[1.0] Monitor Technical specifications
[1.1] General description
ST-HB32A1X is a 32” TFT Liquid Display with 16-CCFL Backlight unit and 1-ch LVDS interface.
This display supports 1366x 768 WXGA format and can display true 16.7M colours (8-bit/color).
The inverter module for backlight is built-in.
NOTE: the monitor is not equipped with speakers and RF module for Radio Frequency TV reception.
[1.2] Features
- High brightness (500 nits)
- High contrast ratio (1200:1)
- Fast response time ( Gray to Gray average 6.5 ms)
- High colour saturation NTSC 75%
- Max resolution 1360 x 768@60 Hz
- LVDS interface
- Low colour shift function option
- Ultra wide viewing angle :176(H)/ 176(V) Super MVA technology
-Support PIP/PAP function
- Configurable ambient light sensor
- VGA/DVI input support Video sync – 720p
- OSD menu controls by Remote controller, OSD button& RS232C controller
[1.3] General Specifications
Active Area 708.954mm(H) x 398.592mm(V) (32.02”diagonal)
Bezel Opening Area 714.96mm(H) x 404.6mm(V)
Driver Element a-si TFT active matrix
Pixel Number 1366 x R.G.B x 768 pixel
Pixel Pitch(sub-Pixel) 0.1730(H) x 0.5190(V)
Pixel Arrangement RGB vertical stripe
Display Colours 16.7M Color
Display operation Mode Transmissive mode / Normally black -
Surface Treatment Anti-Glare coating(Haze 25%), Hard coating (3H)
[1.4] Electrical Specifications [a]
Power source Power Input 100VAC~240VAC (Worldwide)
Operation Mode 250W (Max) Power
consumption Power Saving Mode 20W(Max) W
Storage Temper. Min -20 ~ Max60 Celsius
Operating Temper. Min 5 ~ Max 40 Celsius
