MODEL 2576

OWNER’S

MANUAL

CAUTION:

READ AND

SAVE THESE

INSTRUCTIONS.

HEPA 2500

AIR CLEANER

OPERATING INSTRUCTIONS

Any questions or comments?

Call I-800-526-2832

Mon.-Fri. 8 a.m.

p.m. Central Time

Your Sunbeam 2500 Air Cleaner has been designed to

roughly before your air cleaner is operated.

let you enjoy a refreshing experience in clean air living.

Keep your owner’s manual for future refer-

Airborne particles are removed from air passing

ence.

through the unit.

NOTE: This owner’s manual should be read tho-

2. CARTRIDGE AIR FILTER 3. CHARCOAL

1. PRE-FILTER (HEPA FILTER) AFTER-FILTER

HOW THE SUNBEAM HEPA 2500

AIR CLEANER WORKS

The air around you is filled with thousands of particles

of air pollution. Some of the pollutants (dust, smoke

and lint) are visible to the naked eye, but most of the

pollutants (pollen and bacteria, to name a few) are

microscopic in size.

Figure 2

UNIT LOCATION

Your true HEPA Filter is enclosed with a sealing label Select the location for your air cleaner with an electri-

placed over the top of the collector assembly. This cal outlet nearby. An example of locating your air

label provides a complete sealing of the HEPA Filter cleaner is shown in Figure 3.

ensuring a 99.97% efficiency at removing common

indoor air particles. Do not remove this label unless

replacing the HEPA or Charcoal Filter.

NOTE: DO NOT USE AN EXTENSION CORD TO

SUPPLY POWER TO YOUR AIR CLEANER.

As polluted air is drawn into your console air cleaner

(Figure

1),

an Aluminum Pre-Filter strains out the

larger particles of pollution. The air then passes

through the cartridge air filter (HEPA Filter) where

microscopic particles are collected.

Your console air cleaner can be placed almost any-

where as long as the air can freely circulate into the top

front grill and out of the bottom front grill. (Figure 1)

The now cleaned air then passes through a filter of

activated carbon. Activated carbon acts like a sponge

to help remove odors. (Figure 2) Having been cleaned

three ways, the air returns to the room through the

bottom front grill. (Figure 1)

POLLUTED

AIR IN

CLEAN

AIR OUT

Figure 3

Figure

OPERATION

MAINTENANCE

Plug the cord into any standard household electrical

outlet. (See data label for electrical specifications and

power consumption. This data label can be seen when

the cabinet top is removed.)

Turn the unit on by sliding the ON/OFF switch to the

desired speed: “DAILY USE, MEDIUM or HIGH”. (Fig-

ure 4) The air cleaner should be set on HIGH for 1

minute before switching to desired speed to initially

start-up the unit. Your air cleaner is designed for con-

tinuous operation -- peak efficiency is obtained when

the air cleaner remains on constantly. For best results,

select “DAILY USE” setting.

An operating light is located on the top right front grill

and indicates that the unit is operating. (Figure 5)

Figure 4

OPERATING

LIGHT

Figure

CARE OF CABINET

You should treat the cabinet of your air cleaner as you

would any other piece of fine furniture. A soft, damp

cloth will keep it clean and attractive for many years.

The front grill can be cleaned using a vacuum cleaner

with a brush attachment.

REMOVE HEPA FILTER ASSEMBLY

Turn off the air cleaner and unplug it from the electri-

cal power source.

Remove the cabinet top by lifting up and remove the

Sealing Label (enables 99.97% efficiency) from the top

of the HEPA Filter Assembly. Do not discard Sealing

Label. Lift out the collector assembly using the flip-up

handle. (Figure 6)

The HEPA Filter Assembly includes:

Aluminum Pre-Filter, HEPA Filter and Charcoal

After-Filter.

The front filter (Aluminum) is the Pre-Filter. The HEPA

Filter is the middle (large) filter, and the Charcoal After-

Filter is in the back of the HEPA Filter Assembly. (Fig-

ure 7)

Figure 6

CHARCOAL

AFTER-FILTER

HEPA

FILTER

ALUMINUM

PRE-FILTER

HEPA

, FILTER

ASSEMBLY

Figure 7

TO CLEAN PRE-FILTER TO REPLACE HEPA FILTER ASSEMBLY

Slide out Pre-Filter located in front of the Filter Assem-

bly. Rinse thoroughly with clean warm water. Set aside

to dry.

NOTE: Use directions on the top of the

HEPA

Filter

Assembly for proper placement of the filters

into the assembly and for replacing the as-

sembly into the unit.

