STK Professional Audio PASSIVE SPEAKER SYSTEMS Manual de usuario

PASSIVESPEAKERSYSTEMS

OWNER'SMANUAL ENGLISH

Warranty Information

UNPACKING

As a part of our system of quality control, every

STK product is carefully inspected before leaving the

factory to insure flawless appearance. After unpacking,

please inspect for any physical damage. Save the

shipping carton and all packing materials, as they were

carefully designed to reduce the possibility of

transportation damage should the unit again require

packing and shipping. In the event that damage has

occurred, immediately notify our dealer so that a written

claim to cover the damage can be initiated with the

carrier. The right to any claim against a public carrier

can be forfeited if the carrier is not promptly notified

and if the shipping carton and packing materials are

not available for inspection by the carrier. Save all

packing materials until the claim has been settled.

S T K C u s t o m e r S e r v i c e D e p a r t m e n t

369-2 KURAERI YANGCHON-MYUN KIMPO -CITY

KYOUNG GI-DO, KOREA.

TEL : +82-(0)31-9 8 1 -1788

FAX : +82-(0)31-981-1 7 8 4

E-mai l : s t kcom@stk pr o . com

w w w . s t k p r o . c o m

STK LIMITED 1 YEAR WARRANTY

STK electronics are warranted to be free from

defects in materials and workmanship under normal

use for a period of 1 year from date of original

purchase. During that period, STK will at its option,

repair or replace materials at no charge if product has

been delivered to STK by an STK dealer or STK

Service Center together with the original sales receipt

or other proof of purchase. Warranty excludes fuses,

exteriorm finish, normal wear, failure due to abuse,

or operation outside of specified ratings. Warranty

applies to original purchaser only. This warranty gives

you specifically rights which vary from state to state.

For more information about warranty repair,

please contact:

Cus tomer Servi ce Dept., T h e

S T K P r o f e s s i o n a l A u d i o .

F O R Y O U R R E C O R D S

All of us at STK thank you for your expression of

confidence in STK products. The unit you have

purchased is protected by a limited 1 year warranty.

To establish the warranty, be sure to fill out and mail

the warranty card attached to your product.

For you own protection, fill out the information below for you own records.

Model Number

Serial Number

Dealer

Date Of Purchase

Salesman

Phone

Other Information

Introduction

TheSTKspeakersystemplacesprofessionalqualityfullrange,stand-mount pro audio speaker technology

within easy reach of the working,burget mounted performer. Recent developments include an improved constant

directivity horn for better off-axis response in the high frequency range.

High-frequency which enables them to continue to function, without damage, during typical overload condition.

STANDARDFEATURES

▶Ultra tough Warnex texture coating

▶Heavy-gauge, perforated metal speaker grille.

▶Dual speakon jacks.

▶Metal stand adapters.(except large cabinet).

▶3/4" plywood and chipboard construction.

▶Horn tweeter protection circuitry.

Features

SP-112

A 2-Way system with one 12 inch heavy duty speaker and one high

frequency bullet compression tweeter in an extremely lightweight

aluminum stand adapter.

▶Frequency response: 70㎐to 18㎑

▶SPL: 100㏈at 1W/1m

▶Power handling 150watts continuous, 300watts program

▶Impedance: 8ohms.

▶Suggestion system: V-2, VM-4DDR, VM-6 S DRV,

SP-122

One 12inch heavy duty speaker and on high frequency horn in an

extremely light weight vented enclosure with aluminum stand

adaptor..

▶Frequency response: 63㎐to 18㎑

▶SPL: 101㏈at 1W/1m

▶Power handling 250watts continuous, 500watts program

▶Impedance: 8ohms.

▶Suggestion system: V-2, V-3.5M, V-6, VM-8DRV, VM-1 1 S D RV

SP-152L

One 15inch heavy duty speaker and on high frequency horn in an

extremely light weight vented enclosure with aluminum stand

adaptor..

