Suncast Everett BMS6510 Manual de usuario

BMS6510 Blow Molded Shed

Everett™ Storage Shed

ASSEMBLY INSTRUCTIONS

Quality Control Number:

Easy Bolt Easy Driver

INCLUDED IN KIT

010210410

Tools Needed For Installation

Before You Begin...

• Consult your local authorities for any permits required to construct shed.

Prior to the construction of your shed, check with the local building code ofﬁcial to review any required

permits or building limitations.

• A level and sturdy foundation is required before shed construction can begin.

Review the site preparation information within the manual before beginning assembly.

• Read instructions thoroughly prior to assembly.

This kit contains parts that can be damaged if assembled incorrectly or in the wrong sequence.

• Please follow instructions.

Suncast is not responsible for replacing parts lost or damaged due to incorrect assembly.

• Assistance is required during entire assembly.

IMPORTANT

OPEN ALL BOXES FIRST AND NEATLY LAYOUT PARTS. SMALL PARTS MAY BE CONTAINED IN EACH BOX.

PLEASE REFERENCE THE PARTS LIST WITHIN THIS MANUAL TO VERIFY ALL PARTS ARE PRESENT.

COMPLETE SITE PREPARATION AND FOUNDATION CONSTRUCTION BEFORE UNPACKING ALL PARTS.

Caution

• Proper site preparation required.

• Shed not intended for use in extreme weather conditions.

• Shed not intended for storage of ﬂammable or caustic chemicals.

• Store heavy items near the bottom of shed.

• Shed not intended for use by children.

• DO NOT stand, sit, or store items on storage shed roof.

• Treat carefully in extreme temperatures.

• Repair or replace broken parts immediately.

• Suncast is not responsible for damage caused by weather or misuse.

• At regular intervals inspect your shed to make sure that assembly integrity has been

maintained.

• Periodically check that the location you have chosen to set your shed is still level.

• This kit contains parts with metal edges. Please be careful when handling.

Suncast Products and Replacement Parts

www.suncast.com

24 hours a day, 7 days a week, 365 days a year. 1-800-846-2345 or 1-630-879-2050

Shed Safety and Care

• Hot items, such as recently used grills, blowtorches, etc., must not be stored in the shed.

• Heavy articles should not be leaned against the walls, as this may cause panel distortion and

permanent damage.

• Keep roof clean of snow and leaves.

• The shed walls and roof sections have a textured exterior, much like vinyl home siding.

Over time, dust may accumulate in the texture. When combined with moisture, this could

encourage the growth of moss or mold on the shed. To maintain the look of your shed, we

recommend cleaning it each year with mild soap and water.

DO NOT use bleach, ammonia, or other caustic cleaners, and DO NOT use stiff bristle

brushes. Failure to perform annual cleaning could result in permanent staining of the plastic.

This is not a manufacturing defect and is not covered under warranty.

Assembly Day Tips

• Complete site preparation and foundation construction before unpacking parts and beginning

assembly.

• DO NOT attempt to assemble on a day with strong winds.

• DO NOT attempt to assemble on days when temperature is below 32 degrees.

• Set aside appropriate amount of time to completely assemble shed. Assembly time is

approximately 3 hours.

• Make sure you have assistance nearby to lift and secure parts in place.

• Wear light duty work gloves while assembling shed.

• Once roof is assembled, a ﬂashlight may be of use when assembling smaller components

inside shed.

• DO NOT use a torque wrench or hand drill to tighten provided Easy bolts. Use 010210410

Easy Bolt Easy Driver tool (provided) ONLY.

• Suncast provides extra hardware for small fasteners for customer convenience. In some

cases, there will be extra small fasteners once the assembly is complete.

Note: This product contains parts that are used in different orientations to construct the shed. Please take note

of the orientation of the parts shown throughout this instruction manual. Failure to follow instructions could re-

sult in damage to parts. Suncast is not responsible for replacing parts lost or damaged due to incorrect

assembly.

0B00344 –Back

panel

0B00334 – Left

back corner

0B00335 – Right back corner

0B00340 – Rear floor

0B00338 – Front Floor

0B00343 – Right front corner

0B000342 – Left

front corner

0B00341 – Side

panel

Parts - BMS6510 Walls and Floor

IMPORTANT

OPEN ALL BOXES FIRST AND NEATLY LAYOUT PARTS. SMALL PARTS MAY BE

CONTAINED IN EACH BOX. PLEASE REFERENCE THE PARTS LIST WITHIN THIS

MANUAL TO VERIFYALL PARTS ARE PRESENT.

COMPLETE SITE PREPARATION AND FOUNDATION CONSTRUCTION BEFORE

UNPACKING ALL PARTS.

