Stiga PARK Royal Manual de usuario

February 21, 2003

Park Royal

13-6114-14

PARK

PARK ROYAL

• Two cylinders Honda GCV 530 V-Twin engine, 16 hp.

• Front mounted cutting deck gives better overview and easier

availability.

• Electric cutting height adjustment handled from the right side of

the driver’s seat.

• Cutting deck is easily raised into the cleaning position using the

patented quick-release coupling.

• Handles all Stiga Park cutting decks.

• All controls are ergonomically placed by the driver’s seat.

• Easy filling of petrol on the outside, with fuel gauge.

• Patented height adjustable steering wheel.

• Adjustable comfort seat with comfort spring system.

• Patented foot controlled deck lift.

• Cruise control for increased comfort.

• Hour meter to help you to remember to give service in right

time.

• Headlight is standard.

• All year round machine with many possibilities thanks to many

high quality accessories.

• Accessories are easily exchanged.

Park Royal (13-6114-14)

MOTOR

Brand Honda

Power 16 hp GCV 530 V-Twin

Cylinders 2 - cyl.

Battery 12 V / 18 Ah

FUEL

Type of fuel Petrol

Tank volume 12 l

Fuel gauge Yes

SPEED CONTROL

Type of transmission Hydrostatic Tuff Torque K46

Number of gears Speed gear 0 - 10 km/h + R

STEERING

Type of steering Genuine articulated steering

Adjustable steering wheel Yes

Articulated steering through chain/wire Yes

WHEELS

Type of wheels Stiga special lawn tyre tread, 16 inches

Bearings Plain

Tyre pressure Front 0,6 bar Rear 0,4 bar

Driving Rear wheel drive

Snow chains Accessory

CUTTING SYSTEM

Type of cutting system Front cutting deck

Cutting heights 30 - 85 mm in 14 steps

Cutting width From 92 - 121 cm

Cutting height adjustment Electric with 107 / 121 M El

CONTROLS

Cruise control Yes

Deck connection Quick coupling

Foot controlled deck lift Yes

Electric starter Yes

Head light Yes

Hour meter Yes

Gear lever Foot pedal

COLOUR & MATERIAL

Colour of chassis Yellow / Black

Material of chassis Steel

MEASURES & WEIGHT

Weight 198 kg without cutting deck

Gross weight 239 kg

Package size W*H*L 91 x 109 x 199 cm

Type of package Wood crate

Largest measures W*H*L 113/133 x 117 x 244/233 cm

SEAT

Type of seat Comfort seat

Seat adjustable horizontally Yes

OTHER FACTS

CE-mark Yes

Instructions for use 8211-0276-04

EAN bar code 731 332 130 170 5

Other Carries the Swan label (340 008). Meets the Carlifornia en-

vironmental laws (CARB).