▶Frequency response: 60㎐to 18㎑

▶SPL: 101㏈at 1W/1m

▶Power handling 200watts continuous, 400watts program

▶Impedance: 8ohms.

▶Suggestion system: V-2, V-3.5M, V-6, VM-8DRV, VM-1 1 S D RV,

SP122H

The SP-122H is the compact solution for high power loud speaker

applications where space is premium . A two way passive, trapezoid

system, the SP-122H has a 12"Con Bass driver for high power

handling, coupled with a 2" voice coil compression driver.

▶Frequency response: 60㎐to 18㎑

▶SPL: 101㏈at 1W/1m

▶Power handling 400watts continuous, 800watts program

▶Impedance: 8ohms.

▶Suggestion system: V-6, VS-15, V-9, VM-11SDRV, VM-1 6 S D D R

VM-14SDDR,SM-16SDDR

SP152H

The SP-152H is the compact solution for high power loud speaker

applications where space is premium . A two way passive, trapezoid

system, the SP-152H has a 15"Con Bass driver for high power

handling, coupled with a 2" voice coil compression driver.

▶Frequency response: 60㎐to 18㎑

▶SPL: 101㏈at 1W/1m

▶Power handling 300watts continuous, 600watts program

▶Impedance: 8ohms.

▶Suggestion system: V-6, VS-15, V-9, VM-1 1 S D RV, VM-1 6 S D D R

VM-14SDN

SP-153H

A 3-way enclosure, with one 15inch heavy duty speaker. One heavy

duty 6inch mid range, and one 2.5inch horn tweeter. The SP153 is

pre-wired for full range or bi-amp operation.

▶Frequency response: 53㎐to 19㎑

▶SPL: 101㏈at 1W/1m

▶Power handling 300watts continuous, 600watts program

▶Impedance: 8 ohms.

▶Suggestion system: V-6, VS-12, V-9, VM-1 1 S D R V ,

VM-14SDDR, VM-16SDDR

SP-4730N

High-efficiency, three-way system enclosure, with one 15inch heavy

duty speaker. One heavy duty 8inch mid range, and one 2inch horn

tweeter. The SP4730N is pre-wired for full range or bi-amp

operation.

▶Frequency response: 53㎐to 18㎑

▶SPL: 100㏈at 1W/1m

▶Power handling 400watts continuous, 800watts program

▶Impedance: 4 ohms.

▶Suggestion system: V-9, VS-15, VS-2004, SM-1 6 S D DR

SP-4730H

High-efficiency, three-way system enclosure, with one 15inch heavy

duty speaker. One heavy duty 8inch mid range, and one 2inch horn

tweeter. The SP4730H is pre-wired for full range or bi-amp

operation.

▶Frequency response: 53㎐to 18㎑

▶SPL: 100㏈at 1W/1m

▶Power handling 400watts continuous, 800watts program

▶Impedance: 8 ohms.

▶Suggestion system: V-9, VS-15, VS-2004, SM-1 6 S D D R

SP-253N

High power, 2-Way system featuring two high power 15inch

speakers, a large format compression driver. The SP-253N is pre

wired for full range and bi-amp operation.

▶Frequency response: 50㎐to 19㎑

▶SPL: 101㏈at 1W/1m

▶Power handling 800watts continuous, 1600watts program

▶Impedance: 4ohms.

▶Suggestion system: VS-15, V S -2004, VS-20, SM-1 6 S D DR

SP-4733N

High power, 2-Way trapezoidal system engineered for full range

or bi-amp operation. Features two 15inch speakers with

impregnated

cones plus a high frequency compression driver coupled to a die

cast aluminum horn.

▶Frequency response: 50㎐to 18㎑

▶SPL: 103㏈at 1W/1m

▶Power handling 1200watts continuous, 2400watts program

▶Impedance: 4ohms.

▶Suggestion system: VS-15, V S -2004, VS-20, VS-34

SP-218S(SUBWOOFER)

The SP218S is a dedicated high performance sub bass system

designed to augment the Low frequency output of the SP-218 in

large scale applications where the sub bass enclousers must be

used.

