Speed Queen Home Laundry Manual de usuario
Commercial Quality for Your Home
Laundry — it’s all we do.
For more than 90 years, Speed Queen has been a leading name
in laundry equipment.
Speed Queen’s heritage dates back to 1908 as one of the first
manufacturers of home laundry equipment. Today, we’re a world
leading manufacturer of commercial washers and dryers. We have
built a reputation for manufacturing durable, long-lasting, quality
laundry equipment.
Speed Queen washers and dryers for the home boast the
same design and hardened components used to withstand
the demanding requirements of coin and apartment laundries
around the world.
When you’re looking for reliable laundry equipment built with
American pride since 1908, look to the experts at Speed Queen.
Laundry — it’s all we do.
$ ____________
AWS51 — Additional features:
2-Speed Motor, 17 Cycles, Extra Rinse Option
Commercial Quality and Dura ility
All Speed Queen topload washers boast the same
commercial design and quality components including:
• Commercial transmission with only six moving parts
and all-metal gears
• Automatic balance system that ensures your washer
will operate on almost any floor
• Extra-large 3.3 cu. ft. capacity stainless steel washtub
• Porcelain enamel over commercial quality steel outer draintub
• Three-coat commercial grade cabinet finish
Performance and Efficiency
• Variable water selector
• Flex vane agitator with 210° agitation stroke and 68 strokes
per minute for excellent cleaning, while gentle on clothes
• Fabric softener dispenser
• Bleach dispenser
• 100% upfront service from installed position
• Three water temperatures
$ ____________
$ ____________
AWS17 — Additional features:
1-Speed Motor, 7 Cycles
AWS44 — Additional features:
2-Speed Motor, 8 Cycles
$ ____________
AWS76 — Additional features:
2-Speed Motor, 20 Cycles, Extra Rinse, Fabric Selector Switch
Topload Washers
Standard feature available on all Speed Queen topload wa her .
Commercial-Grade
Steel Cabinet
with a three-coat commercial-
grade finish ensures your
washer will remain looking
new for years to come.
Automatic Balancing
System (ABS)
designed to perform on almost
any floor type for smooth and
quiet operation.
Porcelain Enamel
Over Steel Outer Draintub
for a lifetime of
worry-free performance.
Heavy-Duty All-Metal
Eversmooth Transmission
has only six moving parts for
long-lasting, durable performance.
1/2 HP Heavy-Duty Motor
for years of reliable performance.
Provides 710 RPM spin speed
for maximum water extraction
allowing faster drying and
energy savings.
Topload Inner Strength
Extra-Large 3.3 cu. ft.
Stainless Steel Tub
won’t corrode, chip, crack or
pit with normal use.
Flex ane Agitator
delivers an extra-long 210°
agitation stroke with 68 strokes
per minute for superb washing
results, yet is gentle on
your clothes.
Commercial Quality and Dura ility
All Speed Queen Horizon®frontload washers boast the same
commercial design and quality components including:
• Extra-large 3.3 cu. ft.* capacity stainless steel wash
cylinder and outer tub
• Extra-large 15.5" door opening
• Heavy-duty variable speed induction motor
• Three-coat commercial grade cabinet finish
• Four industrial-quality shock absorbers
• Durable metal trunion, bearing, and drive shaft
• Sealed bearing and aluminum pulley
• Optional Pedestal (part number PDR108W)
* Based on IEC Rat ng.
Performance and Efficiency
•Variable speed induction drive and suspension system
for durable and quiet operation
• High spin speed of 1,000 RPM generating 300 G-Force
for maximum water extraction
• Four temperature settings
• Eight cycles
• Extra rinse option
• Fabric softener dispenser
• Bleach dispenser
• ENERGY STAR®Qualified
• ADA compliant
Speed Queen Frontload Washers can be
ra sed on an opt onal 8" pedestal. (Sold
separately. Part number PDR108W)
ATSA5A — Additional features:
Rear Controls, Boosted Hot
$ ____________
CTSA0A — Additional features:
Front Controls
$ ____________
ATSA0A — Additional features:
Rear Controls
Frontload Washers
Standard feature available on all Speed Queen frontload wa her .
$ ____________
Frontload Inner Strength
Extra-Large 3.3 cu. ft.
Stainless Steel Tub
constructed with 4,912 holes for
increased washing performance
and higher water extraction,
saving energy, time and money.
Three-Coat Commercial-
Grade Steel Cabinet
constructed with a galvanized
metal cabinet and an extra
E coat dip before the final
paint for a long-lasting finish.
Durable Drive System
featuring an aluminum pulley
with sealed bearing in an
aluminum housing for years of
durable and dependable operation.
