Spacerails LEVEL 4 Manual de usuario
LEVEL 4
PRODUCT AND CONSUMER WARNING
CHOKING HAZARD: This product contains small parts and is not intended for children under 3.
• This product is intended for users 8 years of age and older.
• To avoid choking, keep small parts away from children.
• Use caution—this product contains parts with sharp edges.
• To avoid potential damage to the product, only insert the included marbles into the elevator.
Page 2 Seaich Corporation, LLC. All rights reserved. www.seaich.com |Spacerails, LLC. www.spacerails.com
PARTS INCLUDED
Keep parts together to avoid misplacing them.
ARM COMPONENTS
Arm Clip
x56
Arm Sheath
x60
Arm Holder A
x56
Arm Holder B
x62
Arm Lock
x118
RAIL COMPONENTS
Rail Coupling
x10
Marble
x4
Rail
26,000 mm
REQUIRED TOOLS & ITEMS (NOT INCLUDED)
Wire Cutters or Utility Scissors
Pen or Marker
3 AA Batteries (newer models) or 1 C Battery
Ruler (in centimeters)
Rail Clip
x70
SPLIT, SEE-SAW, AND START BLOCK COMPONENTSBASE COMPONENTS
Base Base Holder A Base Holder B
x9 x4 x6
Rail Splitter
x1
Start Block
x1
Start Block
Cover
x1
See-Saw Arm
x3
ELEVATOR COMPONENTS
Elevator Helix
x12
Elevator Ring
x3
Elevator Cover
x1
Elevator Guard
x4
Power Box Stand
x1
Power Box
x1
Shaft (300mm)
x16
Shaft (200mm)
x5
Shaft Connector (90mm)
x1
Shaft Connector (50mm)
x1
Seaich Corporation, LLC. All rights reserved. www.seaich.com |Spacerails, LLC. www.spacerails.com Page 3
A
B
ARM ASSEMBLY (QTY: 66 SHAFT TO RAIL)
RAIL SPLITTERS
1PREPARE THE COASTER COMPONENTS
Step 1: Attach one Arm Holder A and one
Arm Holder B with one Arm Sheath.
Step 2: Insert one Arm Clip into Arm
Holder A. Slide the circular part between
the matching parts on the Arm Holder.
Step 1: Attach one Rail Clip on each of
the Rail Splitter posts.
Step 4: Turn the Arm Lock
counter-clockwise to secure the
ArmClip in place.
Step 3: Insert Arm Lock through Arm
Holder A and Arm Clip. Ensure that the
tab is facing up.
To avoid damaging parts, do not move or adjust the Rail Clip while locked in the arm. To move the Rail Clip, release
Arm Lock by turning clockwise, position Rail Clip as desired, then secure Arm Lock again.
NOTE:
The hole shapes of the Arm Holder
and Arm Sheath dier.
Arm Holder B Arm Holder A
Page 4 Seaich Corporation, LLC. All rights reserved. www.seaich.com |Spacerails, LLC. www.spacerails.com
C
D
SEE-SAW ASSEMBLY
BASE ASSEMBLY
Step 1: Cut 2 rails to 55mm. Insert 1 rail into
each hole on the See-Saw.
Step 2: Insert the See-Saw Arm and the rails into
the Rail Clip. You may need to adjust the See-Saw
after installing it as it may have shifted.
Step 3: Insert See-Saw into Arm Holder B. Step 4: Insert the See-Saw into the Rail Stand
(300mm Shaft). See shaft assembly on page8
for exact placement.
See-Saw Arm
Rail Clip
55mm rail pieces
Step 1: Interlock Base block tabs
as shown below.
Step 2: Press Base Holder A and
Base Holder B pieces into the Base
blocks for a more secure hold.
1
2
2
NOTE:
Base Holder B is used
here instead of A.
Seaich Corporation, LLC. All rights reserved. www.seaich.com |Spacerails, LLC. www.spacerails.com Page 5
Step 3: Once the Corkscrew is
built, attach three support shafts
(300mm) to the Power Box.