▶Frequency response: 30㎐to 200㎐

▶SPL: 98㏈at 1W/1m

▶Power handling 1600watts continuous, 3200watts program

▶Impedance: 4 ohms.

▶Suggestion system: VS-34, VS-40

Features

SP-118S (SUB WOOFER)

Designed for a variety of professional applications, the SP118S a

adheres to a continuing legacy of high efficience and performance

value. A dedicated sub woofer with dual 18 inch transducer in a

vented trapezoidal enclosure engineered to complement the SP

series

full range system. Recessed cup on the top accept the footpads of

a SP4733A or another SP 118S.

Frequency response: 30㎐to 200㎐

▶SPL: 95㏈at 1W/1m

▶Power handling 800watts continuous, 1600watts program

▶Impedance: 8 ohms.

▶Suggestion system: VS-20, VS-2003

SPM-122 (ABS MOLDED CABINET))

The SPM-122 is compact full range sound system with tough

molded ABS cabinets.

Its very light and easy carry full range speaker system.

▶Frequency response: 55㎐to 19㎑

▶SPL: 100㏈at 1W/1m

▶Power handling 200watts continuous, 400watts program

▶Impedance: 8ohms.

▶Suggestion system: VM-4DRV, VM-8DRV, V6, SP-158AP for

satellite

SPM-152H (ABS MOLDED CABINET)

The SPM152H is a 2-way full range system with ABS molded

cabinet.

Enclousers are trapezoidal in shape and easy stacked

▶Frequency response: 55㎐to 19㎑

▶SPL: 98㏈at 1W/1m

▶Power handling 300watts continuous, 600watts program

▶Impedance: 8ohms.

▶Suggestion system: V-6, V-3.5M, VM-8DRV,

VM-11SDRV ,VM-11TDRV

SPM-155H (ABS MOLDED CABINET)

The SPM155H is a 2-way full range system with ABS molded

cabinet.

Enclousers are trapezoidal in shape and easy stacked

▶Frequency response: 55㎐to 19㎑

▶SPL: 98㏈at 1W/1m

▶Power handling 500watts continuous, 1000watts program

▶Impedance: 8ohms.

▶Suggestion system: V-6, V-3.5M, VM-8DRV, VS-15

VM-11SDRV ,VM-11TDRV

SP-115S(SUBWOOFER)

The SP-115S is for sub woofer system in a bass reflex rectangular

enclouser .

▶Frequency response: 53㎐to 350Hz

▶SPL: 99㏈at 1W/1m

▶Power handling 400watts continuous, 800watts program

▶Impedance: 4 ohms.

▶Suggestion system:V-9, VS-15, SP-158AP EXTERNAL delivered

SP-118SL(SUBWOOFER)

The SP-118SL is for sub woofer system in a bass reflex rectangular

enclouser .

▶Frequency response: 30㎐to 200Hz

▶SPL: 100㏈at 1W/1m

▶Power handling 600watts continuous, 1200watts program

▶suggestion system for SUB : SP-1812AP

▶Impedance: 4 ohms.

SP-115M

The SP-115M is professional 2-way full range monitor system

with 15" SK15300 transducers vented the enclosure designed

specialized floor wegge for perfect pattern control with dual purpose

stage monitor and main.

▶Frequency response: 55㎐to 18kHz

▶SPL: 99㏈at 1W/1m

▶Power handling 250watts continuous, 500watts program

▶suggestion system for SUB : SP-1812AP

▶Impedance: 8 ohms.

SP-112M

The SP-112M is professional 2-way full range monitor system

with 12" SK12150 transducers vented the enclosure designed

specialized floor wegge for perfect pattern control with dual purpose

stage monitor and main.

▶Frequency response: 70㎐to 18kHz

▶SPL: 99㏈at 1W/1m

▶Power handling 150watts continuous, 300watts program

▶suggestion system for SUB : SP-158AP

▶Impedance: 8 ohms.