Stainless Steel Outer Tub
built with a stainless steel
draintub for a lifetime of use.
ariable Speed Induction Motor
with Inverter Drive
offers a 300 G-Force and 1,000 RPM
spin speed for optimum water extraction
and outstanding performance.
Commercial Heavy-Duty
Suspension System
constructed with four commercial
heavy-duty shock absorbers for added
strength, durability and suspension,
limiting out-of-balance issues.
Extra-large 15.5" door,
allows easy loading
and unloading.
$ ____________
AES28/AGS28 — Additional features:
3 Cycle Selections, 3 Temperature Settings, Adjustable End-of-Cycle Buzzer,
Rear Control, Cylinder ight
$ ____________
CES68/CGS68 — Additional features:
4 Cycle Selections, 4 Temperature Settings, Front Control, Dryer Rack,
Adjustable End-of-Cycle Buzzer, Extend Tumble Switch, ADA Compliant, Cylinder ight
$ ____________
$ ____________
AES68/AGS68 — Additional features:
4 Cycle Selections, 4 Temperature Settings, Rear Control, Dryer Rack,
Adjustable End-of-Cycle Buzzer, Extend Tumble Switch, Cylinder ight
AES17/AGS17 — Additional features:
3 Cycle Selections, Auto Dry Cycles, Rear Control
Commercial Quality and Dura ility
All Speed Queen dryers boast the same commercial design
and quality components including:
• Durable galvanized steel cylinder
• Superior airflow technology of 220 cfm
• Three-coat commercial-grade finish on cabinet
• Upfront, commercial-grade, secured lint filter
• Reversible door
Performance and Efficiency
• Quiet, highly efficient blower system for faster drying
with less wrinkling
• Extra-large 7.0 cu. ft. capacity cylinder
• Automatic dry cycles
Dryers
Standard feature available on all Speed Queen dryer .
Speed Queen offers an opt onal
dry ng rack. (Sold separately.
Part number 512082P)
Dryer Inner Strength
Galvanized Steel Cylinder
with a commercial galvanized
steel interior that won’t corrode,
chip or crack, and has a limited
lifetime warranty.
Extra-Large
Cylinder Capacity
of 7.0 cu. ft. eliminates large
load problems. The increased
size means superior tumble
action and more efficient drying.
Convenient, Upfront
Lint Filter
that is easy to reach
and clean.
Largest Door Opening
in the Industry
measures 2.06 sq. ft., making
loading and unloading easier.
Reversible Door
can open to the right or left so
you can customize your laundry.
Quiet,highly efficient blower
with a superior airflow of
220 cfm for faster drying.
Up-Front Servicability
for easy maintenance from the
installed position.
Washer
Commercial Quality and Dura ility
All Speed Queen frontload washers boast the same
commercial design and quality components including:
• Extra-large 3.3 cu. ft.* capacity stainless steel wash
cylinder and outer tub
• Extra-large 15.5" door opening
• Heavy-duty variable speed induction motor
• Three-coat commercial grade cabinet finish
• Four industrial-quality shock absorbers
• Durable metal trunion, bearing and drive shaft
• Sealed bearing and aluminum pulley
* Based on IEC Rat ng.
Performance and Efficiency
• Variable speed induction drive and suspension system
for durable and quiet operation
• High spin speed of 1,000 RPM generating 300 G-Force
for maximum water extraction
• ENERGY STAR®Qualified
• ADA compliant
Dryer
Commercial Quality and Dura ility
All Speed Queen dryers boast the same commercial design
and quality components including:
• Durable galvanized steel cylinder
• Superior airflow technology of 220 cfm
• Three-coat commercial-grade finish on cabinet
• Upfront, commercial-grade, secured lint filter
Performance and Efficiency
• Quiet, highly efficient blower system for faster drying
with less wrinkling
• Extra-large 7.0 cu. ft. capacity cylinder
• Automatic dry cycles
$ ______________
CTSA7AWN/CTSA9AWN — Additional features:
Washer: 8 Cycles, 4 Temperature Settings, Front Controls,
Dryer: 3 Cycles, 3 Temperature Settings, Front Controls, Door Windows
• Space savings. The stack unit fits into the floor space of a single washer.
Overall Dimensions: 75 1/4" (H) X 26 7/8" (W) X 28" (D)
• One-piece, heavy-duty stack design. No special installation required.
Discover Space for Laundry
Stack Washer/Dryer
Speed Queen offer olution to your laundry need aving you pace and time
with an ENERGY STAR®Qualified tack wa her/dryer.
