Summit CR1115 Manual de usuario

INSTRUCTION MAN

UAL

for Ceramic Glass

Electric Cooktop Models

CR1115

CR2110

CR2220

CR3240

Felix Storch, Inc.

Summit Appliance Division

770 Garrison Avenue

Bronx, NY 10474

www.summitappliance .com

Please read these instructions in their entirety before

installation and use of your cooktop.

SAVE THIS MANUAL FOR FUTURE REFERENCE.

Table of Contents

Product Specifications ......................................................................................2

Installation Instructions for Ceramic Glass Cooktops .............................3 - 10

Step #1: Unpacking the Cooktop ...............................................................3

Step #2: Check the Electrical Supply Requirements ................................. 4

Step #3: Countertop Preparation ..........................................................5 - 7

Summary of Cutout Dimensions .................................................. 7

Step #4: Installing the Cooktop ............................................................8 - 9

Step #5: Electrical Connection ................................................................10

Step #6: Final Preparations Prior to Use .................................................10

Safety Instructions.....................................................................................11 - 12

Operation....................................................................................................13 - 14

Cookware.................................................................................................13

Heating Elements.....................................................................................13

Controls & Indicators................................................................................14

Cleaning.............................................................................................................14

Warranty ............................................................................................................15

Product Specifications

Single Burner

CR1115: 120V AC – one 6” (140 mm) burner @ 1200 watts

Overall dimensions: 11⅞”W x 12⅝”D x 3⅜”H

(302 mm x 321 mm x 85,7 mm)

Cutout dimensions: 11⅛”W x 11⅞”D

(282 mm x 302 mm)

Double Burner

CR2110: 120V AC – two 6” (140 mm) burners @ 1200 watts each

CR2220: 220V AC – two 6” (140 mm) burners @ 1200 watts each

Overall dimensions: 11⅞”W x 19¾”D x 3⅜”H

(302 mm x 502 mm x 85,7 mm)

Cutout dimensions: 11⅛”W x 19⅛”D

(282 mm x 486 mm)

Triple Burner

CR3240: 220V AC - three 6” (140 mm) burners @1200 watts each

Overall dimensions: 20⅝”W x 19⅛"D x 3⅜”H

(524 mm x 486 mm x 85,7 mm)

Cutout dimensions: 19⅞”W x 18⅜”D

(505 mm x 467 mm)

Contour Cooktop

Installation Instructions

for Ceramic Glass Cooktops

Step #1

Unpacking the Cooktop

Carefully unpack the cooktop from its shipping container. If possible, retain

the original shipping carton and protective packaging in the event the unit

ever has to be returned for service.

Verify and identify the package contents. The following items should be

included in the carton. If any components are missing or damaged, call

SUMMIT immediately.

●

Ceramic glass cooktop

●

Mounting brackets (2 pcs. for Single and Double Burners –

4 pcs. for Triple Burners)

●

Mounting screws (2 pcs. for Single and Double Burners –

4 pcs. for Triple Burners)

For future reference, please record the serial number of your cooktop here:

___________________________________________

IMPORTANT

Save this documentation for review by local inspector.

This appliance must be properly installed and grounded by

a qualified technician.

Mounting brackets

Mounting screws

Fig. 1

Ceramic glass cooktop

Step #2

Check the Electrical Supply Requirements

This product must be installed in accordance with national, state and local

electric codes. The following table provides the correct voltage, amperage

and frequency that must be supplied to the cooktop.

SUMMIT

Model #

Maximum

Connected

Load

Required

Power Supply

Input

Minimum

Wire Size

CR 1115 1200 Watts 120V

AC/10A/60Hz #16 AWG

CR 2110 2400 Watts 120V

AC/20A/60Hz #16 AWG

CR 2220 2400 Watts 220V

AC/10A/60Hz #16 AWG

CR 3240 3600 Watts 220V

AC/15A/60Hz #16 AWG

The supply must be from an individual grounded circuit that is protected by

a circuit breaker and rated per the specifications for the various models as

shown in the table above.

WARNING: INSTALLATIONS MUST COMPLY WITH ALL LOCAL,

STATE AND NATIONAL ELECTRICAL CODES.

