PCI Express USB 3.0 Adapter

Card

1-Port Internal, 1-Port External

PCI Express to SuperSpeed

USB 3.0 Adapter Card

PEXUSB3S11

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the•

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes

only and do not represent an endorsement of a product or service by StarTech.

com, or an endorsement of the product(s) to which this manual applies by the

third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges

that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Table of Contents

Introduction.............................................................................................. 1

Packaging Contents.................................................................................................. 1

System Requirements .............................................................................................. 1

Installation................................................................................................ 1

Hardware Installation................................................................................................ 1

Driver Installation...................................................................................................... 1

Speciﬁcations........................................................................................... 2

Technical Support.................................................................................... 3

Warranty Information............................................................................... 3

Introduction

This StarTech.com SuperSpeed USB 3.0 adapter card enables you to access your data

and transfer ﬁles much faster than USB 2.0! The new USB 3.0 standard supports transfer

rates of up to 5Gbps, while still providing connectivity and support for the older USB 2.0

(480Mbps) and 1.1 (12Mbps) devices. In addition to providing a much faster transfer rate

the PEXUSB3S2 USB 3.0 card also supplies 900mA of power per USB port, allowing for

more external devices to operate without the need of an external power source.

Packaging Contents

1 x PEXUSB3S11 adapter card•

1 x Low Proﬁle bracket•

1 x Driver Installation CD•

1 x Instruction Manual•

System Requirements

PCI Express enabled computer system with available slot•

Microsoft• ®Windows®XP/Server 2003/Vista/Server 2008 R2/7 (32/64-bit)

USB 3.0 type A

connector

USB 3.0 type A

connector

SATA Power

connector

Installation

WARNING! PCI Express cards, like all computer equipment, can be severely damaged

by static electricity. Be sure that you are properly grounded before opening your

computer case or touching your PCI Express card. StarTech.com recommends that you

wear an anti-static strap when installing any computer component. If an anti-static strap

is unavailable, discharge yourself of any static electricity build-up by touching a large

grounded metal surface (such as the computer case) for several seconds. Also be careful

to handle the PCI Express card by its edges and not the gold connectors.

Hardware Installation

Turn your computer off and any peripherals connected to the computer (i.e. Printers,1.

external hard drives, etc.). Unplug the power cable from the rear of the power supply

on the back of the computer and disconnect all peripheral devices.

Remove the cover from the computer case. See documentation for your computer2.

system for details.

Locate an open PCI Express slot and remove the metal cover plate on the rear of the3.

computer case (Refer to documentation for your computer system for details.). Note

that this card will work in PCI Express slots of additional lanes (i.e. x4, x8 or x16 slots).

Insert the card into the open PCI Express slot and fasten the bracket to the rear of the4.

case.

Connect a SATA power connector from the computer’s power supply to the 15-pin5.

SATA power connector on the card.

Place the cover back onto the computer case.6.

Insert the power cable into the socket on the power supply and reconnect all other7.

connectors removed in Step 1.

Driver Installation

Once the computer has started and the operating system is fully loaded, insert the

provided Driver CD into the computer’s CD/DVD drive.

Autorun should start the installation program, so follow the instructions onscreen to

complete the driver installation.

If Autorun does not start, Go into “My Computer” and access the CD/DVD drive that the

CD is in, and run the “setup.exe” ﬁle located on the CD. Follow the onscreen instructions

to complete the driver installation.

Verifying Installation

Windows XP/Server 2003/Vista/7

From the main desktop, right-click on “My Computer” (“Computer” in Vista/7), then select

Manage. In the new Computer Management window, select Device Manager from the left

window panel.

In the Device Manager, under the Universal Serial Bus Controllers category, you should

see the new entries for the USB controller card.

Specications

Bus Interface PCI Express 2.0

(x1 slot connector)

Chipset ID NEC uPD720200

Connectors

1 x USB 3.0 type A (internal)

1 x USB 3.0 type A (external)

1 x 15-pin SATA Power

Form Factor Full/Low Proﬁle

Support Standards USB 3.0 revision 1.0

Maximum Data Transfer Rate USB 3.0: 5Gbps

Operating Temperature 0°C ~ 50°C (32°F ~ 122°F)

Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)

Humidity 0 ~ 85% RH

Dimensions 121.0mm x 76.0mm x 19.0mm

Weight 40g

Compatible Operating Systems Windows XP/Server 2003/Vista/Server

2008 R2/7 (32/64-bit)

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit www.startech.

com/support and access our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in materials and

workmanship for the periods noted, following the initial date of purchase. During this

period, the products may be returned for repair, or replacement with equivalent products

at our discretion. The warranty covers parts and labor costs only. StarTech.com does not

warrant its products from defects or damages arising from misuse, abuse, alteration, or

normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ofﬁcers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of proﬁts, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the actual

price paid for the product. Some states do not allow the exclusion or limitation of incidental

or consequential damages. If such laws apply, the limitations or exclusions contained in

this statement may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy”

since 1985, providing high quality solutions to a diverse

IT and A/V customer base that spans many channels,

including government, education and industrial facilities

to name just a few. We offer an unmatched selection of

computer parts, cables, A/V products, KVM and Server

Management solutions, serving a worldwide market

through our locations in the United States, Canada, the

United Kingdom and Taiwan.

Visit www.startech.com today for complete information

about all our products and to access exclusive interactive

tools such as the Cable Finder, Parts Finder and the

KVM Reference Guide.
