Strikemaster ES Engineering Manual Page 1 of 1 For more information visit www.storm-interface.com



The StrikeMaster ES is a robust and reliable Access Control keypad for installations requiring elevated security levels.

Constructed to survive in exposed, outdoor or unsupervised environments these keypads combine the field proven

durability of the StrikeMaster keypad with a remotely secured electronic control module.

The control module along with a dedicated high spec power supply is contained within an alarmed, secure steel

enclosure. This Secure Controller Unit (SCU) is located within the secured environment, protected from attempts to

breach or disable building security systems.

The Secure Controller Unit (SCU) supports up to two keypads and can control two doors

This manual covers the entire product range, and is available from www.storm-interface.com/downloads.

Each individual product includes a printed datasheet with just the essential information for installation..

Table of Contents



Product Range................................................................................................................................................................2

What’s in the Box ?........................................................................................................................................................3

Installation for DXPS1K10 / DXPS1W10....................................................................................................................4

Installation for DXPS1K30 / D DXPS1W30................................................................................................................7

ProgrammingChart...........................................................................................................................................................9

WallFixingofKeypad–FixingCentresOptions..............................................................................................................11

ControllerConnections–PictorialView.........................................................................................................................12

RecordCard.....................................................................................................................................................................13

ControllerSetup..............................................................................................................................................................17

Programming Mode Functions...............................................................................................................................17

1Add Entry Codes............................................................................................................................................

18

2Remove Entry Codes....................................................................................................................................18

3Enable / Disable Tamper Mechanism on SCU Case Door...................................................................19

4Change Engineer’s Code.............................................................................................................................19

5Set / Change Door Strike Time...................................................................................................................19

6Enable Door Sensor......................................................................................................................................20

7Set Penalty Time.............................................................................................................................................21

9Reset to Factory Defaults............................................................................................................................21

ExampleSystemConfigurations.....................................................................................................................................22



Whilst every effort is made to ensure details are correct at time of print, specifications are subject to change without notice.

Storm Interface products include technology protected by international patent and design registration. Storm is a trademark of Keymat Technology Ltd

Storm Interface is an ISO9001 registered company. Storm Interface is a trading name of Keymat Technology Ltd

Strikemaster ES

Engineering Manual



Strikemaster ES Engineering Manual Page 2 of 2 For more information visit www.storm-interface.com



Product Range

DXPS1K10 Strikemaster ES Controller Kit with Anti-Vandal Keypad (incl Door A connector)

DXPS1W10 Strikemaster ES Controller Kit with Illuminated Keypad (incl Door A connector)

DXPS1K30 Strikemaster ES Controller Kit with Anti-Vandal UL294 Keypad (incl Door A connector)

DXPS1W30 Strikemaster ES Controller Kit with Illuminated UL294 Keypad (incl Door A connector)

DX1KT20 Strikemaster ES Anti-Vandal Keypad (incl Door B connector)

DX2KW20 Strikemaster ES Illuminated Keypad (incl Door B connector)

DXPS0010 Spare Controller

DXPS0030 Spare Controller UL294

RC12020 Back Box for Keypad

1KFS020 Privacy Shield for Keypad

The Strikemaster ES Controller and Keypads are common items; please note that Controller part numbers

are structured as follows :-

Part number ends in 30 Product is supplied in a UL294 PSU Enclosure (rated 120-230V)

Part Number ends in 10 Product is supplied in an EU PSU Enclosure (rated 90- 264V)

Strikemaster ES

Engineering Manual



Strikemaster ES Engineering Manual Page 3 of 3 For more information visit www.storm-interface.com



What’s in the Box ?

Installation Sheet

Controller (both types pictured)

Secure Controller in UL294 PSU or Secure Controller in EU PSU

Keypad Surface Box

Anti-Vandal and seal

shown in pic.

Keypad Wall Screws/

Screws/bit Plugs

Leads for Battery Plugin

Controller

Connectors

Ferrite

Strikemaster ES

Engineering Manual



Strikemaster ES Engineering Manual Page 4 of 4 For more information visit www.storm-interface.com



Installation for DXPS1K10 / DXPS1W10

This unit is only suitable for installation as permanently connected equipment.