0440546A – Window gasket

x1 set

0B00336 – Left door

0B00337 – Right door

0440544B – Window

x1 set

0463370– Door handle Kit

x1 set

HHH

0440631 – D-ring

slide bolt

x1 set

Parts - BMS6510 Doors

IMPORTANT

OPEN ALL BOXES FIRST AND NEATLY LAYOUT PARTS. SMALL PARTS MAY BE CONTAINED

IN EACH BOX. PLEASE REFERENCE THE PARTS LIST WITHIN THIS MANUAL TO VERIFY

ALL PARTS ARE PRESENT.

COMPLETE SITE PREPARATION AND FOUNDATION CONSTRUCTION BEFORE

UNPACKING ALL PARTS.

OMR001005 – Ridge beam

0B00332 – Front header

0MR002002 – Header beam

0B00333 – Rear header

0440630 – Vent screen

x1 set

OMP000001 – Header Bracket

Parts - BMS6510 Header

IMPORTANT

OPEN ALL BOXES FIRST AND NEATLY LAYOUT PARTS. SMALL PARTS MAY BE CONTAINED

IN EACH BOX. PLEASE REFERENCE THE PARTS LIST WITHIN THIS MANUAL TO VERIFY

ALL PARTS ARE PRESENT.

COMPLETE SITE PREPARATION AND FOUNDATION CONSTRUCTION BEFORE

UNPACKING ALL PARTS.

0MP000003 – Truss bracket

0B00331 – Left roof

0MR004001 –

Side adapter

bracket

x1 set

0MR005002 – Truss leg

0MR006002 –

Truss cross brace

0MP000004 –

Truss strap

0B00330 – Right roof

0MR009004–

Roof Support

0102231 – Skylight

CCC

0510700 – Gasket

DDD

Parts - BMS6510 Roof

IMPORTANT

OPEN ALL BOXES FIRST AND NEATLY LAYOUT PARTS. SMALL PARTS MAY BE CONTAINED

IN EACH BOX. PLEASE REFERENCE THE PARTS LIST WITHIN THIS MANUAL TO VERIFY

ALL PARTS ARE PRESENT.

COMPLETE SITE PREPARATION AND FOUNDATION CONSTRUCTION BEFORE

UNPACKING ALL PARTS.

.25 x 2" Hex bolt

FFF

0480374 – Hardware

bag

.25 Locking nut

EEE

Metal hinge plate

0480337 – Hardware bag

0MP000002 – Hardware bag

Easy bolt 7/8"

x26

*Easy bolt easy driver

.625" Truss head screw

x167

0480217 – Hardware bag

.25" x 2"

Hex bolt

.25" x 1"

Hex bolt

.25" x .75"

Machine screw

.25" Locking nut

.75" Sealing

screw

Rubber

washer

Hardware shown at actual size (*Unless otherwise noted.) Extra hardware provided. Not all are used.

.25" Locking

nut

0480340 – Hardware bag 0480342 – Hardware bag

0480298A and 0480336 –

Hardware bag

Hardware - BMS6510

0480370

Hardware

Hardware shown at actual size (*Unless otherwise noted.) Extra hardware provided. Not all are used.

0463370

HHH

.25" Washer

III

.25" x 1" Pan head screw

Door Handle Kit - BMS6510

72"

65 1/4"

FRONT

Anchoring ﬂoor panel to concrete slab

• Secure shed to concrete slab using masonry

fasteners.

• Dimensions allow for shed to ﬁt within the nearest

1" on each side.

65 1/4 "

72"

FRONT

Anchoring ﬂoor panel to wood platform

• Secure shed to wood platform using 1/4" x 3" lag

screws.

Site Preparation and Platform Construction

Materials NOT supplied with BMS6510 Shed Kit

Note: Site preparation is required for this shed. Placing the shed on a constructed foundation is required. Without

a constructed foundation, settling will probably occur, causing distortion and damage to the shed. Suncast is not

responsible for replacing parts damaged or property lost due to incorrect assembly. Warranty requires foundation.

Note: Complete the site preparation and foundation construction before unpacking parts and beginning assembly. For

tips on site preparation, go to www.suncast.com, consult retailer, or local code.

To prepare your shed site, follow the steps below:

1) Consult your local authorities for building codes and covenants before beginning foundation or erecting shed.

2) Before any digging, check with local utilities to determine location of buried cables, pipes, etc.

3) Decide which type of foundation you want:

- Concrete slab, 4" thick

- Wood platform

Use exterior grade wood. The wood platform should be set on pier blocks or footing. Consult your local retailer for

help to determine the best anchoring method for your particular installation. The provided plans are sized for the

minimum number of cuts to lumber and plywood.

4) Prepare the building site:

- The ground should slope away from the foundation area to provide drainage.

- The foundation surface must be ﬂat and level.

- A vapor barrier should be provided to prevent excessive condensation in the shed.

- Follow local building codes for a proper vapor barrier.

5) Anchoring the shed to the foundation:

- Consult your local retailer for help to determine the best anchoring method for your particular installation.

- To secure the shed to a concrete slab, use masonry fasteners available at your local hardware retailer.

- To secure the shed to a wood platform, use 1/4" x 3" long lag screws with washers.
