STA-RITE MAX-E-PRO Manual de usuario

MAX-E-PROTM

CENTRIFUGAL PUMPS

WITH INTEGRAL TRAP

O W N E R’ S M A N U A L

INSTALLATION, OPERATION & PARTS

Series P6E and P6RA

See Page 2 for Model Numbers

Sta-Rite Pool/Spa Group

293 Wright Street, Delavan, WI 53115

International: 262-728-5551, FAX: 262-728-7550

www.starite.com

Union City, TN • Delavan, WI • Mississauga, Ont. • Murrieta, CA

This manual should be furnished to

the end user of this pump; its use will

reduce service calls and chance of

injury and will lengthen pump life.

‘P6RA’ and ‘P6E’ SERIES PUMP

WITH TRAP

To avoid unneeded service calls, prevent possible injuries, and get the most

out of your pump, READ THIS MANUAL CAREFULLY!

The Sta-Rite ‘P6RA’ and ‘P6E’ Series Self-priming Centrifugal pumps:

• Are designed for use with swimming pools or as centrifugal pumps.

• Are excellent performers; durable, reliable.

Table of Contents

Safety Instructions ........................................................................................3

Installation.................................................................................................4-6

Electrical....................................................................................................6-8

Operation ................................................................................................9-10

Storage/Winterizing ....................................................................................10

Pump Service.........................................................................................11-12

Troubleshooting Guide ...............................................................................13

Repair Parts List .....................................................................................14-15

Warranty.....................................................................................................16

Max-E-ProTM Pump Models

HP 2-Speed

1/2 P6E6C-204L

3/4 P6E6D-205L

1 P6E6E-206L P6RA6E-205L

1-1/2 P6E6F-207L P6RA6F-206L P6RA6YF-206L

2 P6E6G-208L P6RA6G-207L P6RA6YG-207L

3P6E6H-209L

READ AND FOLLOW SAFETY

INSTRUCTIONS!

This is the safety alert symbol. When you see this symbol on your system

or in this manual, look for one of the following signal words and be alert

to the potential for personal injury.

warns about hazards that will cause death, serious personal

injury, or major property damage if ignored.

warns about hazards that can cause death, serious personal

injury, or major property damage if ignored.

warns about hazards that will or can cause minor personal injury

or property damage if ignored.

NOTICE indicates special instructions not related to hazards.

Carefully read and follow all safety instructions in this manual and on equip-

ment. Keep safety labels in good condition; replace if missing or damaged.

Incorrectly installed or tested equipment may fail, causing

severe injury or property damage.

Read and follow instructions in owner's manual when installing

and operating equipment. Have a trained pool professional per-

form all pressure tests.

1. Do not connect system to a high pressure or city water system.

2. Use equipment only in a pool or spa installation.

3. Install pump with at least 2 hydraulically balanced main drains equipped

with correctly installed, screw-fastened, anti-entrapment certified covers.

See Page 5.

4. Trapped air in system can cause explosion. BE SURE all air is out of system

before operating or testing equipment.

Before pressure testing, make the following safety checks:

•Check all clamps, bolts, lids, and system accessories before testing.

•Release all air in system before testing.

•Water pressure for test must be less than 25 PSI (7.5 kg/cm2).

•Water Temperature for test must be less than 100oF. (38oC).

•Limit test to 24 hours. After test, visually check system to be sure it is ready

for operation. Remove trap lid and retighten hand tight only.

NOTICE: These parameters apply to Sta-Rite equipment only. For

non-Sta-Rite equipment, consult manufacturer.

INSTALLATION

Only qualified, licensed personnel should install pump and wiring.

Pump mount must:

Be located away from corrosive or flammable chemicals.

IMPORTANT

SAFETY

INSTRUCTIONS

Always follow basic safety pre-

cautions with this equipment, in-

cluding the following.

To reduce the risk of

injury, do not permit children to

use this product unless they are

closely supervised at all times.

