Spearhead TWIGA COMPACT Manual de usuario

Spearhead TWIGA COMPACT

CE Declaration of Conformity,

Conforming to EU Machinery Directive

2006/42

/EC

We, Spearhead Machinery Ltd, Green View, Salford Priors, Evesham,

Worcestershire, WR11 8SW hereby declare that:

Product ……………………………………………..…………………………

Product Code……………………………………………..…………………………

Serial No……………………………………………..……..………………….

Type……………………………………………..…………………………

Manufactured by: Alamo Manufacturing Services (UK) Limited, Station Road,

Salford Priors, Evesham, Worcestershire, WR11 8SW

Complies with the required provisions of the Machinery Directive 2006/42/EC. The

Machinery Directive is supported by the following harmonized standards:

•

BS EN ISO 14121-1 (2007) Safety of Machinery –Risk Assessment, Part 1:

Principles Part 2: Practical Guide and Examples of Methods.

•

BS EN ISO 12100-1 (2010) Safety of Machinery –Part 1: Basic Terminology

and Methodology Part 2: Technical Principles.

•

BS EN 349 (1993) + A1 (2008) Safety of Machinery –Minimum Distances to

avoid the Entrapment of Human Body Parts.

•

BS EN 953 (1998) Safety of Machinery –Guards General Requirements for

the Design and Construction of Fixed and Movable Guards.

•

BS EN 982 (1996) + A1 (2008) Safety Requirements for Fluid Power Systems

and their Components. Hydraulics.

The EC Declaration only applies if the machine stated above is used in accordance

with the operating instructions.

Signed

(On behalf of Spearhead Machinery Ltd)

Status General Manager

Date 01/04/2017

Spearhead TWIGA COMPACT

IMPORTANT

VERIFICATION OF WARRANTY REGISTRATION

DEALER WARRANTY INFORMATION & REGISTRATION

VERIFICATION

It is imperative that the selling dealer registers this machine with Spearhead Machinery

Limited before delivery to the end user –failure to do so may affect the validity of the

machine warranty.

To register machines go to the Spearhead Machinery Limited web site at

www.spearheadmachinery.com, log onto ‘Dealer Inside’ and select the ‘Machine

Registration button’ which can be found in the Service Section of the site. Confirm to

the customer that the machine has been registered in the section below.

Should you experience any problems registering a machine in this manner please

contact the Spearhead Service Department on 01789 491867.

Registration Verification

NOTE TO CUSTOMER / OWNER

Please ensure that the above section has been completed and signed by the selling

dealer to verify that your machine has been registered with Spearhead Machinery

Limited.

IMPORTANT: During the initial ‘bedding in’ period of a new machine it is the

customer’s responsibility to regularly inspect all nuts, bolts and hose

connections for tightness and re-tighten if required. New hydraulic connections

occasionally weep small amounts of oil as the seals and joints settle in –where

this occurs it can be cured by re-tightening the connection –refer to torque

settings chart below. The tasks stated above should be performed on an hourly

basis during the first day of work and at least daily thereafter as part of the

machines general maintenance procedure.

Dealer Name: ……………………..…………………………………………………………….

Dealer Address: …….………………………………………………………………………….

Customer Name: ……………………..…………………………………………………………

Date of Warranty Registration: ……/……/...…… Dealer Signature: ………………..……

Spearhead TWIGA COMPACT

CAUTION: DO NOT OVER TORQUE HYDRAULIC FITTINGS AND HOSES

TORQUE SETTINGS FOR HYDRAULIC FITTINGS

HYDRAULIC HOSE ENDS

PORT ADAPTORS WITH BONDED SEALS

BSP

Setting

Metric

BSP

Setting

Metric

1/4”

18 Nm

19 mm

1/4”

34 Nm

19 mm

3/8”

31 Nm

22 mm

3/8”

47 Nm

22 mm

1/2”

49 Nm

27 mm

1/2”

102 Nm

27 mm

5/8”

60 Nm

30 mm

5/8”

122 Nm

30 mm

3/4”

80 Nm

32 mm

3/4”

149 Nm

32 mm

1”

125 Nm

41 mm

1”

203 Nm

41 mm

1.1/4”

190 Nm

50 mm

1.1/4”

305 Nm

50 mm

1.1/2”

250 Nm

55 mm

1.1/2”

305 Nm

55 mm

2”

420 Nm

70 mm

2”

400 Nm

70 mm

WARRANTY POLICY

WARRANTY REGISTRATION

All machines must be registered, by the selling dealer with Spearhead Machinery Ltd,

before delivery to the end user. On receipt of the goods it is the buyer’s responsibility

to check that the Verification of Warranty Registration in the Operator’s Manual has

been completed by the selling dealer.

LIMITED WARRANTIES

1.1.

All machines supplied by Spearhead Machinery Limited are warranted to be free from

defects in material and workmanship from the date of sale to the original purchaser for

a period of 12 months, unless a different period is specified.

