MX7700 Issue: B Page 1 of 5

SERVICE MANUAL

MX7700

MX7700MX7700

MX7700

ISSUE: B

DATE: 18 March 2005

MX7700 Issue: B Page 2 of 5

SPARE PARTS LIST

Note: Not all parts are available as spare parts. Please check price list.

Item Description No. of

Parts

Supplier’s

Code

Sunbeam

Part No.

Beater Collar RH

P-CM550-001 N/A

Beater Outer

M-CM550-018 N/A

A Beater Outer Assembly 1

A-SA-CM550-001

MX77101

Beater Collar LH

P-CM550-002 N/A

Beater Inner

M-CM550-021 N/A

Beater Scraper

P-CM550-024 N/A

B Beater Inner Assembly 1

A-SA-CM550-002

MX77101

C 10 Spatula 1

P-CM550-047

MX77104

Beater Collar RH

P-CM550-001 N/A

Dough Hook Outer

M-CM550-018 N/A

D Dough Hook Outer Assembly 1

A-SA-CM550-003

MX77102

Beater Collar LH

P-CM550-002 N/A

Dough Hook Inner

M-CM550-017 N/A

E Dough Hook Inner Assembly 1

A-SA-CM550-004

MX77102

Bowl Cover Ring

P-CM550-005 N/A

Bowl Base

P-CM550-034 N/A

Bowl Bracket

M-CM550-020 N/A

Bowl

M-CM550-019 N/A

F Bowl Assembly 1

A-SA-CM550-005

MX77103

G 14 Stand Vent

P-CM550-013 N/A

18 Mixer Speed Control Knob

P-CM550-017 N/A

41 Speed Control Overmould

P-CM550-040 N/A

H Mixer Speed Control Assembly 1

A-SA-CM550-006

MX77107

19 Bowl Speed Control Knob

P-CM550-018 N/A

42 Bowl Control Overmould

P-CM550-041 N/A

I Bowl Speed Control Assembly 1

A-SA-CM550-007

MX77108

37 Rubber Foot Retainer

P-CM550-036 N/A

39 Rubber Foot

P-CM550-038 N/A

J Rubber Foot Assembly

A-SA-CM550-008 N/A

K Instruction Book

B-CM55-IM N/A

L Gift Box

B-CM550-GB N/A

M Replacement Guarantee Book

B-CM550-GU N/A

Turntable bearing Cage

P-CM550-004 N/A

Motor Gear Bush Retainer

P-CM550-005 N/A

PCB Spacer

P-CM550-006 N/A

Head Tilt Handle

P-CM550-007 N/A

Axle Nut short

P-CM550-008 N/A

Axle Nut Long

P-CM550-009 N/A

Neon Lens

P-CM550-010 N/A

Stand

P-CM550-011 N/A

Turntable Cover

P-CM550-012 N/A

Stand Lock Link

P-CM550-013 N/A

Stand Lock Button

P-CM550-014 N/A

MX7700 Issue: B Page 3 of 5

Item Description No. of

Parts

Supplier’s

Code

Sunbeam

Part No.

Control Cover

P-CM550-016 N/A

Top Housing

P-CM550-019 N/A

Bottom Housing

P-CM550-020 N/A

Beater Eject Button

P-CM550-021 N/A

Axle

P-CM550-022 N/A

Turntable Drive Worm

P-CM550-023 N/A

Stand Motor Drive Gear

P-CM550-025 N/A

Beater Retainer

P-CM550-026 N/A

Beater Tension Spring

P-CM550-027 N/A

Turntable Base

P-CM550-028 N/A

Turntable

P-CM550-029 N/A

Drive Shaft

P-CM550-030 N/A

Stand Motor Mount

P-CM550-031 N/A

Power Cord Clamp Top

P-CM550-032 N/A

Power Cord Clamp Bottom

P-CM550-033 N/A

Fan Shroud

P-CM550-035 N/A

Stand Lock

P-CM550-037 N/A

Head Tilt Handle Overmould

P-CM550-039 N/A

Motor Mount Top

P-CM550-042 N/A

Motor Mount Bottom

P-CM550-043 N/A

Motor Mount Grommet

P-CM550-045 N/A

Motor Mount ‘O’ Ring

P-CM550-046 N/A

Turntable Surround

M-CM550-034 N/A

Turntable Ball Bearing

M-CM550-001 N/A

Drive Worm Bush Retainer

M-CM550-002 N/A

Axle Spring

M-CM550-003 N/A

Axle Lock Bracket

M-CM550-004 N/A

Axle Eject Spring

M-CM550-005 N/A

Beater Retainer Spring

M-CM550-006 N/A

Axle lock Pin Surclip

M-CM550-035 N/A

Stand Lock Surclip

M-CM550-010 N/A

Chassis Lower

M-CM550-011 N/A

Chassis Upper

M-CM550-012 N/A

Stand Lock Rod

M-CM550-013 N/A

Stand Cover Plate

M-CM550-016 N/A

Turntable Bush

M-CM550-023 N/A

Drive Worm Pin

M-CM550-024 N/A

Drive Worm/ Motor Gear Bush

M-CM550-025 N/A

Stand Speed Control Switch

Q-COL-CM550-001 N/A

Main PCB

Q-PCB-CM550-001 N/A

Mixer Speed Control PCB

Q-PCB-CM550-002 N/A

Feedback PCB

Q-PCB-CM550-003 N/A

Felt Seal

P-CM550-044 N/A

74 Stand Motor Assy 1

Q-MOR-CM550-01

MX77105

75 Mixer Motor Assy 1

Q-MOR-CM550-02

MX77106

Power Cordset

Q-PC-CM550 N/A

Screw

M-SCW-3*10PT/W N/A

MX7700 Issue: B Page 4 of 5

Item Description No. of

Parts

Supplier’s

Code

Sunbeam

Part No.

Screw

M-SCW-M3*8 N/A

Screw

M-SCW-M3*12 N/A

Screw

M-SCW-M2*8PT N/A

Screw

M-SCW-3*10PT N/A

Screw

M-SCW-3*12PT N/A

Screw

M-SCW-4*12BM N/A

Screw

M-SCW-4*15PT N/A

Screw

M-SCW-4*18PT N/A

Screw

M-SCW-4*30PT N/A

Screw

M-SCW-M3*10H N/A

Nut

M-NUT-M3 N/A

Washer

M-WA-Ø3.3*Ø6.4*0.4 N/A

Washer

M-WA-Ø4.2*Ø8*0.4 N/A

Cable Tie

P-CT-001 N/A

MX7700 Issue: B Page 5 of 5

EXPLODED VIEW DRAWING

MX7700 Issue: B Page 6 of 5

CIRCUIT DIAGRAM

MX7700 Issue: B Page 7 of 5

Notes:
