6
3
4
4
A A
B B
WESTBURY, NEW YORK 11590
956 BRUSH HOLLOW ROAD
CORPORATION
SPECTRONICS
REV
DRAWING NUMBER
SIZE
DATE
DATE
DATE
APPROVED
CHECKED
DRAWN
TITLE
NEXT ASSY.
NO. REQ'D
SCALE
30'
.005
ANG.DEC.
UNLESS OTHERWISE SPECIFIED
DIMENSIONAL TOLERANCES
FRAC.
1/64
+
- -
+-
+
MATERIAL FINISH SPECTRONICS PART NO.
1
A-18130
B
PHILIP C
10/8/2018
C:\Engineering\Projects\EDGE LAMPS\A-18130, EDGE-13T, ASSEMBLY MANUAL.idw
DISCLAIMER N
This drawing is the property of Spe
It contains confidential and proprie
cannot be reproduced or divulged,
without prior written authorization
from Spectronics' Engineering
Department. All technical informati
on on this drawing is for
informational purposes only, and is provided in confidence for
mutual assistance. It may not be used to manufacture anything
without prior written authorization from Spectronics' Engineering
Department.
EDGE-13T
MANUAL
3a
3b
3c
3d
3e
3f
EDGE-13T REPLACEMENT PARTS
ITEM PART NO. DESCRIPTION
1 131162 CLEAR GLASS FILTER ASSY. W/ GASKETS
2131161 UV-A LENS (PACK OF 13)
3a 130155 AC CONTROL BOX W/ CONN., 120V, US CO
3b 131165 AC CONTROL BOX W/ CONN., 230-240V, UK
3c 131164 AC CONTROL BOX W/ CONN., 230-240V, AU
3d 131166 AC CONTROL BOX W/ CONN., 230-240V, EU
3e 130497 AC CONTROL BOX W/ CONN., 240V, BR CO
3f 131163 AC CONTROL BOX W/ CONN., 220-240V, CC
4 130198 CONNECTOR PLUG
1
EDG-13T EXPLODED VIEW
AND REPLACEMENT PARTS
ITEM PART NO. DESCRIPTION
1 131162 CLEAR GLASS FILTER ASSEMBLY WITH GASKETS
2 131161 UV-A LENS (PACK OF 13)
3a 130155 AC CONTROL BOX W/ CONN., 120V, US CONFIG.
3b 131165 AC CONTROL BOX W/ CONN., 230-240V, UK CONFIG.
3c 131164 AC CONTROL BOX W/ CONN., 230-240V, AU CONFIG.
3d 131166 AC CONTROL BOX W/ CONN., 230-240V, EU CONFIG.
3e 131163 AC CONTROL BOX W/ CONN., 220-240V, CCC CONFIG.
3f 130497 AC CONTROL BOX W/ CONN., 220-240V, BRAZIL CONFIG.
Replacement Parts
(1) The Clear Glass Filter Assembly comes with two gaskets.