1.2.

All spare parts supplied by Spearhead Machinery Limited are warranted to be free

from defects in material and workmanship from the date of sale to the original

purchaser for a period of 6 months.

1.3.

The manufacturer will replace or repair for the purchaser any part or parts found, upon

examination at its factory, to be defective under normal use and service due to defects

in material or workmanship. Returned parts must be complete and unexamined.

1.4.

This warranty does not apply to any part of the goods, which has been subjected to

improper or abnormal use, negligence, alteration, modification, fitment of non-genuine

parts, accident damage, or damage resulting from contact with overhead power lines,

damage caused by foreign objects (e.g. stones, iron, material other than vegetation),

failure due to lack of maintenance, use of incorrect oil or lubricants, contamination of

the oil, or which has served its normal life. This warranty does not apply to any

expendable items such as blades, flails, bushes, belts, flap kits, skids, shields, guards,

wear pads or pneumatic tyres.

1.5.

Temporary repairs and consequential loss - i.e. oil, downtime and associated parts are

specifically excluded from the warranty.

Spearhead TWIGA COMPACT

1.6.

Warranty on hoses is limited to 12 months and does not include hoses which have

suffered external damage. Only complete hoses may be returned under warranty, any

which have been cut or repaired will be rejected.

1.7.

Machines must be repaired immediately a problem arises. Continued use of the

machine after a problem has occurred can result in further component failures, for

which Spearhead Machinery Ltd cannot be held liable, and may have safety

implications.

1.8.

Except as provided herein, no employee, agent, dealer or other person is authorised to

give any warranties of any nature on behalf of Spearhead Machinery Ltd.

1.9.

For machine warranty periods in excess of 12 months the following additional

exclusions shall apply:

1.9.1.

Hoses, external seals, exposed pipes and hydraulic tank breathers.

1.9.2.

Filters

1.9.3.

Rubber mountings

1.9.4.

External electric wiring.

1.9.5.

Labour and mileage costs.

1.10.

All service work, particularly filter changes, must be carried out in accordance with the

manufacturer’s service schedule. Failure to comply will invalidate the warranty. In the

event of a claim, proof of the service work being carried out may be required.

NB Warranty cover will be invalid if any non-genuine parts have been fitted or

used. Use of non-genuine parts may seriously affect the machine’s performance

and safety. Spearhead Machinery Ltd cannot be held responsible for any failures

or safety implications that arise due to the use of non-genuine parts.

REMEDIES AND PROCEDURES

2.1.

The warranty is not effective unless the Selling Dealer registers the machine, via the

Spearhead Machinery web site and confirms the registration to the purchaser by

completing the confirmation form in the operator’s manual.

2.2.

Any fault must be reported to an authorised Spearhead Machinery dealer as soon as it

occurs. Continued use of a machine, after a fault has occurred, can result in further

component failure for which Spearhead Machinery Ltd cannot be held liable.

2.3.

Repairs should be undertaken within two days of the failure. Claims submitted for

repairs undertaken more than 2 weeks after a failure has occurred, or 2 days after the

parts were supplied will be rejected, unless the delay has been authorised by

Spearhead Machinery Ltd.

2.4.

All claims must be submitted, by an authorised Spearhead Machinery Service Dealer,

within 30 days of the date of repair.

Spearhead TWIGA COMPACT

2.5.

Following examination of the claim and parts the manufacturer will pay, at their

discretion, for any valid claim the cost of any parts and an appropriate labour allowance

if applicable.

2.6.

The submission of a claim is not a guarantee of payment.

2.07.Any decision reached by Spearhead Machinery Ltd is final.

LIMITATION OF LIABILITY

3.1.

The manufacturer disclaims any express (except as set forth herein) and implied

warranties with respect to the goods including, but not limited to, merchantability and

fitness for a particular purpose.

3.2.

The manufacturer makes no warranty as to the design, capability, capacity or suitability

for use of the goods.

3.3.

Except as provided herein, the manufacturer shall have no liability or responsibility to the

purchaser or any other person or entity with respect to any liability, loss, or damage

caused or alleged to be caused directly or indirectly by the goods including, but not limited

to, any indirect, special, consequential, or incidental damages resulting from the use or

operation of the goods or any breach of this warranty. Notwithstanding the above

limitations and warranties, the manufacturer’s liability hereunder for damages incurred by

the purchaser or others shall not exceed the price of the goods.

3.4.

No action arising out of any claimed breach of this warranty or transactions under this

warranty may be brought more than one (1) year after the cause of the action has

occurred.

MISCELLANEOUS

4.1.

The manufacturer may waive compliance with any of the terms of this limited warranty,

but no waiver of any terms shall be deemed to be a waiver of any other term.

4.2.

If any provision of this limited warranty shall violate any applicable law and is held to be

unenforceable, then the invalidity of such provision shall not invalidate any other

provisions herein.

4.3.

Applicable law may provide rights and benefits to the purchaser in addition to those

provided herein.