This pump is for use

with permanently installed pools

and may also be used with hot

tubs and spas if so marked. Do

not use with storable pools. A

permanently installed pool is con-

structed in or on the ground or in

a building such that it cannot be

readily disassembled for storage.

A storable pool is constructed so

that it may be readily disassem-

bled for storage and reassembled

to its original integrity.

SAVE THESE

INSTRUCTIONS

Have enough ventilation to maintain air temperature at less than the maximum

ambient temperature rating (Max. Amb.) listed on the motor model plate. If this

pump is installed in an enclosure/pump house, the enclosure must have ade-

quate ventilation and air circulation to keep the temperature in the enclosure at

or below the motor’s rated ambient temperature whenever the pump is running.

Be solid - Level - Rigid - Vibration free - Non-combustible. (To reduce

vibration and pipe stress, bolt pump to mount.)

Allow pump suction inlet height to be as close to water level as possible.

Allow use of short, direct suction pipe (To reduce friction losses).

Allow for gate valves in suction and discharge piping.

Have adequate floor drainage to prevent flooding.

Be protected from excess moisture.

Allow adequate access for servicing pump and piping.

Fire and burn hazard. Modern motors run at high temperatures.

To reduce the risk of fire, do not allow leaves, debris, or foreign matter to col-

lect around the pump motor. To avoid burns when handling the motor, let it

cool for 20 minutes before trying to work on it.

NOTICE: Use Teflon tape or Plasto-Joint Stik1for making all threaded connec-

tions to the pump. Do not use pipe dope; pipe dope will cause stress cracking

in the pump.

NOTICE: Pump suction and discharge connections have molded in thread

stops. DO NOT try to screw pipe in beyond these stops.

Teflon Taping Instructions:

Use only new or clean PVC pipe fittings.

Wrap male pipe threads with one to two layers of Teflon tape. Cover entire

threaded portion of pipe.

Do not overtighten or tighten past thread stop in pump port!

If leaks occur, remove pipe, clean off old tape, rewrap with one to two addi-

tional layers of tape and remake the connection.

NOTICE: Support all piping connected with pump!

1Lake Chemical Co., Chicago, Illinois

Suction

Port

from

pool or

vacuum

filters

Strainer Basket

cover

Discharge Port

to filter

or pool

Clamp

Knob

Bonding Lug

Pump may be bolted to level

foundation or mounting bracket

4284 1102

Figure 1

NOTICE: Port threads

are: Internal - 2" NPT

for direct connection to

pipe. External - 3-1/4"

Buttress. Fits Sta-Rite

U11-200P Union Collar

for quick disconnect

pipe connection.

See Page 14 for Union

Kits.

Piping:

Use at least 2" IPS PVC (51mm) pipe. Increase size if a long run is needed.

To avoid strains on the pump, support both suction and discharge pipes inde-

pendently. Place these supports near the pump.

To avoid a strain left by a gap at the last connection, start all piping at the

pump and run pipe away from the pump.

Never use a suction pipe smaller than pump suction connection.

To avoid airlocking, slope suction pipe slightly upward toward the pump.

NOTICE: To prevent flooding when removing pump for service, all flooded

suction systems must have gate valves in suction and discharge pipes.

Fittings:

Fittings restrict flow; for best efficiency use fewest possible fittings.

Avoid fittings which could cause an air trap.

Pool fittings must conform to International Association of Plumbing and

Mechanical Officials (IAPMO) standards.

Use only non-entrapping suction fitting or double suction.

POOL PUMP SUCTION

REQUIREMENTS

Pump suction is hazardous and can trap and drown or disem-

bowel bathers. Do not use or operate swimming pools, spas, or hot tubs if a

suction outlet cover is missing, broken, or loose. Follow the guidelines below

for a pump installation which minimizes risk to users of pools, spas, and hot

tubs.

Entrapment Protection

The pump suction system must provide protection against the hazard of

suction entrapment or hair entrapment/entanglement.

Suction Outlet Covers

All suction outlet covers must be maintained. They must be replaced if

cracked, broken, or missing.

See below for outlet cover certification requirements.

All suction outlets must have correctly installed, screw-fastened covers in

place.

At Least

3 Feet

Suction Outlet

(Main Drain)

Suction Outlet

(Main Drain)

IAPMO Certified

Anti-entrapment

Cover or Suction Fitting,

screw-fastened to

Main Drain Sump

IAPMO Certified

Anti-entrapment

Cover or Suction Fitting,

screw-fastened to

Main Drain Sump

Pump

Valves OK between

pump and Tee

No valves between

Tee and Main Drains

2762 0197

Figure 2 – Recommended pump suction layout.

Hazardous voltage.

Can shock, burn,

or cause death.

Ground pump before

connecting to

power supply.

Testing and Certification

Suction outlet covers must have been tested by a nationally recognized testing

laboratory and found to comply with the latest ASME/ANSI Specification for

Suction Fittings For Use in Swimming Pools, Spas, Hot Tubs, and Whirlpool

Bathtub Applications.

Outlets Per Pump

Provide at least two hydraulically balanced main drains, with covers (see Page

5), for each swimming pool pump suction line. The centers of the main drains

(suction fittings) must be at least three feet apart.

The system must be built so that it cannot operate with the pump drawing

water from only one main drain (that is, there must be at least two main drains

connected to the pump whenever it is running). (See Figure 2). However, if

two main drains run into a single suction line, the single suction line may be

equipped with a valve which will shutoff both main drains from the pump

(see Figure 2).

More than one pump can be connected to a single suction line as long as the

requirements above are met.

Water Velocity

The maximum water velocity through any suction outlet must be 1.5 feet per

second unless the outlet complies with the latest ASME/SNSI Specification for

Suction Fittings For Use in Swimming Pools, Spas, Hot Tubs, and Whirlpool

Bathtub Applications. In any case, do not exceed the suction fittings maxi-

mum designed flow rate.

If 100% of the pump’s flow comes from the main drain system, the maximum

water velocity in the pump suction hydraulic system must be six feet per sec-

ond or less even if one main drain (suction fitting) is completely blocked. The

flow through the remaining main drain(s) must comply with the latest

ASME/ANSI Specification for Suction Fittings For Use in Swimming Pools,

Spas, Hot Tubs, and Whirlpool Bathtub Applications.

ELECTRICAL

Ground motor before connecting to electrical power supply. Failure to

ground motor can cause severe or fatal electrical shock hazard.

Do not ground to a gas supply line.

To avoid dangerous or fatal electrical shock, turn OFF power to motor

before working on electrical connections.

Ground Fault Circuit Interrupter (GFCI) tripping indicates an electrical

problem. If GFCI trips and will not reset, have a qualified electrician

inspect and repair electrical system.

Exactly match supply voltage to nameplate voltage. Incorrect voltage

can cause fire or seriously damage motor and voids warranty.

If in doubt consult a licensed electrician.

Voltage

Voltage at motor must be not more than 10% above or below motor name-

plate rated voltage or motor may overheat, causing overload tripping and re-

duced component life. If voltage is less than 90% or more than 110% of rated

voltage when motor is running at full load, consult power company.

Grounding/Bonding

Install, ground, bond and wire motor according to local or National Electrical

Code requirements.

Permanently ground motor. Use green ground terminal provided under motor

canopy or access plate (See Figure 3); use size and type wire required by

code. Connect motor ground terminal to electrical service ground.

Bond motor to pool structure. Use a solid copper conductor, size No. 8 AWG

(8.4 sq.mm) or larger. Run wire from external bonding lug (see Figure 3) to

reinforcing rod or mesh.

Connect a No. 8 AWG (8.4 sq.mm) solid copper bonding wire to the pressure

wire connector provided on the motor housing and to all metal parts of the

swimming pool, spa, or hot tub and to all electrical equipment, metal piping

or conduit within 5 feet (1.5 m) of the inside walls of swimming pool, spa, or

hot tub.

