2017 Quick Reference Guide

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Lock/Unlock doors

BASIC OPERATION

For detailed operating and safety information, please refer to

your Owner’s Manual.

Remote keyless entry system

All doors and the rear gate will be locked/unlocked by the following procedures carrying the

access key on your person. (The driver should always carry the access key.)

Keyless access function (if equipped)

Side door (front door handles only): Rear gate:

Remote

transmitter key

(if equipped)

Access key

(if equipped)

PANIC

1All doors will be locked.

2The driver’s door will be unlocked.

(To unlock all doors, briey press the button

a second time within 5 seconds.)

3Press the button to open the rear gate.

4The horn will sound and the hazard warning

ashes will ash.

Lock

Unlock*

Door lock sensor

Grip

Touch

Press

Lock

Open

Press

*Grip the driver’s door handle to unlock the

driver’s door. Grip the front passenger’s

door handle to unlock all doors and the rear

gate.

Ignition switch must be in ACC or ON position.

1Select side to adjust.

2To adjust the mirror, move the switch in the

direction of your desired position.

Adjust each component

1Forward and backward adjustment

2Seat cushion angle adjustment

3Seat height adjustment

4Seatback reclining adjustment

5Lumbar support control

1Forward and backward adjustment

2Seat height adjustment (driver’s seat only)

3Seatback reclining adjustment

Power seat (driver’s seat - if equipped):

Manual seat (if equipped):

Front seat

Tilt/telescopic steering wheel

Remote control mirror switch

1Pull the tilt/telescopic lock lever down.

2Move the steering wheel to the desired level.

3Pull the lever up to lock the steering wheel in

place.

Make sure that the steering wheel is securely

locked by moving it up and down, and forward and

backward.

1 2

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Start/Stop engine

To start engine:

STEP1: Carry the access key, and sit in the driver’s seat.

STEP2: Apply the parking brake.

STEP3: Shift the select lever in the Pposition.

STEP4: Depress the brake pedal until the indicator on

the push-button ignition switch turns green.

STEP5: While depressing the brake pedal, press the

push-button ignition switch.

To stop engine:

STEP1: Stop the vehicle completely.

STEP2: Move the select lever to the Pposition.

STEP3: Apply the parking brake.

STEP4: Press the push-button ignition switch.

Every time the button is pressed without depressing the brake pedal, the power is

switched in the sequence of OFF➞ACC➞ON➞OFF.

OFF ( Turned off ) ACC (Orange) ON (Orange)

Change of the power supply (Without starting engine)

The key can be turned from ACC to LOCK only

when the select lever is in the Pposition and the key

is pushed in while turning it.

Push-button ignition switch (if equipped)

Ignition switch (if equipped)

Operation

indicator

Shift paddle:

Gearshifts can be performed using the shift paddle

behind the steering wheel.

Operate Select lever/Shift lever

M = Manual mode:

With the vehicle either moving or stationary, move

the select lever from the D position to the M position

to select the manual mode.

Continuously variable transmission (if equipped)

With the brake pedal depressed, shift while

pressing the button in

Shift while pressing the button in

Shift without pressing the button

Select lever button

Downshift Upshift

Models with

Manual mode

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

MAIN PARTS AND OPERATION

1Headlights

2 Headlightasher,High/Lowbeamchange

(dimmer)

3Turn signal

4Front fog lights (if equipped)

Headlight switch/Turn signal lever/Fog light switch

1Windshield wiper:

To operate the wiper, rotate knob to;

: Mist (for a single wipe)

: Off

: Intermittent

: Low speed

: High speed

2Wiper intermittent time control

3Windshield washer:

Pull the wiper control lever toward you.

4Rear window wiper and washer:

To operate the wiper, rotate knob to;

: Continuous

: Intermittent

: Off

: Washer (accompanied by wiper operation)

Wiper and washer switch

To turn on the hazard warning asher, press the

button.

Use the hazard warning asher when you have to

park in emergency conditions.

 Hazardwarningasherswitch

Turn the dial to adjust the illumination brightness of

the instrument panel.

When the control dial is turned fully upward to

position, the illumination brightness becomes the

maximum and the automatic dimming function does

not work at all.

Illumination brightness control dial

To brighten

To darken

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

1Defroster button:

Press the button or turn the dial to defrost the

windshield.

2Rear window defogger button:

Press the button to turn on rear window defogger,

outside mirror defogger and windshield wiper

deicer (if equipped). The function will automatically

shut off after approximately 15 minutes.

Defroster button/Rear window defogger button

Hood lock release knob

Power rear gate switch (if equipped)

Memory switch (if equipped)

Your desired rear gate height can be registered.

Press and hold

Pull

1Lock switch

2For driver’s window

3For front passenger’s window

4For rear left passenger’s window

5For rear right passenger’s window

Power window switches

To unlock all doors and the rear gate

To lock all doors and the rear gate

Power door locking switch

Seat heater switches (if equipped)

HIGH

LOW

HIGH

LOW

HIGH: Rapid heating

LOW: Normal heating

 Fuelllerlidreleaselever

Pull

This indicates that the fuel ller door (lid) is

located on the right side of the vehicle.

Right side

◆Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Audio control buttons

These buttons allow the driver to control audio

functions without taking his/her hands off the

steering wheel.

1To lower:

Pull the release lever and slide the anchor down.

2To raise:

Slide the anchor up.

Front seat shoulder belt anchor height

Moonroof switch

1Open

2Close

Located on the edge of each rear door.

When the lever is in the LOCK position, the rear

door cannot be opened from the inside.

Child safety locks