The PSU is NOT SUITABLE for external installation.

EQUIPMENT MUST BE EARTHED.

Before installation, ensure that all power is removed from any cabling.

This equipment MUST be installed according to all relevant safety regulations.

As this is permanently connected a readily accessible disconnect device must

be located near the equipment.

Fix the PSU Box

Use the drill template. Mount securely allowing minimum clearance of 100mm above and side from wall.

Route mains and low voltage output cables via different cable entry holes.

Use bushes and cable glands rated to UL94 HB minimum.

Connect the Mains Cable

Use 3-core mains cable, with a minimum capacity of 3A at 240VAC. Fasten using cable ties.

Connect to the power supply terminal block

and clip the mains cable into the adjacent support clip .

Ensure the mains cable is physically secured

Keypad/Lock Wiring

The wiring diagram on the next page shows how each component must be connected.

Note that only keypad A can be used for programming

Ensure that you fit a spike suppressor across the door lock connections.

Ensure that any pairs of wires are twisted together

Mains Power Up

Apply mains power.

Check green Mains LED is on

Disconnect mains power

Standby Battery

If necessary, connect a 12V lead-acid rechargeable battery using the battery leads supplied.

Ensure the battery polarity is correct (red is +ve, black is –ve).

Please note: if the battery is partially charged, the controller might now be powered. Green LED will be on.

Apply mains power and check there is no fault indication (red LED).

After a few minutes, disconnect mains power and ensure that the controller remains powered from the battery

Controller Setup

Once you have fitted the keypad / door lock / exit switch you can configure the controller.

Press the program switch on the controller board ( LED will flash), and set a new Engineer Code.

Write down the new code inside the door of the PSU box.

Program entry codes and lock operation via the Door A connector ( either locally or from Door A keypad outside)

100mm

Strikemaster ES

Engineering Manual



Strikemaster ES Engineering Manual Page 5 of 5 For more information visit www.storm-interface.com



PSU Connections and Fuses

F1: Mains Input F2 :PSU Output Fuse F3 :Battery Fuse

Earth Live

Neutral

Live Fault

Battery

Fuses

Mains Input F1 :T2AH 5mm x 20mm Time Delay Fuse. Recommend Cooper Bussmann S505-2-R

Output F2 : F3.15A Quickblow, 5mm x 20mm. Recommend Cooper Bussmann S500-3.15A

Battery F3 : F1A Quickblow, 5mm x 20mm. Recommend Cooper Bussmann S500-1A

Strikemaster ES

Engineering Manual



Strikemaster ES Engineering Manual Page 6 of 6 For more information visit www.storm-interface.com



PSU

The PSU Model # G13803N features a regulated 13.8Vdc output supplying continuous full rated current to load and

up to an additional 0.5A for charging a standby battery. The universal mains input voltage enables the power supply to

be used across a wide geographical area. The highly efficient switch mode design ensures low operating costs,

generates less heat and with a small physical size increases the room available for additional PCBs or cables. The

modular construction simplifies maintenance.

Continuous full rated current to load

Additional 0.5A to charge standby battery

Universal mains input voltage 90-264Vac

High efficiency electronics for reduced running costs and lower operating temperatures

Installer safe design with all high voltage electronics fully shrouded

Modular construction for ease of maintenance and installation

Full electronic short circuit and overload protection on load output under mains operation

Mains transient protection circuit

Lid opening tamper detection RATING 0.05A, 24vdc

Green Mains present LED

Red Fault LED

Input Specification

Voltage (rated) 100-240Vac

Voltage (operating) 90-264Vac

Frequency 50-60Hz

Max current 1.2A

Mains Input Fuse T2.0A

Max standby Power 0.5W (No load and No battery connected)

Output Specification

Voltage 13.4 – 14.2vdc (13.8vdc nominal) on mains power

10.0 – 12.3vdc on battery standby

Max load current 3A

Ripple 150 mV pk-pk max

Load output Fuse F3.15A

Overload Electronic shutdown until overload or short circuit removed (under mains

power only)

In order to meet the requirements of immunity std EN 50130-4 Clause 8 Voltage Dips & Interruptions , the

back-up battery must be fitted, or the system must be powered via an uninterruptible power supply (UPS)

Recommended Battery 12v Valve Regulated Lead Acid

Battery Type & Capacity 1 x NP7-12 (8Ah)

Battery Charging Fuse

protection F1.0A 20mm glass

Caution : Risk of explosion if battery is replaced by an incorrect type.