Wiring

Pump must be permanently connected to circuit. See Figures 4A and 4B for

wiring connection diagrams. Match wire and circuit breaker sizes to correct

Fusing and Wiring Data Chart (Page 8). If other lights or appliances are also on

the same circuit, be sure to add their amp loads to pump amp load. (If unsure

how to do this or if this is confusing, consult a licensed electrician.) Use the

load circuit breaker as the master on-off switch.

Install a Ground Fault Circuit Interrupter (GFCI) in circuit; it will sense a short-

circuit to ground and disconnect power before it becomes dangerous to pool

users. For size of GFCI required and test procedures for GFCI, see manufac-

turer’s instructions.

In case of power outage, check GFCI for tripping (which will prevent normal

water circulation). Reset if necessary.

NOTICE: If you do not use conduit when wiring motor, be sure to seal wire

opening on end of motor to prevent dirt, bugs, etc., from entering motor.

BONDING

LUG

GREEN

GROUND

SCREW

510 0993

Figure 3: Typical ground screw and

bonding lug locations.

Figure 4A: Single-phase, single speed

wiring connection diagram.

For 3-phase connection, refer

to motor nameplate.

Figure 4B: Wiring connections for plug-in type terminal board (Single speed, single phase motors)

White

230

Volt

Lines

Blue

469 0194A

115 V

230 V

230 Volt to 115 Volt Conversion. Move plug to change voltage.

Ground

Screw

230V

115V

230V

115V

230V

115V

230V

115V

Power Supply

Wires

Pull plug

straight

out from

terminal

board.

Plug in again

with arrow

on plug

pointing to

'115 Volts'.

230

Volts

115

Volts

230

Volts

115

Volts

Ground

Screw

3962 0401 A

230 Volt to 115 Volt Conversion. Move plug to change voltage.

TABLE II - RECOMMENDED FUSING AND WIRING DATA – P6RA MODELS

Serv. to Motor - Dist. in Ft. (M)

Motor Branch Fuse Max Load Voltage/ 0-100' 101-200' 201-300'

HP Rating Amps* Amps Hz/Phase (0-30 M) (30-60 M) (60-90 M)

P6RA Models:

120/15 15.3/7.6 115/230/60/1 12/14(3/2) 8/14(8.4/2) 6/14(14/2)

1-1/2 30 19.2 115/60/1 10(5.5) 8(8.4) 6(14)

1-1/2 15 9.6 230/60/1 14(2) 14(2) 12(3)

215 12.0 230/60/1 14(2) 14(2) 12(3)

P6RA 2-Speed Models:

1-1/2 15 9.2/2.5 230/60/1 14(2) 14(2) 12(3)

21510.1/3.7 230/60/1 14(2) 14(2) 12(3)

* Time delay fuses are recommended instead of standard fuses in any motor circuit.

Wire

Size

AWG

(mm2)

}

TABLE I - RECOMMENDED FUSING AND WIRING DATA – P6E MODELS

Serv. to Motor - Dist. in Ft. (M)

Motor Branch Fuse Max Load Voltage/ 0-100' 101-200' 201-300'

HP Rating Amps* Amps Hz/Phase (0-30 M) (30-60 M) (60-90 M)

P6E Models:

1/2 15 11.0 115/60/1 14(2) 10(5.5) 8(8.4)

3/4 20 13.8 115/60/1 12(3) 10(5.5) 8(8.4)

125 16.0 115/60/1 12(3) 8(8.4) 6(14)

1/2 15 5.5 230/60/1 14(2) 14(2) 14(2)

3/4 15 6.9 230/60/1 14(2) 14(2) 14(2)

115 8.0 230/60/1 14(2) 14(2) 14(2)

1-1/2 15 10.4 230/60/1 14(2) 12(3) 12(3)

215 11.2 230/60/1 14(2) 12(3) 12(3)

325 15.8 230/60/1 12(3) 12(3) 10(5.5)

* Time delay fuses are recommended instead of standard fuses in any motor circuit.

Wire

Size

AWG

(mm2)

}

OPERATION

NEVER run pump dry. Running pump dry may damage seals, causing

leakage and flooding. Fill pump with water before starting motor.

