Sportline SL708 Manual de usuario

Introduction......................................................................................................................3

Caution ............................................................................................................................3

Button Overview ..............................................................................................................4

Operation.........................................................................................................................6

Speciﬁcations..................................................................................................................14

Battery Usage .................................................................................................................15

Display Viewing..............................................................................................................15

Table of Contents

SP4425IS01ENB.indd 2SP4425IS01ENB.indd 2 3/18/08 4:39:35 PM3/18/08 4:39:35 PM

Head H1 or H2

Introduction

The Sportline®Heart Rate Watch with LED Beats Per Minute accurately measures ECG

heart rates without a chest strap. It operates as a basic analog watch and features digital

time, calendar and heart-rate monitor functions.

Read all instructions carefully before use. Save these instructions for future reference.

Caution

• Avoid exposing the watch to extreme conditions.

• Avoid rough use and severe impacts.

• Do not attempt to repair, disassemble or modify the watch in any way.

• Clean the watch occasionally with a soft damp cloth.

• Store the watch in a dry place when not in use for an extended period.

• To avoid the possibility of damage, we recommend that you take the watch to a specialist

for battery replacement. 3

SP4425IS01ENB.indd 3SP4425IS01ENB.indd 3 3/18/08 4:39:36 PM3/18/08 4:39:36 PM

Button Overview

• Time Button

• Heart Rate Button

• Crown

• Daily Alarm Button

• Sensor Contact 1

• Back Cover (Sensor Contact 2)

SP4425IS01ENB.indd 4SP4425IS01ENB.indd 4 3/18/08 4:39:36 PM3/18/08 4:39:36 PM

Head H1 or H2

Button Overview

Time Button: Press to view Current Time Display, date, day of week and seconds.

Hold down to enter the Current Time Setting mode.

Heart Rate Button: Hold down in conjunction with the Sensor Contacts to measures heart

rate. Press to select among different settings.

Crown: Pull out to set analog time.

Time Button

Sensor

Contact 1

Heart Rate

Button

Crown

Daily Alarm

Button

SP4425IS01ENB.indd 5SP4425IS01ENB.indd 5 3/18/08 4:39:36 PM3/18/08 4:39:36 PM

Button Overview

Daily Alarm Button: Displays alarm setting. Press to increase/change setting value.

Sensor Contact 1: Heart-rate sensor contact. Hold down button in conjunction with Heart

Rate button to measure heart rate.

Back Cover (Sensor Contact 2): Heart-rate sensor contact. Battery door.

Operation

Setting the Analog Watch

1. To set the analog time, gently pull the Crown out, until you feel a click. The second

hand stops and the digital time ﬂashes.

2. Turn the Crown clockwise/counterclockwise until the desired time is set. The digital

time can be used as a reference for setting the analog time.

3. To display the hour, minute or second digitally, press any button.

SP4425IS01ENB.indd 6SP4425IS01ENB.indd 6 3/18/08 4:39:37 PM3/18/08 4:39:37 PM

Head H1 or H2

Operation

4. Once the time is set, to resume normal operation, gently push the Crown back to its

original position.

Setting Date and Time

1. Press and hold down the TIME button until the digital display starts to ﬂash.

2. To browse through the different formats (second, minute, hour, year, month, day, date

and time), press the HEART RATE button.

3. To select a format, press the DAILY ALARM button; to change the setting values, press

the button again; to increase the rate of change, hold down the button.

4. With digital seconds selected, to zero out (reset) the watch and synchronize the analog

and digital seconds, press the DAILY ALARM button.

5. When complete, press the TIME button to save the settings and return to the Current

Time Display.

SP4425IS01ENB.indd 7SP4425IS01ENB.indd 7 3/18/08 4:39:37 PM3/18/08 4:39:37 PM

Operation

Note: The watch exits setting mode and shuts off automatically after 60 seconds of

inactivity.

Synchronizing Analog and Digital Time

The analog and the digital time of the LED Heart Rate Watch will differ because they are

two independent systems. You will need to set both time functions manually to synchronize

the time.

Setting Alarm Time

1. Hold down the DAILY ALARM button; the digital display ﬂashes.

2. To browse through the different settings (alarm ON/OFF, alarm hour, alarm minute),

press the HEART RATE button.

3. To select a setting, press the DAILY ALARM button.

4. To save the selected setting, press the TIME button.

SP4425IS01ENB.indd 8SP4425IS01ENB.indd 8 3/18/08 4:39:37 PM3/18/08 4:39:37 PM

Head H1 or H2

Operation

Heart-Rate Mode (Precautions and Tips)

• There are two heart-rate sensor contacts on the watch: Sensor Contact 1 and the Back

Cover (Sensor Contact 2). The Back Cover must make ﬁrm contact with the user’s skin

(wrist) during measurement.

• Do not take heart-rate measurements while diving or under water.

• Do not use with hand cream. It will insulate the signal between the skin and

Sensor Contacts.

• Do not use the ﬁngertips where the skin is dry and thick. For those with extremely dry

skin, moisten the ﬁngers and wrist with tap water or a conductive gel.

• Clean the Back Cover occasionally, using a damp cloth. Wipe dry to remove any residue.

• To ensure better signal transmission, clean your skin and ﬁngers with soap and water.

SP4425IS01ENB.indd 9SP4425IS01ENB.indd 9 3/18/08 4:39:38 PM3/18/08 4:39:38 PM

Operation

• Hold the watch ﬁrmly when taking measurements in motion.

• Avoid awkward motions during measurement. They may create inaccurate heart-

rate readings.

Heart-Rate Measurement

1. To measure heart rate, press the HEART RATE button with your index ﬁnger for about

5 seconds.

2. Ensure the Back Cover of the watch sits ﬁrmly on the skin.

3. Press SENSOR CONTACT 1 with your thumb.

Note: To obtain a heart-rate reading, both Sensor Contact buttons must be pressed

simultaneously.

SP4425IS01ENB.indd 10SP4425IS01ENB.indd 10 3/18/08 4:39:38 PM3/18/08 4:39:38 PM
