Summer 3Dmicro Manual de usuario
For instructional video,
visit www.summerinfant.com/3Dmicro
or scan code.
components:
Stroller replacement parts:
rear wheels
front wheels
carry bag
canopy
32903-22
32903-24
32903-07
32903-10
IMPORTANT! Before assembly, inspect this product
for damaged hardware, loose joints or missing
parts. Never use if any parts are missing or broken.
!
2
Stroller
A
A
Carry bag
(on certain models only)
Front wheel
B
BC
C
2x
3
features:
storage basket
brakes
canopy
5-pt safety harness
harness covers
buckle
footrest
front wheels
soft handles
fold release buttons
rear wheels
fold lock
fold release button
seat recline clip
fold release button
4
unfolding stroller
1
2
34
!
NOTE: When
opening the stroller,
ensure that your
child, or other
children, are at a
safe distance.
To open, lift up on the fold lock.
Once unlocked, spread the back of
stroller open.
Quickly pull up stroller by the
handle bars until it clicks into
fully open position.
Make sure handles are fully extended into
the highest position.
click!
click!
Once handle is
locked into
highest handle
position pull up
on the crossbar
to lock it.
Look for this label on both sides of the frame to
check that the frame is LOCKED in OPEN position.
GREEN MUST be fully visible in window.
3
attaching wheels
Insert wheels into front mounts as shown.
Repeat on other mount.
5
Pinch the seat recline clip on back of stroller and slide recline clip along webbing
to adjust the seat recline.
To adjust handle height,
press the 2 fold release buttons
and pull handle to desired height.
adjusting the seat recline
adjusting handle height
1
2
3
6
canopy
To use canopy: pull forward to open and push back to close.
Press both brake levers down to lock both rear wheels.
Lift the foot pedal up to unlock the rear wheels.
brakes
7
locking/unlocking 5 point safety harness:
tightening and loosening the 5-point safety harness:
slide to tighten
slide to loosen
8
folding the stroller:
1
To fold the stroller, lock the rear brakes, close the canopy, and remove your child.
Squeeze button on cross bar between the handles and press down.
2Press the 2 thumb release buttons on the ends of the handles and press handles
down past the 3 handle height positions.
9
For instructional video, visit www.summerinfant.com/3Dmicro or scan code.
folding the stroller:
3
5
4Fasten the fold lock.
Press sides of stroller together.
click!
10
With fingers placed under the hooks,
push down completely on the stroller
handle then push the stroller forward
towards the ground.
