StarTech.com PCI220USB Manual de usuario

PCI USB 2.0 Adapter Card

2/4-Port PCI High Speed

USB 2.0 Adapter Card

PCI220USB

PCI420USB

PCI220USBLP

Instruction Manual

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction..................................................................... 1

Packaging Contents.....................................................................1

System Requirements .................................................................1

Installation....................................................................... 2

Hardware Installation...................................................................2

Driver Installation.........................................................................2

Speciﬁcations.................................................................. 3

Technical Support........................................................... 4

Warranty Information...................................................... 4

Introduction

Thank you for purchasing a StarTech.com USB 2.0 PCI card. This PCI

expansion card will enable you to add high speed USB 2.0 ports to

your computer, and provide data transfer speeds up to 480 Mbps. Now,

you can easily connect and use high-performance USB peripherals like

DVD drives, video conferencing cameras, or high resolution scanners.

Plus, USB 2.0 is also backwards-compatible with USB 1.0/1.1,

meaning your existing peripherals will still function perfectly with no

additional conﬁguration required.

Packaging Contents

1 x PCI USB 2.0 Adapter Card•

1 x Instruction Manual•

System Requirements

PCI enabled computer system with available PCI slot•

Low Proﬁle PCI slot for PCI220USBLP•

Microsoft• ®Windows®98SE/ME/2000/XP/Server 2003/Vista/7,

or Apple® Mac OS®X, or Linux

*PCI420USB shown

Installation

WARNING! PCI cards, like all computer equipment, can be severely

damaged by static electricity. Be sure that you are properly grounded

before opening your computer case or touching your PCI card.

StarTech.com recommends that you wear an anti-static strap when

installing any computer component. If an anti-static strap is unavailable,

discharge yourself of any static electricity build-up by touching a large

grounded metal surface (such as the computer case) for several

seconds. Also be careful to handle the PCI card by its edges and not

the gold connectors.

Hardware Installation

Turn your computer off and any peripherals connected to the1.

computer (ie. Printers, external hard drives, etc.). Unplug the power

cable from the rear of the power supply on the back of the computer.

Remove the cover from the computer case. Refer to documentation2.

for your computer system.

Locate an open PCI or PCI-X slot and remove the metal cover plate3.

on the rear of the computer case.

Insert the card into the open PCI or PCI-X slot and fasten the4.

bracket to the rear of the case. Refer to documentation for your

computer system.

Place the cover back onto the computer.5.

Insert the power cable into the socket on the power supply and6.

reconnect all previously disconnected peripherals.

Driver Installation

Windows 2000/XP/Server 2003/Vista/7

No driver installation is required for these operating systems, as this

USB 2.0 adapter card is natively supported, so the drivers are already

installed.

Specications

PCI220USB

PCI220USBLP PCI420USB

Bus Interface PCI rev 2.2 (3.3/5V)

OHCI/EHCI

External Connectors 2 x USB type A 4 x USB type A

Internal Connectors 1 x USB type A

Chipset ID VIA VT6212 VIA VT6212

Maximum Data

Transfer Rate 480 Mbps

Compatible

Operating Systems

Windows 98SE/ME/2000/XP/Server 2003/

Vista/7, Mac OS X, Linux

Technical Support

StarTech.com’s lifetime technical support is an integral part of our

commitment to provide industry-leading solutions. If you ever need

help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does

not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government, education

and industrial facilities to name just a few. We offer an unmatched

selection of computer parts, cables, A/V products, KVM and Server

Management solutions, serving a worldwide market through our

locations in the United States, Canada, the United Kingdom and

Taiwan.

Visit www.startech.com today for complete information about all

our products and to access exclusive interactive tools such as the

Cable Finder, Parts Finder and the KVM Reference Guide.