Failure to comply with the applicable codes may result in fire,

property damage, personal injury or death.

If the electric power supply does not meet the product

specifications, consult with a licensed electrician before

proceeding with installation.

Step #3

Countertop Preparation

Please read this section prior to making cutout for the cooktop.

It is important to plan ahead for installation of the cooktop, keeping the

following dimensions in mind (please refer to Fig. 2).

13 inches maximum depth of overhead

cabinets

36 inches is minimum height of countertop

above floor

The minimum flat countertop surface that

the cooktop will rest upon must be equal

to or greater than the overall cooktop

dimensions (refer to the following pages

for overall cooktop dimensions).

30 inches minimum clearance between

the top of the cooking surface and the

bottom of an unprotected wood or metal

cabinet or 24 inch minimum clearance

when the bottom of wood or metal cabinet

is protected by not less than ¼-inch-thick

flame retardant millboard covered with not

less than No. 28 MSG sheet steel, 0.015-inch-thick stainless steel,

0.024-inch-thick aluminum or 0.020-inch-thick copper.

1-inch minimum from backsplash of countertop to edge of glass (refer to

the following pages for overall cooktop dimensions).

Do not install closer than ½ inch (12 mm) from any adjacent surface!

Before making the countertop cutout, check for clearance. Check to see if

the cooktop will clear the front and side walls of the base cabinet. It is also

important to provide enough ventilation.

WARNING: To eliminate the risk of burns by reaching over

heated surface units, cabinet storage space located above

surface units should be avoided. If cabinet storage is

necessary, the risk can be reduced by installing a range hood

that projects horizontally a minimum of 5” beyond the bottom

of the cabinets.

Fig. 2

Adequate ventilation of the space below the countertop must be provided

to ensure proper operation of the cooktop. Heat transferred from the

cooktop bottom pan during operation will overheat an improperly ventilated

area.

Fig. 3

Allow a 2” minimum clearance between the bottom of the metal pan of the

cooktop and any combustible surface located below, i.e.: the upper edge of

a drawer installed below the cooktop (refer to Fig. 3). Failure to provide

proper clearances and ventilation may result in a fire hazard.

Cooktop dimensions for each model are shown below and on the following

page:

2 inch (51 mm) minimum

Model: CR1115 Models: CR2110, CR2220

Fig. 4a Fig. 4b

Summary of Cutout Dimensions

Model Width Depth

CR1115 11⅛" 11⅞"

CR2110, CR2220 11⅛" 19⅛"

CR3240 19⅞" 18⅜"

NOTE: When making the countertop, radius the corner of the cutout (1/4”

radius is typical). This will prevent cracking of the countertop. Follow

manufacturer’s instructions regarding minimum corner radius and

reinforcement of corners.

Model: CR3240

Fig. 4c

Step #4

Installing the Cooktop

Strips of foam sealant have already been installed around the outer

edge of the underside of the cooktop. This special sealant prevents

liquid from infiltrating into the cabinet. Additionally, the mounted sealant

helps prevent damage to the countertop if the cooktop should ever

need to be removed for servicing.

Attach the mounting brackets supplied with the SUMMIT cooktop (refer

to Figs. 6-7-8) to the inside bottom surface of the cutout. The brackets

are to be mounted on opposing sides. Center the bracket in the

opening, flush with the countertop and secure with long self-tapping

screws (included). Position the cooktop in the cutout opening and press

firmly on all sides to seal the frame into the sealant strips. Secure the

cooktop to the brackets from underneath with the small sheet metal

screws that are supplied. There are two mounting brackets for the

single and double glass ceramic cooktops and four brackets for the

triple glass ceramic cooktop. These brackets are designed to tighten

the cooktop and then seal it onto the counter to avoid any movement of

the cooktop and to provide good insulation.

Fig. 5

NOTE: BE CAREFUL NOT TO OVERTIGHTEN THE SCREWS.

NOTE: Cooktop carrier brackets have already been installed on your cooktop.

Fig. 7

Fig. 6

SELF-

ADHESIVE

SEALANT

Fig. 8
