Steren COM-567 Manual de usuario
IMPORTANT
Before using the Wireless optical mouse, please read next
recomendations
Clean only with a soft, dry cloth.
Do not try to open the equipment, may cause malfunction and warranty
repeal.
Do not use or store the equipment near wet places.
Check the batteries regularly.
When the equipment is not to be used for a long time, remove the
batteries.
FEATURES
RF wireless system (27MHz)
800DPI resolution
Plug & Play
OS supports: Windows 98, Windows ME, Windows 2000, Windows XP
and Windows Vista
•
•
•
•
•
•
•
•
•
ENGLISH
ENGLISH-02
CONTROLS
1. Right button
2. Left button
3. Scroll wheel
4. Optical sensor
6. Receiver compartment
7. Battery compartment
8. USB connector
ENGLISH-03
ENGLISH
1
2
3
4
567
BATTERY INSTALLATION
1.- Remove the battery compartment cover.
2.- Install two batteries type AAA into the compartment, paying attention to the
right polarity.
3.- Replace the battery compartment cover.
ENGLISH-04
ENGLISH
ENGLISH-05
ENGLISH
CONNECTING THE RECEIVER
1.- Turn the computer on.
2.- Take the receiver out from the compartment and plug it into an available
USB port.
3.- The computer detects the new device. Windows XP automatically will
install the required drivers. On other systems may run the Found New
Hardware Device assistant, follow the instructions. The required drivers are
already on Windows OS.
4.- Now you can use the mouse, normally.
6.- To set the mouse options, click on Control Panel / Mouse to
customize your mouse settings.
Menu. Maximum effective range: 5ft
If you want to use the mouse in other computer, unplug the receiver from
the USB port and keep it into the receiver compartment.
After 5 minutes in sleep mode turns off the mouse, to activate it again
just click the left button
ENGLISH-06
ENGLISH
SPECIFICATIONS
Input: 3V - - - (2 x AAA)
Dimensions: 3,9 x 2,5 x 1,4in
Weight: 70,8g
Carrier frequency: 27MHz
Power transmission: 0,5mW
Code´s number : 256
Operating temperature: 0-40°C
Relative Humidity: 5-80% (No condensed)
Product design and specications are subject to change, without notice.
WARRANTY
This Steren product is warranted under normal usage against defects in workmanship and materials to
the original purchaser for one year from the date of purchase.
CONDITIONS
1.- This warranty card with all the required information, invoice or purchase ticket, product box or
package, and product, must be presented when warranty service is required.
2.- If the product stills on the warranty time, the company will repair it free of charge.
3.- The repairing time will not exceed 30 natural days, from the day the claim was received.
4.- Steren sell parts, components, consumables and accessories to customer, as well as
warranty service, at any of the addresses mentioned later.
THIS WARRANTY IS VOID IN THE NEXT CASES:
If the product has been damaged by an accident, acts of God, mishandling, leaky batteries, failure to
follow enclosed instructions, improper repair by unauthorized personnel, improper safe keeping, among
others.
a) The consumer can also claim the warranty service in the purchase establishment.
b) If you lose the warranty card, we can reissue it, if you show the invoice or purchase ticket.
RETAILER INFORMATION
Name of the retailer Part number Brand
Address Serial number
Product Date of delivery
In case your product fails or have questions, please contact your nearest dealer. If you are in
Mexico, please give a call to our Call Center. 01 800 500 9000
Product: Wireless optical mouse
Part number: COM-567
Brand: Steren
IMPORTANTE
Antes de utilizar su nuevo Mouse óptico inalámbrico, lea las siguientes
recomendaciones
Siempre utilice un paño suave, limpio y seco para limpiar el equipo.
No intente abrir el equipo, puede ocasionar malfuncionamiento y
se anulará la garantía.
Revise las baterías periódicamente.
Cuando no vaya a utilizar el equipo por un período de tiempo prolongado
retire las baterías.
CARACTERISTICAS
Sistema inalámbrico de Radio Frecuencia (27MHz)
Resolución de 800DPI
Plug & Play
Soporta Windows 98, Windows ME, Windows 2000, Windows XP,
Windows Vista
•
•
•
•
•
•
•
•
Antes de utilizar su nuevo Kit Convertidor Analógico/Digita Ant
ESPAÑOL
ESPAÑOL-02
CONTROLES
1. Botón derecho
2. Botón izquierdo
3. Rueda de movimiento
4. Sensor óptico
6. Compartimiento de receptor
7. Compartimiento de baterías
8. Conector USB
ESPAÑOL-03
ESPAÑOL
1
2
3
4
567
