Step-By-Step Quick Start
Guide To Using Your Generator
GENERATOR SPECIFICATIONS:
• 3 HP Engine, 4 Stroke OHV
• Recoil Start
• 1.32 Gallon Fuel Tank
• UL Listed Electrical Components
• Engine Shut Off Switch
• Circuit Breaker & Power Outlets
• 1-12V DC Outlet
• 2 -120V AC Outlets
• Carbon Monoxide Warning Alert
• Complies with EPA emissions
• Run time = 9 hours @ 50% load
• Decibel Rating < 68 db @ 0% load
• Warranty: 2 YEAR Limited Emissions
• Warranty: 1 YEAR Limited
• If you are using a generator 3,000 ft. above
sea level, the generator may not function
properly because of air flow getting through
the carburetor.
• High Altitude Use: This generator is not
recommended for high altitude use 3,000 ft.
above sea level.
GEN2K
Remove Generator From Package
Add Oil
Add Fuel
Start The Generator
2,000 Surge / 1,800 Running Watts
UNLEADED GASOLINE FUEL
Oil Type: SAE10W-30 Oil (Must add BEFORE first use)
Oil Capacity: 13.5 fluid oz
Because this generator includes Low Oil Shut Off, the
generator will not start with low oil. Start out with 13.5 oz,
then fill until almost overflowing.)
Unleaded gasoline only octane rating of 87 or higher
Maximum Capacity: 1.32 Gallon fuel tank
Use the generator OUTDOORS in a WELL VENTILATED AREA.
DO NOT CONNECT electrical devices until AFTER the generator
is started.
Turn Engine Switch to ON
Turn FUEL PETCOCK to ON (Figure A)
Adjust the CHOKE to CLOSED/CHOKE position (Figure B)
Start the generator manually with the Recoil (Pull) Start.
Once the engine has started, GRADUALLY move the choke lever
to the “RUN/OPEN” position until the engine levels off. Then let
the engine run approximately 5 minutes BEFORE adding
appliances or tools.
You can now connect electrical devices.
Choke (Figure B)
Fuel Petcock (Figure A)
O
On
Run/Open
Closed/Choke
3Add Gasoline
Add Oil
Engine
Switch
Recoil
Start 42
4
OIL IS NOT INCLUDED WITH THIS
GENERATOR. IT IS SOLD SEPARATELY.
Read and understand instruction manual
before using generator.
1
2
3
4
Need Help? Call Customer Service!
Monday-Friday 8:00-4:00 Central Time
TOLL-FREE NATIONWIDE HELP LINE! 866-460-9436
ATTENTION
ALERT!
This generator includes
a built-in Carbon Monoxide
Warning Alert! The generator
will automatically shut-off
if
dangerous levels of Carbon
Monoxide i
s detected.
SPORTSMANSPORTSMAN
CARBON
MONOXIDE
ALERT
