Star EV SIRIUS Manual de usuario
PERSONAL TRANSPORTATION VEHICLE
Owner’s Manual
page 2page 3
Notes
page 2page 3
Foreword
Dear STAR EV® Product Owner,
STAR EV employees, dealers, and authorized technicians would like to
thank you for purchasing the STAR EV SIRIUS®. The Sirius is the first of
its kind in the market; conceived, designed and developed with you
in mind. The Sirius is a direct result of research, development, and
customer feedback that have all contributed to this innovative oering
from STAR EV. Unlike manufacturers of fleet golf cars have a volume
demand that strips vehicles down to the basics, the Sirius is purposely
designed with the personal transportation vehicle owner in mind. You
will notice ample storage options, class-leading technology, extremely
competitive performance, high quality materials and intelligent
problem solving for reliability, serviceability and distinct styling with
a purpose that sets the Sirius electric vehicle apart from others in
the neighborhood. Our design and development team consists of
individuals who have a passion for providing creative automotive
solutions and have a reputation for placing quality, performance, and
styling above all else and never, ever settle for “good enough”.
On behalf of the entire team at STAR EV, we thank you for your purchase
and look forward to establishing customer loyalty as we continue to
develop more exciting oerings in the future.
page 4page 5
Contents
Foreword 3
General Disclaimer 7, 8
I. Warnings and Safety 9
A. Disclaimer and Liability 10
B. Labels and Locations 10
1. Underside of roof 10
2. Seat pan above batteries 11
II. Quick Guide for Basic Operation 12
A. Positioning Side View Mirrors 12
B. Seating and Safety Belt Use 13
C. Starting and Key Switch 14
D. Direction Selection 15
1. Drive 15
2. Neutral 15
3. Reverse 16
E. Releasing the Parking Brake 17, 18
F. Speed Selector 19
G. Accelerator Pedal 20
H. Brake Pedal 21
J. Setting Parking Brake 22, 23
K. Powering the Unit O 24
III. Sirius Flip Seat 25
Sirius with Ultimate Flip Seat 25-26
IV. Sirius Specifications 27
A. Exterior Dimensions 27. 28
B. Weight & Distribution 29, 30
C. Capacities 31
D. Tires and Wheels 31
E. Suspension and Brakes 31
page 4page 5
Contents
V. Features Location and operation 32
A. LCD Digital Instrumentation 32, 33
1. Mode, Set and Reset Instructions 32, 33
B. EL Interior Ambient Lighting 34
C. Secure Glove Box 35
D. Electric Trunk Release 36
E. Back-Up Manual Storage Trunk Release 37
F. Secure Trunk Storage 38
G. False Floor Cooler Lid 39
H. Storage Cooler Drain 40
J. Headlights 41
1. Daytime Running Light Operation 42
2. Headlight Operation 43
3. Engaging High Beam 44
K. Taillights 45
L. Side View Mirror Turn Indicators 46, 47
M. Hazard or Emergency Flashers 48
N. Horn 49
P. Adjustable Seat Back 50
Q. Center Storage Pocket 51
R. Seat Pan Storage Pocket 52
S. Seat Belts 53
T. Flip Windshield 54, 55
U. USB and 12 V Outlet 56
V. EZ Connect Main Charging Port 57
W. Optional Golf Ball and Tee Holder 58
page 6page 7
Contents
VI. Maintenance 59
A. Preventative Maintenance Schedule 59
B. Batteries 60
1. Charging the Batteries 60, 61
2. Important Things to Remember 62
3. Battery Layout and Cable Routing 63, 64
4. Watering and Flooded Batteries 65, 66
C. Liing the Vehicle 67, 68
D. Alignment 69
E. Lubrication Points 70
F. Adjustable Ride Height 71-72
G. Tire Pressure 73
H. Light Bulb Replacement 73
1. Headlight Bulb Replacement 73, 74
J. Headlight Adjustment 75
VII. Care and Cleaning 76, 77
A. Interior 76
B. Exterior 76
VIII. Storage 78
A. Procedure 78
IX. Warranty 79-80
A. Clarifications 80
B. Exclusions 81
C. Remedy 81
D. Disclaimer 82
E. Warning 82
F. Voiding of Warranty 83
Troubleshooting 84
page 6page 7
General Disclaimer
General Disclaimer
Good common sense and prudent driving practices must be used at
all times to prevent accidents and injury and do more than warnings
and instructions combined. The manufacturer strongly suggests
that anyone who operates this equipment read the entire manual
paying particular attention to the safety warnings while operating and
maintaining this vehicle.
