StarTech.com ECUSB3S2 Manual de usuario

Manual Revision: 11/28/2012

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

ECUSB3S2

2 Port ExpressCard SuperSpeed USB 3.0 Adapter

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction ............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements .............................................................................................................................. 1

Installation ..............................................................................................2

Hardware Installation .............................................................................................................................. 2

Driver Installation ...................................................................................................................................... 2

Verifying Installation ................................................................................................................................ 3

Specications ..........................................................................................4

Technical Support ..................................................................................5

Warranty Information ............................................................................5

Instruction Manual

Introduction

10x faster than that of USB 2.0, this SuperSpeed USB 3.0 adapter card enables you to

access your data and transfer les much faster than USB 2.0! The new USB 3.0 standard

supports transfer rates of up to 5Gbps, while still providing connectivity and support

for the older USB 2.0 (480Mbps) and 1.1 (12Mbps) devices.

Packaging Contents

• 1 x USB 3.0 ExpressCard Adapter

• 1 x Driver CD

• 1 x Instruction Manual

System Requirements

• ExpressCard/34 or /54 enabled computer system

• Microsoft® Windows® 2000/ XP/ Server 2003/ Vista/ 7 (32/64-bit) / 8 (32/64-bit)

USB 3.0 type

A ports

DC power connector

(on opposite side)

Instruction Manual

Installation

Hardware Installation

1. ExpressCard adapters can be hot-plugged into a computer system, while running.

Turning the computer o to insert/remove ExpressCard adapters is not necessary.

2. Locate your computer’s ExpressCard slot. This card can t into an ExpressCard/34 or

ExpressCard/54 slot.

3. Slide the adapter card into the ExpressCard slot fully and you should hear the card

engage with a clicking noise.

NOTE: Some ExpressCard/54 slots hold an ExpressCard/34 adapter loosely, so

movement of the computer or the adapter card can result in accidental disconnection.

An ExpressCard/34 to /54 bracket is recommended for those types of computers

(i.e. StarTech.com ID: ECBRACKET).

4. The card should now be detected by the computer systems operating system.

5. To remove the card, press the card into the ExpressCard slot all the way and

you should hear it disengage with a clicking sound. The card should now be

automatically ejected from the slot.

OPTIONAL: If the ExpressCard slot on the computer does not provide enough power

to the USB ports, an external power adapter would be required and plugged into the

DC power connector.

Driver Installation

Windows XP/Server 2003/Vista/7

1. Once the computer has started and the operating system is fully loaded, insert the

provided Driver CD into the computer’s CD/DVD drive.

2. AutoPlay should give you the option to browse the les on the CD or automatically

open the CD.

Instruction Manual

If Autorun does not start, Go into “My Computer” and access the CD/DVD drive that

the CD is in.

3. Run the “setup.exe” le located in “ExpressCard USB 3.0 2Port Card (ECUSB3S2)”.

Follow the onscreen instructions to complete the driver installation.

Verifying Installation

Windows 2000/XP/Server 2003/Vista/7

From the main desktop, right-click on “My Computer” (“Computer” in Vista/7), then

select Manage. In the new Computer Management window, select Device Manager

from the left window panel.

In the Device Manager, under the Universal Serial Bus Controllers category, you should

see the new entries for the USB 3.0 controller card.

Instruction Manual

Specications

Bus Interface

ExpressCard (34mm form factor)

USB 3.0 rev1.0

Intel xHCI rev0.95

External Connectors 2 x USB 3.0 type A Female

1 x DC power connector

Chipset ID NEC uPD720200

Maximum Data Transfer Rate USB 3.0: 5Gbps

Operating Temperature 0°C ~ 50°C (32°F ~ 122°F)

Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)

Humidity 0% ~ 85% RH

Power Adapter (optional) 5VDC, 2A, type H plug,

center positive

Compatible Operating Systems Windows 2000/XP/Server 2003/Vista/

7 (32/64-bit) /8 (32/64-bit)

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
