SPOT xp 575 Manual de usuario
CAUTION!
Contents
Inspection.
Description of the appearance
Features
Safety instructions
Lamp Installation
Rigging
Linking
, QVWUXFWLRQI RUJ RERUHSODFHP HQW
DMX Channel Chart
Control Board
Maintenance
Replacing the Fuse
Appendix A
Product Specifications
Connection with the mains
1
2
3
4
5
6
7
7
8
9
14
15
16
16
17
Great effect variety
9+1 fixed gobos and 6+1 rotating gobos allocated in two different
gobo wheels; and all gobos are easily changed.
!Various kinds of glass gobos are available for clients' choices.
!Rotating three facet prism.
!1-7Hz fast flashing and 0-100% linear dimmer.
Sophisticated appearance and structure design
Stylish, high impact resistant polymer shell, which is lighter than
anyone else of the same class in the market.
!Smooth and silent revolving of a big range of 570-degree in X axis
and 270-degree in Y axis, automatic electronic sensor to zero.
!Two separated 11-dichroic color + white wheels, creating moving
colors as beautiful as the rainbow.
!
!10,000K and 6500K Temperature correction filter.
!3200K temperature correction filter.
!IRIS linear adjustment.
!Remote-controlled focus.
!Remote-controlled lamp switch ON/OFF.
!
!Solid square base is convenient set on the TRUSS, or directly stand
on the ground or stage for uses.
!Systematic modular construction design has all inner function wheels
and PCBs modularized, which allows version update or customization
more convenient.
!Sophisticated optical system makes light output more bright and
sharp.
Simple and easy operation
!Standard USITT DMX512 protocol, 16 or 14 DMX Channel.
!High-torque stepper motors, smooth and precise micro-stepping
control.
!LED screen controls DMX coding and built-in functions' election, as
well as also display lamp's time usage.
Features
1
Description of the appearance
Filter
2
Inspection
Carefully unpack the carton, and make sure if any damage or loss
caused by transportation.
Contact your PROLIGHTS dealer to assure your right by telephone or
facsimile immediately if damage has occurred or if something is
missing.
Packing List:
A. XP SPOT 575 Moving Head
B.Operating Manual
C.
D.GOBO
E. Lamps (Optional)
Bracket
3
Safety instructions
This appliance must be earthed (grounded).
Disconnect power before removing covers or servicing.
Keep case closed while operating.
XP SPOT 575 contains no user serviceable parts. Refer servicing to
qualified technicians only.
Lamp and components become hot during operation. Allow time to
cool before handling.
Keep flammable material at least one meter away from unit.
Do not operate in wet conditions or near liquids.
Keep air vents clear to avoid overheating.
Lamp produces hazardous UV light. Do not look directly at lamp
when lit.
Replace any blown or damaged fuses only with those of identical
values.
4
Lamp Installation
Keep projector-head upward (See Figure below.) and loosen three
screws on the cover with appropriate tool then open the top cover
and put it aside.
Loosen and grab the screws on the
shutter cover with appropriate tool.
Wear the gloves and extract the lamp from
the package, loosen the screws on both sides of
the lamp, then slide the lamp paralleled into the
lamp socket. Adjust the round point of the
lamp upward (See Figure.) and fasten the
screws snugly.
Reverse the above-mentioned processes for
the complete installation.
5
WARNING!
Remove the power cord before installing the lamp.
a a
d
XP SPOT 575 can be set on the flat stage floor directly or use clamp to
mount on any kinds of trusses for fitting the mobility of various venues.
Mount two attached brackets(a) on the bottom (See Figure), and
collocate the appropriate clamps(b) to rig with trusses. Must use the
safety ropes that can hold the ten times as heavy as the fixture through
the eye bolts(c) on the bottom of the base and trusses; then join the
safety ropes with screw-on carabines(d).
Rigging:
6
Linking
Use 3-pin XLR data cables to link the controller to DMX lighting
equipment.
3-pin XLR connectors are follows:
Building a serial DMX-chain:
Connect the DMX output of the first fixture with the DMX input of the
next fixture. And execute all the setups following the above-
mentioned instruction.
Flip the DIP SWITCH #3 of last fixture to ON position for terminal
confirmation.
12
3
12
3
1:Ground
2:Signal(-)
3.Signal(+)
1:Ground
2:Signal(-)
3.Signal(+)
' 0 ; RXWSXW
; / 5 P RXQWLQJ VRF NHW
' 0 ; LQSXW
; / 5 P RXQWLQJ SOXJ
Connection with the mains
Connect the device to the mains with the power-plug.
The occupation of the connection-cables is as follows:
Cable Pin International
Brown Live L
Blue Neutral N
Yellow/Green Earth
The earth has to be connected! In general, lighting effects should not
be connected to dimming-packs.
7
, QVWUXFWLRQVI RUJ RERUHSODFHP HQW
Please choose the suitable gobo dimensions of this fixture. (Appendix A)
3.Push GOBO & the spring ring out with the
fingers carefully. (*Caution: Avoid falling
the spring ring into the fixture.)
2.Turn the open (circle) of the GOBO wheel to
"U" shape gap in order to extract the rotating
GOBO easily.
Rotating GOBO wheel
1.Open the top cover (*Refer to the steps of lamp installation.), and
loosen the screws with appropriate tools then extract A . (See the
figures below.)
4.Insert the new GOBO and the spring ring (*Press the spring ring
tight with the appropriate tools in order to keep GOBO compact),
put A back and screw up the top cover.
Fixed GOBO wheel
The instructions are the same as changing the rotating GOBO; only
winkle the spring ring out with appropriate flat screw driver before
push GOBO out.
' $1* ( 5
, QVWDOOWKHJ RERVZ LWKWKHGHYLFHVZ LWFKHG
RIIRQO\ 8 QSOXJ I URP P DLQVEHI RUH
!
A
8
