M-SERIES
GENERAL INFORMATION
Thank you for choosing a Li510 Lithium Material
Handling Baery. This baery system is completely
self-contained and can be used as a direct
replacement for the most current in-use lead acid and
lithium-ion systems.
Scope of supply
The following parts are included:
• Li510 Lithium Material Handling Baery
Documentaon (installaon and operaon manual)
• External display (oponal)
• Stryten Energy Charger (oponal)
Aer unpacking the parts, please examine them for
possible damage. If any damage is found, please do
not use the product; if in doubt, please contact the
manufacturer.
The described product is a Lithium rechargeable
baery system for use in material handling
applicaons.
SAFETY INSTRUCTIONS
Informaon and instrucons aached directly on the
Li510 Lithium Material Handling Baery system must
always be followed. These instrucons contain basic
informaon and guidance to be noted and followed
during operaon and maintenance and must be read
by all personnel.
The Stryten Energy Lithium-ion baery system may
not be operated without precise knowledge of these
Installaon and Operang Instrucons or without
strict adherence to all safety instrucons. Knowledge
of the contents of the Installaon and Operang
manual is a fundamental requirement to protect
people from danger, to avoid errors and to operate
the system safely and fault-free.
The Installaon and Operang Instrucons must be
accessible to operang and maintenance personnel
at all mes. Each person given the task of operang
or maintaining the system must have read and
understood the instrucons.
WARNING:
DEEP DISCHARGE SHOULD BE AVOIDED AT
ALL COSTS AS THE SUDDEN CUT OFF OF
THE BATTERY CAN LEAD TO DAMAGE AND
HAZARDS, SUCH AS SPONTANEOUS STOP OF
THE VEHICLE.
THE RESET BUTTON CAN BE PRESSED ONCE
TO GET THE VEHICLE TO THE CHARGER. AFTER
THAT, THE BATTERY REMAINS TURNED OFF
IN ORDER TO AVOID FURTHER DAMAGE. THE
VEHICLE NOW HAS TO BE TOWED TO THE
CHARGER WITH AUXILIARY MEANS.
INSTALLATION/OPERATION
Quick Start Guide
• Check the baery housing, the cables and
connectors for damages.
• Switch the baery on by pressing the ON/ OFF
buon for one second, observe the buon.
• In normal operaon the buon will rapidly ash
green for a few seconds while the baery powers up,
and will then steadily ash green once per second.
Flashing red color indicates a warning or failure state.
Please refer to the secon Warning and Alarms in
this case.
• At the delivery state the baery SOC display should
indicate a State of Charge of 30% or higher.
• The baery must be fully charged prior to rst usage.
The Li510 Lithium Material Handling Baery
communicates status to the vehicle via the CAN bus
and to the operator via an external Stryten Energy
display.
Deep Discharge Protecon
When charge level is low, the buzzer beeps once per
second. The baery must be charged immediately. If
the baery becomes deeply discharged, the buzzer will
beep rapidly (3 mes per second), indicang that the
baery will turn o in 15 seconds.
Li510
