USER’S MANUAL
/
MODEL S2
USER’S MANUAL
OUR GOAL .......................................................................................................................... 4
THE SUIFF®PRO EQUIPMENT ............................................................................................ 4
THE SUIFF®PRO SENSOR .................................................................................................. 5
TECHNICAL SPECIFICATIONS FOR THE SUIFF®PRO SENSOR .......................................... 5
SUIFF®PRO SENSOR DETAILS ......................................................................................... 6
CORRECT USE OF THE SUIFF®PRO SENSOR ................................................................... 7
MAXIMUM ALLOWED LOAD ............................................................................................. 7
LED MODES ........................................................................................................................ 8
CLICK PATTERNS ................................................................................................................. 9
WARMING UP ....................................................................................................................... 9
CONNECTING THE SENSOR WITH THE APP AND CALIBRATING TO ZERO .................. 10
AUTOMATIC SWITCH-OFF FEATURE ................................................................................13
CHARGING THE BATTERY .................................................................................................14
BLUETOOTH RECOMMENDATIONS ................................................................................ 15
CHOOSING THE RIGHT PLACE TO USE SUIFF®PRO ...................................................... 15
SAFETY INFORMATION ..................................................................................................... 16
EXERCISES AND RECOMMENDATIONS .......................................................................... 18
HOW TO ANCHOR THE SUIFF®PRO SENSOR .................................................................19
MAINTENANCE ................................................................................................................. 21
PROBLEM SOLVING .......................................................................................................... 22
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENTS ..................................................24
DISPOSING OF THE EQUIPMENT ..................................................................................... 24
DISCLAIMER .......................................................................................................................25
WARRANTY ........................................................................................................................25
CUSTOMER SERVICE .........................................................................................................27
CONTENTS
USER’S MANUAL
Thank you for purchasing a SUIFF®product. This means you have a challenge ahead. Let us be
part of it and help you rise to it.
To use your SUIFF®PRO sensor with a mobile device, please install the SUIFF®PRO App on
your mobile phone or tablet.
Search for it on Google Play and download it.
For further information visit www.suiff.com.
WARNING! BEFORE STARTING YOUR SUIFF®PRO EQUIPMENT, CAREFULLY READ THE
USER’S INSTRUCTIONS AND SAVE THEM FOR FUTURE CONSULTATION.
USER’S MANUAL
4
OUR GOAL
THE SUIFF® PRO EQUIPMENT
We aim to help physical conditioning and rehabilitation professionals, providing technological
equipment that can add value to their patient treatment and services.
The SUIFF®PRO equipment consists of the SUIFF®PRO sensor and its training accessories:
The SUIFF®PRO case, the SUIFF®PRO carabiners, the express SUIFF® at sling and the Micro
USB cable.
SUIFF®PRO Kit SUIFF®PRO Case
Express SUIFF® Flat SlingSUIFF®PRO Carabiner
USER’S MANUAL
5
THE SUIFF® PRO SENSOR
The SUIFF®PRO sensor is an innovative and exclusive wireless sensor that can measure traction
forces applied in a wide variety of dynamic and static muscle strength exercises.
The sensor records force measurements and sends them to a mobile device, a smartphone or
tablet. The exclusive SUIFF®PRO mobile App receives and processes the data sent by the SUIFF®
PRO sensor and presents it to the user in real time.
The SUIFF®PRO sensor must be used with SUIFF®training accessories, for example the SUIFF®
PRO carabiners, the express SUIFF® at sling or the SUIFF®resistance band kit.
TECHNICAL SPECIFICATIONS FOR THE SUIFF® PRO SENSOR
Model
Dimensions (width x depth x height)
Weight (g)
Material of tensor piece
Material of body
Maximum load (kg)
Accuracy
Triaxial accelerometer
Sample frequency (Hz)
Maximal Supply Voltage (VAC)
Battery
Full charge cycle
Connectivity
Bluetooth range (m)
Compatibility
Recommended range of temperature
S2
136x78x31 mm
120
Aluminium alloy
PCB+ABS and thermoplastic vulcanizates (TPV)
180
±600 g o ±0.9% of reading (whichever is greater)
± 8 g
100
5 V 3 mA
Built-in rechargeable lithium polymer battery, 450 mAh
1 hour full charge cycle
Bluetooth Low Energy 4.0
15
Android
5°C to 35°C
USER’S MANUAL
6
SUIFF® PRO SENSOR DETAILS
Micro USB connector
To charge the battery with a
USB cable (USB A male Micro
USB B male).