REPLACEMENT OF HEPA FILTER

After about 12 months of collecting dirt, dust, pollen

and other pollutants, the HEPA Filter of your unit will

need to be replaced. The

HEPA

Filter cannot be

cleaned. Use the enclosed reorder form to order

replacement filters if not available from your retailer.

Remove the Pre-Filter and Charcoal After-Filter from

the HEPA Filter Assembly and place aside. The HEPA

Filter can now be discarded. Using the directions on

top of the new HEPA Filter, replace the aluminum

Pre-Filter in slots provided in front of the HEPA Filter

and replace the Charcoal After-Filter in the slots pro-

vided in the back.

Using the handle, slide the HEPA Filter Assembly back

into the cabinet. Aluminum Pre-Filter will face the front

grill. Replace the Sealing Label provided with the new

HEPA Filter over the opening containing the HEPA

Filter Assembly.

TO REPLACE CABINET TOP

Replace the cabinet top by positioning over the unit

and placing on cabinet. (Figure 8) Be sure that the plas-

tic ball and socket are engaged.

Plug the cord into the electrical power source and

select desired speed.

REPLACEMENT OF CHARCOAL FILTER

ACTIVATED CHARCOAL FILTER HELPS REMOVE

HOUSEHOLD ODORS.

To remove the Charcoal Filter, remove the Sealing

Label from top of Filter Assembly and place aside so it

can be reused. Remove the Charcoal Filter from the

Filter Assembly. Do not wash the Charcoal Filter. It

should be replaced every 3-6 months under average

conditions. These filters are available in your retail

store or use the enclosed order form.

After replacing the Charcoal Filter, return the Filter

Assembly back into the cabinet. Reseal the top of the

Filter Assembly with the Sealing Label removed pre-

viously.

PLASTIC

BALL

SOCKET

Figure 8

TROUBLESHOOTING CHECKLIST

Many times questions that appear to be major can be solved quite easily. The chart below lists potential questions/

problems and how to correct them. Remember, check the simple things first.

CONDITION WHAT TO CHECK

Unit fails to turn on.

Unit does not

remove pollutants/

Reduced air flow

1. Power Cord

2. Electrical Outlet

3. ON/OFF Switch

4. Cabinet Top is properly

intalled

5. Collector assembly is pro-

perly installed.

HEPA

Filter

Unit still does not

operate properly. Re-check the above points.

NOTE:

WHAT TO DO

1. Plug in power cord.

2. Check for power to the electrical outlet.

Plug a table lamp into the electrical outlet

to ensure power availability.

3. Set ON/OFF Switch to desired speed.

4. Refer to section on previous page,

“To Replace Cabinet Top.”

5. Use directions on the top side of the

assembly. Aluminum Pre-Filter will face the front

grill.

1. As the HEPA Filter collects, a higher speed

may be necessary to maintain the original

cleaning level of the air cleaner.

2. The HEPA Filter needs to be replaced. (Will

need to be replaced every 12 months or

sooner depending on the environment the

air cleaner is operated in.)

Return unit to Appliance Service Station,

Hattiesburg, MS, for service. See

Warranty Information on back cover

for address.

Blowing smoke directly into the front grill is not a good test for unit performance.

CABINET TOP

CHARCOAL

REPLACEMENT

FILTER

ALUMINUM

PRE-FILTER

PARTS LIST

Key

Part

Number Number

344953-001

123324-003

6576

6575

Description

Cabinet Top

Aluminum Pre-Filter

HEPA Filter

Charcoal Replacement Filter

To order Replacement Parts, write to Appliance Service Center, 117 Central Industrial Row, Purvis, MS 39475.

Notes/Notas

MODEL 2576

OWNER’S

MANUAL

HEPA

2500

AIR CLEANER

LIMITED ONE YEAR WARRANTY STATEMENT

This product is warranted for one year from the date of purchase

against electrical and mechanical defects in material and workman-

ship. If the unit fails to operate during this period, return it, prepaid, to

Appliance Service Station, 117 Central Industrial Row, Purvis, Mississ-

ippi,39475, for repair or replacement without charge at the manu-

facturer’s option. This warranty gives you specific legal rights, and

you may also have other rights which vary from state to state.

Warrantor: Sunbeam-Oster Household Products

Made in America

@Sunbeam,

@Sunbeam-Oster

Household Products, Distributed by Sunbeam-Oster Household Products, Schaumburg

60173

Part No. 61803 (144965001)

Printed in USA

Committed To Our Environment . . . Printed on Recycled Paper ,‘*,
