
1-2.Buttons
2. Power On and Power Off
2-1.Power on
2-2.Power off
3. Windows XP Connection
5. Scan Mode Settings
6. Data Query
7. Data and Time Settings
4. IOS and Android Connection
4-1.I OS connect with XL-9038
4-2.Data transfer display
8. Scanner Function Settings
8-1.Scan settings
8-2.Capital and lowercase settings
.................. 1
1
1
2
2
3
4
4
5
5
9
9
11
13
14
14
16
17
16
..................
........
............................................
........
................
....................................
......................................
.
.
.
.
.
............
....................................
....
....................................
....
.
......
.
........
................
.
......................
....................................
.
................
............................
......
8-3.Beep tones
8-4.Prefix and Suffix
8-7.Information delay
8-5.Setting max & min length
8-6.Barcode space setting
1919
23
25
26
27
................................
............
.....
.......
...........
............
.....
.
.......
.
...........
This user manual is designed for
bluetooth ba rcode scanner. For
detailed user manual information,
please download the complete user
manual from our website or obtain it
from our distributor.
Copyright
All right reserved by our company.
Reprint, copy or sales of this manual
are forbidden without our company
permission.
Responsibility Clause
We are not responsibility for errors,
omissions and variation without notice.
Introduction
1
This product is a bluetooth barcode
scanner, support Windows, Android
and IOS systems. With barcode
scanning, data storage, query,
transmission and display functions.
1. Functions and Buttons
FIG. 1-1 XL-9038 Front View
1-1. Functions
2
FIG. 2-1: Power Button.
FIG. 2-2: Bluetooth Control Button.
FIG. 2-3: Scan/Wake up Button.
FIG. 2-4: Up/Down and Right/Left
Control Buttons.
FIG. 2-5: Select Confirm and Scan
Button.
FIG. 2-6: Cancel Button.
FIG. 2-7: Return Button.
1-2. Buttons
FIG. 2-1 FIG. 2-2 FIG. 2-3 FIG. 2-4
FIG. 2-5 FIG. 2-6 FIG. 2-7
3
2. Power On and Power Off
2-1. Power on
2-2. Power off
Press the Power button to power on the
terminal.
Long press the Power button to power
off the terminal.
4
3. Windows XP Connection
Plug the Bluetooth adapter into the PC
USB interfaces, the Bluetooth icon will
appear in the lower right corner of the
taskbar.
Right - click the Bluetooth icon (as
shown in FIG. 3-1), select “Add the
Bluetooth Device”.
Pop up FIG. 3-2 check “my device is
set up and ready to be found”click
“Next” .
Select the Bluetooth device has been
found as FIG. 3-3 shown click “Next”.
5
Select “Let me choose my own
password”, and enter “0000”, click
“next” as FIG. 3-4 and will pop up the
dialog box as shown FIG. 3-5.
Click on “Finish” and complete settings
FIG. 3-5. After completing setting,will
shown “found new hardware icon” at
lower right corner in the taskbar.
Otherwise it’s not successful, need to
reset again.
FIG. 3-1
6
FIG. 3-2
7