SP-215S(SUBWOOFER)

The SP-215S is for sub woofer system in a bass reflex rectangular

enclouser .

▶Frequency response: 47㎐to 350Hz

▶SPL: 101㏈at 1W/1m

▶Power handling 1200watts continuous, 2400watts program

▶suggestion system for SUB : V-9, VS-12, SP-158AP EXTERNAL

delivered

▶Impedance: 4 ohms.

ENCLOSURE CONSTRUCTION

The STK speaker system enclosure utilizers a structural

material that combines the strength of high-quality plywood

with the density and acoustic damping of particle board

without brittleness. Road-Wood uses the same principle of

crossbreeding veneers, as in plywood, in order to achieve its

very high is rigidity. Alternate layers are perpendicularly

bonded under intense heat and pressure to form panels of

superior uniformity. Unlike many grades of plywood,

Road-Wood is dimensionally stable, water-resistant and free

from voids.

A combination of dado-cut joints, tough adhesives,

and proper bracing ensure a sonically dead enclosure free

from panel resonances. The densely-woven, industrial-grade,

abuse-resistant carpeting provides a finish that is both

attractive and highly durable. Large, heavy-duty metal corner

protectors, firmly secured rubber feet, and recessed handles

complete the enclosure and ensure that the Music Town

seriessystemisideallysuitedtoa long and reliable life "on the

road."

CONNECTIONS

The STK speakersystem is equipped with high quality

Speakon connectors. Two connectors are installed in parallel

akkowing additional STK speaker system to be installed.

One matching Speakon connector is supplied with each

system. These connectors are locking, self-polarizing and

capable of 30 amps RMS continuously. Additional connectors

and cables can be purchased from your dealer.

BI-AMPING

The SP153H, SP4730N and SP4733N may be easily converted

for bi-amp operation. On the rear connector panel there are

two 6pin terminal block with exposed link bar connector. For

full range operation the 4 link bar is as figure 1.

Reconnecting the 2 link bar in the bi-amp operation. The

crossover frequency for bi-amp operation should be between

500 and 800 Hz with either a second-order Butterworth

(12-dB-per-octave slopes),a third-order Butterworth (18-dB-

per-octave slopes), or a fourth-order Butterworth (24-dB-per-

octave slopes) response characteristic.

For flattest response in the crossover region when a second-

order of fourth-order crossover is used, the polarity between

the woofer and hight-frequency sections should be the same,

i.e., the positive output terminal of the low-frequency amplifier

should go to the positive woofer input on the SP4730N

(SP153H, SP4733N,SP253N) and the positive output terminal of

the high-frequency amplifier should go to the positive

high-frequency input on the SP4730N,SP4730H.

(SP153H, SP4733N,SP253N).

This instruction assumes of course, that there is no polarity

shift between the high-and low-frequency amplifier channels.

When a third-order crossover is use, the polarity

between the woofer and high-frequency section should

be reversed.

The pin arrangements are:

Full Range: Bi-Amp:

1 - = IN (-) 1 - = LF (-)

1 + = IN (+) 1 + = LF (+)

2 - = Not used 2 - = HF (-)

2 + = Not used 2 + = HF (+)

Dear STK Speaker System Customer,

Your newSTK speaker system has been upgraded to include our latest design improvements. So that you can fully understand

the newfeatures of your STK speaker system, the upgraded is described below. If you have any questions regarding your STK

speaker or its operation, please contact your STK Dealer or STK Authorized Service Center. We wish you all the best in the use of

your outstanding STK speaker system.

The high frequency horn or tweeter driver on your STK speaker is protected by a specially designed circuit using a Fuse Lamp. In

the event of a sudden loss of high frequency performance, it is likely that your horn of tweeter driver is OK and Fuse Lamp has failed.

The Fuse Lamp should be replaced by a qualified technician using a replacement lamp of the same type and rating.