Anchor handles
Aluminium alloy.
To attach the device to a wide
variety of exercise machines in a
fast and easy way.
Body
PCB+ABS and thermoplastic
vulcanizates (TPV).
On/off button
Switch on – click.
Switch off – Hold for 3 sec.
USER’S MANUAL
7
CORRECT USE OF THE SUIFF® PRO SENSOR
MAXIMUM ALLOWED LOAD
WARNING! PLEASE USE THE SUIFF®PRO SENSOR CORRECTLY AS DESCRIBED IN THIS
USER’S MANUAL. PAY SPECIAL ATTENTION TO OUR SAFETY RECOMMENDATIONS AND
KEEP UNATTENDED CHILDREN AWAY FROM THE DEVICE AND ITS ACCESSORIES.
The SUIFF® PRO sensor and its accessories do not require any difcult or complicated operations
but should be used under professional supervision.
The SUIFF®PRO sensor and its accessories can be used in any suitable space for the practice of
sport such as home, a garden, a tness centre or any public area that is appropriate for sport acti-
vities like parks, promenades or sports centres.
Both the SUIFF®PRO sensor and its accessories can be used outdoors at a temperature between
+5°C and +35°C but they should not be used when raining or be immersed in any liquid.
The SUIFF®PRO sensor can be used by children over 8 and by people with no experience or spe-
cialist knowledge if they know how to use the device and its accessories in a safe way and unders-
tand the risks involved.
The maximum traction load allowed by the SUIFF®PRO sensor is 180 kg.
If this maximum load of 180 kg is exceeded, the device’s measuring system or its internal sensor
might be affected leading to incorrect functioning.
WARNING! THE SUIFF®PRO SENSOR PROVIDES A STRUCTURAL SAFETY MARGIN OVER THE
MAXIMUM LIMIT LOAD WITHOUT RISKING THE STRUCTURAL INTEGRITY OF ITS ANCHOR
HANDLES OR THE INTEGRITY OF THE USER.
USER’S MANUAL
8
LED MODES
Upper led
Green light ashing
Sensor on
Upper led
Permanent blue light
Sensor connected to mobile
device
Lower led
Red light ashing
Low battery, recharge battery
USER’S MANUAL
9
CLICK PATTERNS
WARMING UP
To start the SUIFF®PRO sensor, press the power button once. The upper smart led will start blin-
king green, which indicates the device is on.
To switch the SUIFF®PRO sensor off, press the power button for three seconds until the upper
smart led goes off. Your device is off if the two led lights are inactive.
It is advisable to allow the sensor a short warm-up time of at least one minute before you start
training in order to get exact and stable readings. This is the warm-up time required by the
SUIFF®PRO sensor.
WARNING! NOT RESPECTING THE WARM-UP TIME MAY SLIGHTLY AFFECT THE PRECISION
AND ACCURACY OF FORCE MEASURES.
Sensor on
Click
Sensor off
Press for
3 s
USER’S MANUAL
10
CONNECTING THE SENSOR WITH THE APP AND CALIBRATING TO ZERO
Switch on the SUIFF®PRO sensor and open the SUIFF®PRO App on your mobile device.
Keep the SUIFF®PRO sensor on for at least 1 minute (warm-up time) before connecting it to your
mobile device to start training. To pair your SUIFF®PRO sensor with your mobile device:
A. Go to DEVICE LIST (1) and nd your SUIFF®PRO sensor on the DEVICE LIST, select it and
follow the instructions provided to connect and calibrate your SUIFF®PRO sensor.
1