Spearhead TWIGA COMPACT

Contents

General Information

EC Declaration of conformity 1

Warranty 2

Introduction 8

Specification 9

Safety

Safety Recommendations 10

Overhead Power Lines 12

Safety Decal 14

Warning Signs 14

Roadwork Guidelines 14

Training 15

Tractor Requirements 15

Installing your Machine

Attaching To The Tractor 16

Running Up Your Machine 20

Removing From The Tractor 20

Cable Controls 21

MINIPILOT Controls 22

Operational Warnings 27

Operation 28

Cutter Bar 29

Oil Cooler 30

Servicing & Maintenance

Lubrication 31

Torque Settings 32

Hydraulic Hoses 33

Oil Supply 34

Filtration Maintenance 34

Pins & Bushes 35

Regular Service Chart 36

Pump & Motor Failure 36

Spearhead TWIGA COMPACT

Introduction

The TWIGA is a very robust high capacity reach mower that is easy to operate and

maintain. To ensure trouble-free operation this manual should be carefully studied.

The term Left and Right hand applies to the machine when coupled to the tractor

and viewed from the rear, this also applies to the tractor.

Important Note

The information contained in this manual is correct at the time of publication.

However, in the course of constant development, changes in specification are

inevitable. Should you find the information given in this book different to the

Machine it relates to please contact the “After Sales Department” for advice.

Please ensure that this manual is handed to the operator before using the

machine for the first time. The operator must fully understand the contents

of this manual before using this machine.

(If the machine is resold the Manual must be given to the new owner.)

Spearhead TWIGA COMPACT

Specification

320

420

360

460

Weight inc. Oil (Kg)

1350

1370

1350

1370

Weight of head (Kg)

130

Tractor horse power

Min. tractor weight (Kg)

1300

2000

1300

2000

Oil tank capacity (ltr)

Reach A (m)

3.2

4.2

3.6

4.6

Reach B (m)

3.3

4.3

3.3

4.3

Reach C (m)

2.1

3.1

2.1

3.1

Reach D (m)

3.8

4.8

3.8

4.8

Reach E (m)

2.8

3.8

2.8

3.8

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cortacésped de Spearhead

Spearhead

Spearhead RHD OPEN Series Manual de usuario

Spearhead

Spearhead EXCEL 470 Manual de usuario

Spearhead

Spearhead Q15S Manual de usuario

Spearhead

Spearhead RHD Series Manual de usuario

Spearhead

Spearhead AGRICUT 180 Manual de usuario

Spearhead

Spearhead MULTICUT 460 Manual de usuario

Spearhead

Spearhead RHD OFFSET 160 Manual de usuario

Spearhead

Spearhead RHD OPEN Series Manual de usuario

Spearhead

Spearhead STARCUT 730 Manual de usuario

Spearhead

Spearhead Twiga Series Manual de usuario

Spearhead

Spearhead XRHD 250 Manual de usuario

Spearhead

Spearhead TWIGA 320 Manual de usuario

Spearhead

Spearhead R130 Manual del producto

Spearhead

Spearhead ROLLIFLAIL 150 Instrucciones de montaje

Spearhead

Spearhead 15 Park Manual de instalación y operación

Spearhead

Spearhead RHD 160 Manual de usuario

Spearhead

Spearhead ROLLICUT 170 Manual de usuario

Spearhead

Spearhead R Series Manual de usuario

Spearhead

Spearhead AGRICUT 180 Instrucciones de montaje

Spearhead

Spearhead ORBITAL S63 Manual de usuario

Spearhead

Spearhead Q15S Manual de instalación y operación

Spearhead

Spearhead Rollicut 500 Manual de usuario

Spearhead

Spearhead Multicut 300 Instrucciones de montaje

Spearhead

Spearhead Excel 606 Manual de usuario

Manuales populares de Cortacésped de otras marcas

RHINO

RHINO 1958 Manual de usuario

Wolf Garten

Wolf Garten Compact plus 40 B Manual de usuario

Cub Cadet

Cub Cadet LTX 1045 Manual de usuario

Craftsman

Craftsman 917.378461 Manual de usuario

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manual de usuario

Challenge

Challenge CH18V2 Instrucciones de operación

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manual de usuario

DEWEZE

DEWEZE ATM-725 Manual de operación

Weed Eater

Weed Eater 180083 Manual de usuario

Husqvarna

Husqvarna Poulan Pro PP185A42 Manual de usuario

Better Outdoor Products

Better Outdoor Products Quick Series Manual de usuario

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manual de funcionamiento

MTD

MTD 795, 792, 791, 790 Manual de usuario

Toro

Toro Groundsmaster 3505-D Manual de usuario

Dennis

Dennis FT 610 Manual de usuario

AIRFORCE

AIRFORCE F-15 Gen 3 Manual de usuario

MTD

MTD 126-220-000 Manual de usuario

Toro

Toro 74806 Manual de usuario
