Stiga GARDEN COMPACT E Manual de usuario

January 15, 2004

Garden Compact E Stiga

13-2502-17

GARDEN

GARDEN COMPACT E

A small and flexible ride-on lawnmower with Collection and Multi-

clip.

The ride-on lawnmower is excellent when an effective collection

is important. The flexible ride-on mower can also be driven in

Multiclip mode (accessory). Then you don´t have to rake or empty

grass. Mowing is quieter and you fertilise the grass at the same

time.

The ride-on lawnmower is comfortable to operate with just one

pedal for clutch and brake and an electric started engine. The seat

is adjustable. The collector (140 litres) is very handy. Emptying is

performed easily from the driving seat.

Equipped with an environment friendly 6,5 hp engine.Cutting

width is 63 cm.

Garden Compact E (13-2502-17)

MOTOR

Brand Briggs & Stratton

Power 6,5 hp Intek Pro 65 OHV

Speed 2 - 7 km/h

12 V / 7,2 Ah

FUEL

Type of fuel Petrol

Tank volume 3,0 l

SPEED CONTROL

Type of transmission Gear and differential

Number of gears 3 + R

STEERING

Type of steering Front wheel steering

WHEELS

Wheel size Front 11 x 4,00-4. Rear 13 x 5,00-6

Driving Rear

CUTTING SYSTEM

Type of cutting system Collecting / Multiclip

Cutting heights 30 - 70 mm in 5 steps

Cutting width 63 cm

CONTROLS

Electric starter Yes

COLOUR & MATERIAL

Colour Yellow

Material of chassis Steel

MEASURES & WEIGHT

Weight 111 kg

Gross weight 126 kg

Package size W*H*L 135*78*78 cm

Largest measures W*H*L 170*73*103 cm

SEAT

Seat adjustable horizontally Yes

OTHER FACTS

CE-mark Yes

Instructions for use 1136-0782-02

EAN bar code 731 332 130 168 2

Other features Multiclip function kit as accessory.