EELEVATOR ASSEMBLY
Step 2: Connect Elevator Helix
pieces together with the male part
facing up to ll the shaft.
NOTE:
Install the rst Elevator
Helix piece male side
up and rotate it until
it slides in place and
engages with driver at
the base of Power Box.
Step 1: Place a shaft in the
white hole on the Power Box.
Step 6: Place the Elevator Cover
onto the top of the elevator
assembly.
Step 7: Attach an Elevator Guard to
each of the Elevator Rings, then to
the right side of the Rail Clip.
Step 5: Place the three Elevator
Rings over the three shafts.
NOTE:
The Marble may fall
out of the elevator if it
enters too fast.
Step 4: Connect
one Rail Clip to each
Elevator Ring. Install
Elevator Ring with
tabs facing up, as
shown above.
Page 6 Seaich Corporation, LLC. All rights reserved. www.seaich.com |Spacerails, LLC. www.spacerails.com
F
G
STARTER ASSEMBLY
SHAFT ASSEMBLY
Step 1: Connect Arm Holder B to
300mm Shaft. Insert Arm Lock.
Step 4: Attach Rail Clips and
Start Block Cover to Starter.
Step 1: Slide Arm Holder B of each arm on
to a shaft and lock in place with Arm Lock.
Refer to the next page for orientation and
location of each arm.
This is how the pieces are
referenced on the shaft drawings.
Arm
Arm Holder B
See-Saw
Step 2: Connect the Starter pegs
to the Arm Holder.
Step 3: Ensure the Starter is at
a slight angle so the Marble will
run smoothly.
NOTE:
Please see the included full-size drawings for the next
several steps. This will simplify the positioning of base,
arms, shafts, and the rail cut lengths.
Seaich Corporation, LLC. All rights reserved. www.seaich.com |Spacerails, LLC. www.spacerails.com Page 7
Step 2: Attach each Arm and See-Saw Arm as shown in step 1 with the orientation
and location shown here. In later steps the letter of each Shaft and number of each
Arm will guide in the installation of the Rails. Illustration is approximately 51% of
actual size. All Shaft measurements are in Millimeters.
200 200 200
104
124
140
117
68
54
33
300
41
225
88
300
149
103
62
47
21
247
300
102
264
300
71
51
276
300
256
300
113
278
Page 8 Seaich Corporation, LLC. All rights reserved. www.seaich.com |Spacerails, LLC. www.spacerails.com
Step 2 Continued
300 300 300 300 300300
110
67 72
24
55
79 80
111
123
119
78
107
135
162
199
115
161
168
216
201 203
240
208
226
216
258
241
277 283
281
200 200
109
60
99
141
185
Seaich Corporation, LLC. All rights reserved. www.seaich.com |Spacerails, LLC. www.spacerails.com Page 9
HINSTALLING SHAFTS INTO BASE
Start Block
Shaft Stand
Shaft Stand
LEFT
RIGHT
FRONTBACK
Step 3: Place shafts and elevator into base.
Push shaft into holes on base until sturdy.
Attach Power Box Stand to the Power Box.
Firmly seat the posts from the Power Box in
the holes on the base.
Step 4: Attach Shaft Connector (90mm) to
Shafts K and N. Attach Shaft Connector (50mm)
to Shafts F and G.
Page 10 Seaich Corporation, LLC. All rights reserved. www.seaich.com |Spacerails, LLC. www.spacerails.com
CUT THE RAIL TO SIZE
Step 1: Measure each section and mark the cutting point with a pen.
Step 2: Cut each section according to your measurement. Make sure
to cut at a 90° angle.
Tip: To help avoid do-overs and using too much rail, cut generously
(slightly longer than required) to begin with. You can always cut a
long rail shorter.
NOTES:
Illustration of rail lengths is
approximately 5% in scale.
Measure carefully and use a tape
measure for longer segments.
See included insert for rail
measurements in 1:1 scale.
G
300cm
A
5cm
B
45cm
45cm
C
200cm
200cm
D
E
F
G
350cm
