Speed Queen TR3 Manual del operador

Quick Consumer

Manual

Two (2) lter

screen washers

Two (2) plain

rubber washers

Four (4) rubber

feet

Beaded strap

Installation

Parts included:

1. Remove shipping brace and shipping plug.

2. Wipe out inside of washtub.

3. Connect ll hoses – water pressure = 20-120 psi [138-827 kPa].

• Two required, sold separately

• Flush water supply lines

• Use two lter screen washers with screen facing faucet

• Use two rubber washers in end of hose connecting

to the machine

4. Connect drain hose to drain receptacle – 36 in. [91 cm]

recommended height.

• Use beaded strap to secure drain hose to drain receptacle

5. Position and level washer – adjust front two legs. Tilt washer

forward and back to set rear legs.

• Place four rubber feet on leveling legs

6. Connect washer to electrical power – on individual branch

circuit. Refer to serial plate for electrical ratings.

7. Run washer through one complete cycle to make sure it is

operating properly.

Welcome

Thank you for purchasing a Speed Queen®appliance. We value you as a customer.

At Speed Queen, leading performance is our daily reality. We seek to deliver an outstanding

experience in every aspect of laundry. Your machine was built to last 25 years in your home and

Speed Queen support has been built to provide you with the best service in the industry.

8. Check for leaks.

The Normal Eco Cycle

The Normal Eco Cycle is designed for providing

an eco-friendly solution for washing everyday

cottons and linens. You will notice that this cycle

uses less water and less hot water than other

cycles. These functions are unique to the Normal

Eco Cycle. All other cycles and options have no

temperature restriction and use a full tub rinse.

Electronic Control Washers –

Special Cycles Reference

When you select the Special Cycles keypad, pressing the

up and down arrow keypads will allow you to choose from

eight dierent cycles. The display will show P and a number

relating to the cycle.

Eco Heavy Duty

This cycle uses a spray rinse to

reduce water consumption. It also

uses less hot water. It has a longer

wash time than the Normal Eco

cycle. If using fabric softener in this

cycle, select the Extra Rinse option.

Eco Delicate

This cycle uses a spray rinse to

reduce water consumption. It also

uses less hot water. It has a shorter

wash time and a gentler wash

action than the Normal Eco cycle.

If using fabric softener in this cycle,

select the Extra Rinse option.

Waterproof

Wash waterproof items such as rain

coats and bed liners with this cycle.

It includes a gentle agitation, very

low spin, and lower water levels. For

best washing results, add another

item such as a cotton sheet on top

of the waterproof items to make

sure they get fully submersed in

the water and that no air is trapped

under the waterproof items.

Super Soiled

Use for very heavily soiled items. It

includes a 15-minute soak at the

beginning of the cycle, a longer

wash time than Heavy Duty and

Extra Rinse.

Wool

Wash wool items using this cycle.

It includes cold water, a 30-minute

soak, a very short gentle agitation,

a one-minute spin, a cold rinse, and

an extended spin time.

Athletic

This cycle includes a cold wash and

a shorter, gentle agitation.

Denim

This cycle is similar to the Heavy

Duty cycle but with cold wash and a

longer spin time.

Cycle Information

Whites

This cycle is designed to keep white

laundry white. It utilizes a longer

wash time. Use for items such as

sheets and towels.

Auto Fill

Auto Fill will provide the most ecient use of

water and also enhance wash performance by

optimizing the water level for each particular

load size and type.

6. 7. 9.

5. Set cycle

Operating

1. Prepare laundry 2. Add detergent

3. Load laundry 4. Close lid

6. Set temperature

1. Register your product at www.speedqueen.com

to take full advantage of the limited warranty.

2. Download full documentation and view installation and operating

videos for an immersive experience at Speedqueendoc.net or scan

the QR code below.

3. If you wish to receive printed documents at no cost, please complete

the order form and return by mail to the address on the form, or

email your request to [email protected].

Warranty

3, 5 & 7 Year Warranties, depending on your model.

Covers all parts and in-home labor.

Order Form for Printed Documentation

Allow 1-2 weeks for delivery.

Model No.

Serial No.

Name

Address City State

Zip Code Phone No.

Email Address

7. Set load size

(Auto ll recommended) 8. Set soil level

9. Press start/pause

Note: This unit includes a limited warranty. Refer to

Speedqueendoc.net to download the full warranty bond.

TR3 control

TR5 control

TR7 control

BUSINESS REPLY MAIL

FIRST CLASS MAIL PERMIT NO. 489 RIPON,WI

POSTAGE WILL BE PAID BY ADDRESSEE

NO POSTAGE

NECESSARY IF

MAILED IN THE

UNITED STATES

SPEED QUEEN

TECHNICAL DOCUMENTATION

SHEPARD STREET

P O BOX 990

RIPON WI 54971-9967

Part No. 204793R1

April 2019