Dispose of used batteries according to user instructions

Strikemaster ES

Engineering Manual



Strikemaster ES Engineering Manual Page 7 of 7 For more information visit www.storm-interface.com



Installation for DXPS1K30 / DXPS1W30

This unit is only suitable for installation as permanently connected equipment and the controller is NOT SUITABLE for

external installation. EQUIPMENT MUST BE EARTHED. Before installation, ensure that all power is removed from

any cabling. This equipment MUST be installed according to all relevant safety regulations. As this is permanently

connected a readily accessible disconnect device must be located near the equipment.

Fix the Controller

Install the controller to the wall following Section 1 in the FPO Manual included with the product.

Select Input Voltage – default is 120V, cut and remove Jumper JP1 for 230V

Connect the Mains Cable to J9

J9 accepts the provided three-wire connector harness for connection to AC. Connections are by wire nut as follows:

120VAC 230VAC

Green – Earth Ground Green – Earth Ground

Black – Hot Black – Phase 1

White – Neutral White – Phase 2

Keypad/Lock Wiring

Make Connections for keypad, lock and alarms into the connector blocks, then plug them into the Secure Controller

Typical setup as shown below. The black connectors are for a second keypad / second door.

Note that only keypad A can be used for programming. Leave the keypad switch in RUN mode at all times.

Ensure that you fit a spike suppressor across the door lock connections.

GREEN DOOR A KEYPAD CONNECTOR

WITH EXIT SWITCH AND DOOR SENSOR

GREEN DOOR A LOCK

CONNECTOR WITH MAG LOCK

(LINK FROM A TO C)

BLUE ALARMS CONNECTOR WITH 12V BELL

(200mA max) AND NORMALLY OPEN ALARM

SOUNDER (LINK FROM 1 TO 4)

1 KEYPAD +12V TO KEYPAD A +12V 1 BELL +12V

2 KEYPAD KEYPAD LED/BUZZER B LOCK RELAY NC 2 +12V

3 KEYPAD KEYPAD D1 C RELAY COM 3 RELAY NC ALARM

4 KEYPAD KEYPAD D0 D RELAY NO 4 RELAY COM

5 KEYPAD GROUND E LOCK GROUND 5 ALARM RELAY NO ALARM

6 SENSOR DOOR SENSOR 6 BELL BELL

7 EXIT EXIT SWITCH 7 GROUND

8 EXIT &

SENSOR GROUND 8 ALARM GROUND

CAUTION

Always connect earth ground first

and disconnect last

Strikemaster ES

Engineering Manual



Strikemaster ES Engineering Manual Page 8 of 8 For more information visit www.storm-interface.com



Power Up & Controller Setup

Mains Power Up

Apply mains power.

Check green Mains LED is on. (The diagram below shows all the connections on the FPO75, not all are used).

Disconnect mains power

Standby Battery

If using a standby battery, connect a 12V lead-acid rechargeable battery using the battery leads supplied.

Ensure the battery polarity is correct (red is +ve, black is –ve).

Please note: if the battery is partially charged, the controller might now be powered. Green LED 19 will be on.

Apply mains power (Green LED will be on) and check there is no fault indication on LED .

After a few minutes, disconnect mains power and ensure that the controller remains powered from the battery

Controller Setup

Once you have fitted the keypad / door lock / exit switch you can program the controller.

Make sure the keypad is fitted to the backbox (otherwise it will tamper when you try to program)

Press the program switch on the controller board (LED will flash), and set a new Engineer Code.