SPECIFICATION

model

SP112

SP112M

SP122

SP122H

SP152H

S Y ST E M T YP E

2-way

Speaker System

2-w ay M o nito r

Speaker System

2-way

Speaker System

2-way

Speaker System

2-way

Speaker System

POWER

Continuous

Program

150 W

300 W

150 W

300 W

200 W

400 W

800 W

300 W

600 W

IMPEDANCE

(nominal)

8 ohm

S E NS I T IV IT Y

( SP L 1 W /1 m)

100 dB

101 dB

105 dB

101 dB

FREQUENCY

RANGE

(-3dB)

70 - 18000 Hz

63 - 18000 Hz

61 - 19000 Hz

55 - 19000 Hz

C RO SSOV E R

FREQUENCY

3.3㎑

3.0㎑

2.5㎑

TRANSDUCERS:

SK 2 0 ST N

SK 3 0 ST N

SK60D

SK-60D

N/A

300mm(12")

SK12150

300mm(12")

SK12150

300mm(12")

SK12200

380mm(15")

SK1 2400

380mm(15")

SK15300

CONNECTIONS

2 speaker jack

(in parallel)

2 speaker jack

(in parallel)

2 speaker jack

(in parallel)

2 speaker jack

(in parallel)

2 speakon jack

(in parallel)

DIMENSIONS

(WXHXD)

400x564x330mm

420x564x397mm

480x632x350mm

414x654x440mm

480x704x480mm

NET WEIGHT

16.54㎏

17.76㎏

21.9㎏

28.7Kg

29.3Kg

Model

SP-253N

SP-4733N

SP-118S

SP-218S

SP-215S

S Y ST E M T YP E

2-way

Speaker System

2-way

Speaker System

Subwoofer

Speaker System

Subwoofer

Speaker System

Subwoofer

Speaker System

POWER

Continuous

Program

800 W

1600 W

1200 W

2400 W

800 W

1600 W

3200 W

1200W

2400W

IMPEDANCE

(nominal)

4 ohm

8 ohm

4 ohm

S E NS I T IV IT Y

( SP L 1 W /1 m)

101 dB

103 dB

95 dB

98 dB

101 dB

FREQUENCY

RANGE

(-3dB)

50 - 19000 Hz

50 - 18000 Hz

31 - 200 Hz

30 - 200 Hz

47 - 350 Hz

C RO SSOV E R

FREQUENCY

1.5㎑

TRANSDUCERS:

SM110MD

2.5" voice coil

SK120MDN

3" voice coil

N/A

380mm(15")

SK1 5500-8X2

380mm(15")

SK15600X2

457mm(18")

SK18800

457mm(18")

2 x SK18800

380mm(15")

2 X SK15600

CONNECTIONS

2 speakon jack

(in parallel)

2 speakon jack

(in parallel)

2 speakon jack

(in parallel)

2 speakon jack

(in parallel)

2 speakon jack

(in parallel)

Full & bi amp

terminal

Full & bi amp

termi nal

DIMENSIONS

(WXHXD)

560x1240x460mm

600x1240x480mm

604x592x754mm

604x1165x754mm

912 x 476 x 5 95mm

NET WEIGHT

60.0㎏

66.70㎏

43㎏

80㎏

45kg

Model

SP152L

SP153H

SP4730N

SP4730H

SP-115M

S Y ST E M T YP E

2-way

Speaker System

3-way

Speaker System

3-way

Speaker System

3-way

Speaker System

2-way

speaker system

POWER

Continuous

Program

200 W

400 W

300 W

600 W

400 W

800 W

400 W

800 W

250W

500W

IMPEDANCE

(nominal)

8 ohm

4 ohm

8 ohm

S E NS I T IV IT Y

( SP L 1 W /1 m)

101 dB

103 dB

101 dB

FREQUENCY

RANGE

(-3dB)

60 - 18000 Hz

53 - 19000 Hz

53 - 18000 Hz

55 - 18000 Hz

C RO SSOV E R

FREQUENCY

2.5㎑

500㎐, 3.5㎑

2.5㎑

TRANSDUCERS:

SK 3 0 ST N

SK-60D

SK 3 0 ST N

N/A

205mm(8")

SK8200

205mm(8")

SK8200

205mm(8")

SK8200

N/A

380mm(15")

SK15300

380mm(15")

SK15300

380mm(15")

SK15500-4

380mm(15")

SK15500-8

380mm(15")

SK15300

CONNECTIONS

2 speaker jack

(in parallel)

2 speakon jack

(in parallel)

2 speakon jack

(in parallel)

2 speakon jack

(in parallel)

2 speakon jack

(in parallel)

480x704x397mm

Full & biamp

ter minal

Full & biamp

termi nal

Full & biamp

termi nal

DIMENSIONS

(WXHXD)

480x704x397mm

600x754x480mm

600x832x480mm

460x669x424mm

NET WEIGHT

25Kg

35.0㎏

40㎏

41㎏

26kg

SPECIFICATION

model

SP-115S

SP-118SL

SPM-122

SPM-152H

SPM-155H

S Y ST E M T YP E

SUB WOOFER

Speaker System

SUB WOOFER

Speaker System

2-way

Speaker System

2-way

Speaker System

2-way

Speaker System

POWER

Continuous

Program

400 W

800 W

600 W

1200 W

200 W

400 W

300 W

600 W

500 W

1000 W

IMPEDANCE

(nominal)

4 ohm

8 ohm

S E NS I T IV IT Y

( SP L 1 W /1 m)

99 dB

100 dB

98 dB

FREQUENCY

RANGE

(-10dB)

53 - 350Hz

30 - 200Hz

55 - 19000 Hz

54 - 19000 Hz

C RO SSOV E R

FREQUENCY

N/A

2.5㎑

TRANSDUCERS:

N/A

SK-40

SK-70

N/A

380mm(15")

SK15500

457mm(18")

SK18600S

300mm(12")

SK12200

380mm(15")

SK15300

380mm(15")

SK1 5500-8

CONNECTIONS

1 speakon jack

(in parallel)

2 speakon jack

(in parallel)

2 speakon jack

(in parallel)

2 speakon jack

(in parallel)

2 speakon jack

(in parallel)

DIMENSIONS

(WXHXD)

476x540x595mm

568x640x595mm

426x598x326mm

452x700x348mm

NET WEIGHT

29㎏

41.5㎏

26.76㎏

20.44㎏

The all speaker systems generates magnetic field.

Do not place them closer than two or three

Feet(60-100cm) from TV or computer monitors.

Check the screen for any magnetic audio or

Video tapes or computer discs near the

active systems.

Owner's Manual For The STK Speaker Systems

PrintedInKorea STK-Professional Audio 11/07

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Oradores de STK Professional Audio

STK Professional Audio

STK Professional Audio GD Series Manual de usuario

Manuales populares de Oradores de otras marcas

argon audio

argon audio IE20 Manual de usuario

Denon

Denon SC-N7 Manual de usuario

Gemline

Gemline Ace 3952 Manual de usuario

Focal

Focal ON WALL 300 Manual de instrucciones

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manual de usuario

SoundLogic

SoundLogic BCCS-6/6395 Manual de usuario

Peavey

Peavey DTH 218 Manual de usuario

Avantree

Avantree Pluto Air Manual de usuario

Morel

Morel Integra Series INTEGRA OVATION 4 Manual de usuario

Oppo

Oppo SONICA Manual de usuario

Bose

Bose SoundLink Wireless Music System Manual de usuario

Rocksteady

Rocksteady Stadium Manual de usuario

Bowers & Wilkins

Bowers & Wilkins 4 Manual de usuario

Sonance

Sonance SONOS OUTDOOR Series Manual de usuario

Electro-Voice

Electro-Voice EVID FM4.2 Manual de usuario

Pioneer

Pioneer XW-HTD630 Manual de usuario

Onn

Onn BWA16AA002 Manual de usuario

HP GL313AA - USB Speakers PC Multimedia Manual de usuario
