SR160 SURFACE ROUGHNESS TESTER

USER MANUAL

4 PKG08761-UMSR160

TABLE OF CONTENTS

Components 5

Using the Instrument 12

Function Buttons 13

Device Icons 14

Menu 15

SR160 Overview 24

SR160 Accessories 27

SR160 Dimensions 29

Quick Start Guide 32

PKG08761-UMSR160 5

COMPONENTS

1. BLUETOOTH TECHNOLOGY - Quick, reliable communication between traverse and

display/control unit.

2. PROFILE GRAPH - Clear detailed graph showing measurement area - excellent for

visually identifying defects.

1 2 3

6 PKG08761-UMSR160

COMPONENTS

3. SIMPLE 3-BUTTON NAVIGATION - Instant access to menu option settings.

4. USB MINI CHARGING PORT - Charge from mains or any standard USB charging port.

5. RUBBERIZED MOLDING - Enhanced durability and improved grip provides unbeatable

protection in harsh shop floor environments.

6. LI-POLY BATTERY - Most advanced rechargeable battery technology for unrivalled

reliability and battery life.

PKG08761-UMSR160 7

COMPONENTS

7. DIAMOND STYLUS AND PIEZOELECTRIC PICK-UP - The hard wearing, robust

piezoelectric pick-up stylus with diamond tip assures very reliable measurement.

8. SEPARATES - The SR160 splits into a display/control unit and traverse unit via a

slide and lock mechanism.

9. MEASURE - Tactile measurement button great for challenging orientations.

8 PKG08761-UMSR160

COMPONENTS

FAST AND RELIABLE

Simply press the measurement button and in a few seconds a full set of

traceable measurement results including a detailed profile graph is displayed.

PKG08761-UMSR160 9

COMPONENTS

BUILT TO LAST, BY DESIGN

Impact resistant rubberized moldings surround a recessed, Mylar

protected high durability screen making the unit robust.

PKG08761-UMSR160 11

SR160 SURFACE ROUGHNESS TESTER

THIS IS A STARRETT USER GUIDE FOR THE SR160 SURFACE

ROUGHNESS TESTER.

ALL SPECIFICATIONS IN THIS DOCUMENT ARE CORRECT AT TIME

OF PRODUCTION AND ARE SUBJECT TO CHANGE. PLEASE CONTACT

STARRETT FOR FURTHER INFORMATION.

12 PKG08761-UMSR160

ENGLISH

USING THE INSTRUMENT

OVERVIEW

SR160 OPERATION MODE

SR160 STORAGE MODE

Status LED Traverse unit

power button

Display unit power/

Measure button

Color screen

3 Menu buttons

Pick up and stylus

USB Charging port

'Connected' mode

Slides apart

'Separated' mode

'Storage' mode