Keep a record of the Engineer Code

Program entry codes and lock operation via the Door A connector (either locally or from Door A keypad outside)

Strikemaster ES Manual



Strikemaster ES Engineering Manual Page 9 of 9 For more information visit www.storm-interface.com



Toaddnew

Engineer’sCode

Enter



Enternew6digit

Engineer’sCode



Removecode



Enter



Toaddan

entrycode

Enter



Enterthe2digitindex

number(max98)

Selectdoor

andmodeofentryrequired

forthisentrycode

Enter

newcode



Enter



EnterIndex

numberwhere

codeistobe

removed

Enter



DoorA

Timed

Enter



DoorA

Latched

Enter



DoorB

Timed

Enter



DoorB

Latched

Enter



Index

allocated

–try

another

IndexNo.DoorA



Enter



Tosetdoorstriketimes



Enter



DoorB



Enter



EnterStrikeTimein

seconds

Enter

Toreset

PenaltyTime

Enter



EnterPenaltyTimein

seconds



Enter



Systemcommands



Enter



Startnew

commandsequence

ChooseOptionto

LOGOFFNOW?Enter



NO YES

To Enter Programming Mode from Door A

Keypad: Press # then the Engineer Code

#

ChangeEngineer

Code

Removecode



AddingacodeDoorStrikeTime

Set

PenaltyTime



Systemisnowin

NormalOperationMode

Systemremainsin

ProgrammingMode

A/B

Timed

Enter



ResetFactory

Defaults

EnterPINlengthforuser

codes



4,5or6tocorrespond

tono.ofdigitsincode

Enteroror

Enable/DisableDoor

Sensor

ToEnable/DisableDoorSensor



Enter



Resetto

factory

defaults



Enter



DoorA

Remove

Single

Code



DoorB

Remove

single

code



DoorA

Remove

all

codes



DoorB

remove

all

codes



remove 

all

codes



Door A



Enter



Door B



Enter



Enable

sensorand

alarm



Enter



Enablesensor,

Disablealarm



Enter



Enable/Disable

CaseTamper

A/B

Latched

Enter



Yes



Enter





No



Enter



Press the programming switch on the controller to enter

Programming Mode. Then enter #111111 on Door A Keypad

You have to do this for Initial Setup, or to Change the Engineer Code,

or to Reset Factory Defaults.

Enable/Disable

casetamper



Enter



To

Disable

Enter



To

Enable

Enter



Disable

sensorand

alarm



Enter



Programming

Chart

Strikemaster ES Manual



Strikemaster ES Engineering Manual Page 10 of 10 For more information visit www.storm-interface.com



DrillTemplateforWallFixingofEUControllerEnclosure

UseNo.8x1.5”PanheadScrews

Allowatleast100mmairspacebetweensideofcaseandwall

Tabla de contenidos

Manuales populares de Controladores de acceso IP de otras marcas

ZKTeco

ZKTeco SpeedFace-V5L Manual de usuario

Jantar

Jantar REX A-1-9 Manual de usuario

2N Access Unit Hoja de instrucciones

Kedacom

Kedacom KSCA120 Series Manual de usuario

H3C

H3C WX2880X Manual de usuario

G4S

G4S S870-EX Guía

PRASTEL

PRASTEL M2000PE Manual de usuario

Allegion

Allegion interflex IF-281 Cylinder Manual de usuario

TECOM

TECOM TS1067E Manual de usuario

Fermax

Fermax Memokey 100C Guía del usuario

Fermax

Fermax CITYLINE MEMOKEY Manual de instrucciones

Software House

Software House iSTAR Pro 2U RM Manual de instrucciones

AKCP

AKCP SP+ Manual de usuario

Bpt

Bpt HNA/102 Manual de usuario

Civintec

Civintec CV9601T-T-1F Manual de usuario

BioMax

BioMax N-X90W Manual de usuario

ZKTeco

ZKTeco OP-200 Manual de usuario

FingerTec

FingerTec s-Kadex Manual de usuario