Before removing trap cover:

1. STOP PUMP before proceeding.

2. CLOSE GATE VALVES in suction and discharge pipes.

3. RELEASE ALL PRESSURE from pump and piping system.

4. NEVER tighten or loosen clamp while pump is operating!

If pump is being pressure tested, be sure pressure has been released be-

fore removing trap cover.

Do not block pump suction. To do so with body may cause severe or

fatal injury. Small children using pool must ALWAYS have close adult

supervision.

Fire and burn hazard. Modern motors run at high temperatures.

To reduce the risk of fire, do not allow leaves, debris, or foreign matter to col-

lect around the pump motor. To avoid burns when handling the motor, let it

cool for 20 minutes before trying to work on it. An automatic internal cutoff

switch protects the motor from heat damage during operation.

NOTICE: Maximum ambient temperature for motor operation must not

exceed maximum ambient temperature rating on motor model plate.

Priming Pump

Release all pressure from filter, pump, and piping system; see the filter owner’s

manual.

In a flooded suction system (water source higher than pump), pump will prime

itself when suction and discharge valves are opened.

If pump is not in a flooded suction system, remove trap cover handle ring and

trap cover; fill trap and pump with water.

Do not lubricate the trap cover O-Ring. The original equipment O-Ring con-

tains a permanent internal lubricant.

NOTICE: If you replace the O-Ring with a non-internally lubricated O-Ring,

you may need to apply a silicone based lubricant.

Clean and inspect O-Ring; reinstall on trap.

Replace trap cover and handle ring on trap; turn handle ring clockwise to

tighten cover.

NOTICE: Tighten trap cover handle ring by hand only (no wrenches)!

Pump should prime now. Priming time will depend on vertical length of suc-

tion lift and horizontal length of suction piping.

If pump does not prime, make sure that all valves are open, suction pipe end

is under water, and that there are no leaks in suction pipe.

See Troubleshooting Guide, Page 13.

Routine Maintenance

The only routine maintenance needed is inspection/cleaning of trap basket.

Debris or trash that collects in basket will choke off water flow through the

pump. Follow instructions below to clean trap:

1. Stop pump, close valves in suction and discharge, and release all pressure

from system before proceeding.

Hazardous suction.

Can trap hair or

body parts, causing

severe injury

or death.

Do not block

suction.

2. Remove trap cover handle ring (turn counterclockwise). If necessary, tap

handles gently with a rubber mallet.

3. Remove strainer basket and clean. Be sure all holes in basket are clear,

flush basket with water and replace in trap with large opening at pipe con-

nection port (between ribs provided). If basket is replaced backwards cover

will not fit on trap body.

4. Clean and inspect lid O-Ring; reinstall on trap.

5. Clean O-Ring groove on trap body and replace cover and handle ring. To

help keep cover from sticking, tighten hand tight only.

6. Prime pump (see priming instructions).

Draining Pump

1. Pump down water level below all inlets to the pool.

To avoid dangerous or fatal electrical shock hazard, turn OFF power to

motor before draining pump.

2. Remove trap cover and use low pressure air to blow accumulated water

from the piping system. Lugs have been provided on the trap lid to use a

lever or pry bar for loosening.

3. Cap inlet piping after draining to keep water out of the pipes.

4. To prevent pump from freezing, remove trap cover and drain the tank body

through the drain plugs (Key No. 19, Pages 14 - 18). Clean pump and trap

basket thoroughly; replace trap cover.

NOTICE: Tighten trap cover by hand only (no wrenches)! Use a rubber

mallet only if necessary to remove cover! If pump is not anchored, use cau-

tion not to break attached piping!

5. Be sure motor is kept dry and covered.

Storage/Winterizing:

Explosion hazard. Purging the system with compressed air can

cause components to explode, with risk of severe injury or death to anyone

nearby. Use only a low pressure (below 5 PSI), high volume blower when air

purging the pump, filter, or piping.

NOTICE: Allowing pump to freeze will damage pump and void warranty!

