Ssl CL12D Manual de usuario
03.2012
CL12D
CL12D
31
0.464
6.003
0.503
1.918
0.315
1.8
96
1000W/2000W
2
31
0.456
5.775
0.495
2.105
0.315
7.2
96
1000W/2000W
8
12” (305mm) Subwoofer
(1000 Watts RMS Sealed Enclosure)
Wiring
Please take every precaution to wire your DVC woofers
for the correct impedance
+-+-
+-+-
12” (305mm) CUSTOM TOOLED HIGH EFFICIENCY POLY
INJECTION CONE BUTYL RUBBER SURROUND
DUAL 2-1/2” (64mm) HIGH TEMPERATURE KAPTON
VOICE COIL
2000 WATTS PEAK/1000 WATTS RMS
FREQUENCY RESPONSE: 25 Hz-2 KHz
SENSITIVITY: 96dB (1 WATT/1 METER)
IMPEDANCE: DUAL 4 OHMS
MOUNTING DEPTH: 6-9/16” (167mm)
MOUNTING DIAMETER: 11-3/16” (284mm)
2 ohms 8 ohms
Box Volume :
1.4 Cu Ft to 2.0 Cu Ft
Port Frequency :
Port Diameter :
Port Length :
4
40 to 35
14 to 10
lnches
Hz
lnches
Box Volume :
0.6 Cu Ft to 2.0 Cu Ft
Box is given as internal air volume including driver displacement
Ported Enclosure
Frequency
CL12D Amplitude Response(dB/Hz)
Box is given as internal air volume including driver displacement
Sealed Enclosure
Recommended Enclosures
Frequency
Please note : Our recommended box volumes are given for
internal air requirements.
CL12D Amplitude Response(dB/Hz)
Sealed Enclosure
Ported Enclosure