STAR EV reserves the right to make design changes to vehicles for
constant improvement without obligation to change previous models
produced and sold prior to updates and the information in this manual
is subject to change without notice to customers, dealers, or agents.
In order to remain completely up-to-date on production changes,
please contact your STAR EV Authorized Dealer or our web site:
www.starev.com for the most recent version of this manual and if
needed schedule an appointment to consider updating your product
if value is determined.
These vehicles are designed for “enclosed community” use and may
include private and public land. Every STAR EV Sirius is equipped
with proper lighting and safety equipment, but it is the owner’s
responsibility to ensure your vehicle conforms to local laws to be
driven on public secondary roads as each state and county has
dierent guidelines and laws.
Some communities may permit operation on public streets in specific
areas on a limited basis and in accordance with local ordinance.
It is the responsibility of the vehicle owner to follow local use laws.
Electrically powered vehicles require that all electrical accessories be
properly grounded directly to battery (-) post. Never use the chassis
or body as a grounded connection.
page 8page 9
General Disclaimer
Refrain from modifying the vehicle in any way that will alter the weight
distribution of the vehicle, decrease stability or increase speed beyond
factory specifications. Such modifications can cause serious injury,
property damage and even death. Only STAR EV Authorized Dealers
may modify the vehicle.
Vehicles that are capable of higher speeds must continue to conform
to surrounding traic and environment, conditions, and terrain.
Attention
Because the STAR EV Sirius can be upgraded to a legal “Low Speed
Vehicle” (LSV) in some states, the following is required to understand.
If you believe that your LSV has a defect which could cause a crash
or could cause injury or death, you should immediately inform the
National Highway Traic Safety Administration (NHTSA) in addition to
notifying JH Global Services, Inc.
If the NHTSA receives similar complaints, it may open an investigation,
and if it finds that a safety defect exists in a group of vehicles, it may
order a recall and remedy campaign. However, the NHTSA cannot
become involved in individual problems between you, your dealer, or
JH Global Services,Inc.
To contact the NHTSA, you may call the Vehicle Safety Hot
line toll-free at 1-888-327-4236 (TTY: 1-800-424-9153); go to
http://nhtsa.safercar.gov; or write to: Administrator, NHTSA, 1200
New Jersey Avenue SE, Washington, DC 20590. You can also
obtain other information about motor vehicle safety from
http://www.safercar.gov.
page 8page 9
Warning
Only Licensed STAR EV Technicians and Authorized Dealers may
perform any needed repairs to STAR EV products. Failure to do so may
result in voiding warranty, personal injury, or even death.
Maintain the battery as per the User Manual Guidelines. Failure to
follow the procedures listed in this manual may result in a decreased
duration of the batteries.
Unauthorized modifications to this vehicle may reduce performance
and safety capabilities which could result in equipment failure,
personal or property damage, or death.
Use the vehicle in a responsible manner and maintain the vehicle in
safe operating condition.
Read and observe all warnings and operation instruction labels
posted on vehicle and printed in this manual.
Follow all safety rules posted and adhere to all traic and road signs.
Ensure all passengers and cargo are secure before driving vehicle.
Follow seat belt laws where applicable. If children are on board, ensure
they are secure with adult supervision.
Use turn signals to communicate your direction of travel to other
motorists.
Do not leave unsupervised minors in vehicle.
When vehicle is in motion, it is strongly suggested that running lights
or headlights are on.
Warning
page 10 page 11
Warnings and Safety
I. Warnings and Safety
A. Disclaimer and Liability
This manual has been designed to assist in maintaining your new
STAR EV Sirius personal vehicle in accordance with procedures
developed by the manufacturer. Compliance to these procedures and
troubleshooting tips will ensure the best performance and reliability
of your vehicle.
B. Labels and Locations
1. Underside of roof