NOTICE: Do not use anti-freeze solutions (except propylene glycol) in your

pool/spa system. Propylene glycol is non-toxic and will not damage plastic

system components; other anti-freezes are highly toxic and may damage plas-

tic components in the system.

Drain all water from pump and piping when expecting freezing temperatures

or when storing pump for a long time (see instructions below).

Keep motor dry and covered during storage.

To avoid condensation/corrosion problems, do not cover pump with plastic.

For outdoor/unprotected installations:

1. Gravity drain system as far as possible.

2. Protect areas which retain water with non-toxic propylene glycol antifreeze

(“RV antifreeze”).

3. Enclose entire system in a weatherproof enclosure.

4. To avoid condensation/corrosion damage, allow ventilation; do not wrap

system in plastic.

5. Use a 40% propylene glycol/60% water solution to protect pump to -50°F

(-46°C).

Hazardous voltage.

Can shock, burn,

or cause death.

Disconnect power

before working

on pump or motor.

Otros manuales para MAX-E-PRO

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Bomba de piscina de STA-RITE

STA-RITE

STA-RITE CSP Series Manual de usuario

STA-RITE

STA-RITE DYNA-GLAS 5MPRA Series Manual de usuario

STA-RITE

STA-RITE 5P1R Manual de usuario

STA-RITE

STA-RITE MAX-E-GLAS PE Series Manual de usuario

STA-RITE

STA-RITE Dyna-Wave Manual de usuario

STA-RITE

STA-RITE 5P2R Manual de usuario

STA-RITE

STA-RITE MAX-E-PRO Manual de usuario

STA-RITE

STA-RITE ABG Series Manual de usuario

STA-RITE

STA-RITE WATERFORD SYSTEMS JWPS5EL Manual de usuario

STA-RITE

STA-RITE MAX-E-PRO Manual de usuario

STA-RITE

STA-RITE PRC Series Manual de usuario

STA-RITE

STA-RITE ABG Series Manual de usuario

STA-RITE

STA-RITE PCD-10B Guía

STA-RITE

STA-RITE JTACLC-A Manual de usuario

STA-RITE

STA-RITE JWPA5C Manual de usuario

STA-RITE

STA-RITE DYNA-GLAS Manual de usuario

STA-RITE

STA-RITE 60 CYCLE C Series Manual de usuario

STA-RITE

STA-RITE JTACL1/2 HP Manual de usuario

STA-RITE

STA-RITE DURA-GLAS PE Series Manual de usuario

STA-RITE

STA-RITE S5P Series Manual de usuario

STA-RITE

STA-RITE Supermax Manual de usuario

STA-RITE

STA-RITE JWPA5DL-A Manual de usuario

STA-RITE

STA-RITE IntelliPro VS-3050 Manual de usuario

STA-RITE

STA-RITE 5MPR Manual de usuario

Manuales populares de Bomba de piscina de otras marcas

TIP

TIP STEAM 35000 INV Diagrama de cableado

Jacuzzi

Jacuzzi J-HI27C Manual de usuario

PoolRite

PoolRite SQI 400 Manual de usuario

Pentair

Pentair IntelliComm Manual de usuario

Calpeda

Calpeda NMP Manual de usuario

WilTec

WilTec 50374 Manual de usuario

Evolution

Evolution Evoflow Storm Eco-V Manual de usuario

AquaTools

AquaTools AT240701 Manual de usuario

Sibo

Sibo AquaForte RD352 Manual de usuario

CLS

CLS VICTORIA PLUS SILENT Manual de usuario

Pond One

Pond One Piranha 800 Manual de usuario

Hayward

Hayward VSP Manual de usuario

Resol

Resol DeltaSol B Pro Manual de usuario

Evolution Aqua

Evolution Aqua UniTech Perfect 5000 Manual de usuario

Outside Living Industries

Outside Living Industries Ubbink Heatermax Pool Guía de inicio rápido

CPI

CPI Olympic 2P1815 Manual de usuario

Flotec

Flotec FP6121-01 Manual de usuario

Pentair

Pentair ONGA LEISURETIME LTP400 Manual de usuario
