StarTech.com ATXPW500PRO2 Manual de usuario
Manual Revision: 04/19/2012
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
ATXPW500PRO2
ATXPW550PRO2
500/550 Watt Professional 20/24-pin ATX
2.01 Computer Power Supply
*actual product may vary from photos
Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.
Instruction Manual
i
Table of Contents
Introduction ............................................................................................1
Packaging Contents ................................................................................................................................. 1
System Requirements .............................................................................................................................. 1
Installation ..............................................................................................2
Hardware Installation .............................................................................................................................. 2
Specications ..........................................................................................4
Connectors .................................................................................................................................................. 5
Technical Support ..................................................................................6
Warranty Information ............................................................................6
Instruction Manual
1
Introduction
The ATXPW500PRO2 500 Watt EPS12V/ATX12V power supply delivers a professional-grade
PC power solution, with support for recent Intel® and AMD® dual-core CPU designs.
Featuring a comprehensive range of device connections, including SATA and dual PCI
Express connectors for systems with high-end video cards, the PSU is compliant with
ATX12V 2.01 & EPS12V 2.92 revision standards and oers dual 12V power rails and a 20/24
pin motherboard connection to ensure broad compatibility and simple installation.
To maintain stable power delivery to the most demanding devices, the power supply
features Quad+1 protection against short-circuit, over-power, over-voltage and
no-load situations, as well as an 80mm dual ball bearing fan to help keep the power
supply cool for peak performance.
Packaging Contents
• 1 x Power Supply
• 1 x Power Cord
• 1 x Instruction Manual
System Requirements
• ATX compliant motherboard
• ATX compliant computer case that supports full sized power supplies
Instruction Manual
2
Installation
WARNING! Computer parts can be severely damaged by static electricity. Be sure that you
are properly grounded before opening your computer case. StarTech.com recommends
that you wear an anti-static strap when installing any computer component. If an anti-
static strap is unavailable, discharge yourself of any static electricity build-up by touching
a large grounded metal surface (such as the computer case) for several seconds.
Installation of a power supply requires some mechanical skill and requires that you open
your computer case to disconnect and reconnect wires. If you are unfamiliar with this
kind of work, consider bringing your computer and new StarTech.com power supply to
your local computer store for help.
Hardware Installation
1. Turn your computer o and any peripherals connected to the computer (i.e.
printers, external hard drives, etc.).
2. If the power supply has a power switch on it, set it to the “0” position. Unplug the
power cable from the rear of the power supply on the back of the computer and
disconnect all other peripheral cables.
3. Remove the cover from the computer case. Refer to documentation for your
computer system for details.
4.
Disconnect all of the power connectors from the motherboard and peripheral devices (i.e.
hard drives, CD/DVD drives, etc). Make sure to take note of each connector and where they
were plugged in. Ensure there are no devices connected to the existing power supply.
5. Remove the existing power supply from the computer case. This is typically done by
removing four (4) mounting screws on the outside face of the power supply. Refer to
documentation for your computer system/case for specics.
6. Install and mount the new power supply by reversing the steps used to remove the
old power supply.
7.
Connect the power connectors from the power supply to the motherboard and peripheral
devices that were disconnected previously. Note that this power supply uses a 20+4
pin ATX connector, so it can be used on motherboards with either a 20-pin or 24-pin
connector. Simply detach the extra 4-pin attachment for use on 20-pin motherboards.
Instruction Manual
3
NOTE: the detached 4-pin connector cannot be used in place of the 4-pin ATX12V (P4) connector.
8. Make sure any loose or unused cables from the power supply are away from fans
and other moving parts.
9. Place the cover back onto the computer case.
10. Make sure the power switch on the power supply is set to “0”, then insert the power
cable into the socket on the power supply. If the old power cable looks worn or
damaged in any way, replace with the supplied power cable, otherwise it is safe to reuse it.
11. Reconnect all other connectors/cables that were removed in Step 2. Set the power
switch on the power supply to “1”.
Instruction Manual
4
Specications
ATXPW500PRO2 ATXPW550PRO2
Standards ATX12V 2.01
EPS12v 2.92
Maximum Power Output 500W 550W
Eciency Rating 72% (typical load)
Fans 1 x 80mm 1 x 120mm
Input Power
100 ~ 120VAC, 10A
200 ~ 240VAC,5.5A
47 ~ 63Hz
100 ~ 120VAC, 12A
200 ~ 240VAC, 6A
47 ~ 63Hz
MTBF 100, 000
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20°C ~ 80°C (-4°F ~ 176°F)
Humidity 10 ~ 90% RH
Dimensions (LxWxH) 140.0mm x 150.0mm x 86.0mm
Weight 1800g 1830g
ATXPW500PRO2 Power Output
DC
Output
+3.3V +5V +12V1 +12V2 -12V +5Vsb
30A 45A 18A 16A 1A 2.5A
Max
Power
275W 380W 12W 12.5W
475.5W
Instruction Manual
5
ATXPW550PRO2 Power Output
DC
Output
+3.3V +5V +12V1 +12V2 -12V +5Vsb
30A 50A 18A 18A 1A 2.5A
Max
Power
300W 420W 12W 12.5W
525.5W
Connectors
1 x ATX 20+4 pin 1 x 4+4 pin ATX12V
(8-pin EPS12V)
2 x 6-pin PCI Express 5 x 15-pin SATA (ATXPW500PRO2)
7 x 15-pin SATA (ATXPW550PRO2)
5 x 4-pin Molex Power (LP4) 2 x 4-pin Mini-Power (SP4)
1 x 3-pin Fan (TX3)
Instruction Manual
6
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a three year warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.
StarTech.com is your one-stop source for every connectivity part you need. From
the latest technology to legacy products — and all the parts that bridge the old and
new — we can help you nd the parts that connect your solutions.
We make it easy to locate the parts, and we quickly deliver them wherever they need
to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to
the products you need in no time.
Visit www.startech.com for complete information on all StarTech.com products and
to access exclusive resources and time-saving tools.
StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology
parts. StarTech.com was founded in 1985 and has operations in the United States,
Canada, the United Kingdom and Taiwan servicing a worldwide market.
