Southworth PalletPal Stack-n-Go FPS3000-43 NAS Manual de usuario
OWNER’S MANUAL
Model # ______________________________________
Serial # ______________________________________
Date placed in Service __________________________
SOUTHWORTH PRODUCTS CORP
P.O. Box 1380 • Portland, ME 04104-1380
Telephone: (207) 878-0700 or (800) 743-1000
Fax: (207) 797-4734
www.SouthworthProducts.com
Email: [email protected]
PalletPal Stack-n-Go
Model FPS3000-43 NFO-21
Model FPS3000-43 NFO-27
For models that do not have GC or ST stamped into the mast
September 2019
2 Southworth PalletPal Stack-n-Go / FPS3000-43NFO-21/27
PalletPal Stack-N-Go
Please note:
This manual was current at the time of printing.
To obtain the latest, most updated version, please contact
Southworth’s Customer Service Department or go to our website:
www.SouthworthProducts.com, under Parts & Service
you will nd a complete list of current
owner’s manuals to print.
Southworth PalletPal Stack-n-Go / FPS3000-43NFO-21/27 3
SOUTHWORTH
TABLE OF CONTENTS
INTRODUCTION............................................................................................................. 5
RESPONSIBILITY OF OWNERS AND USERS .............................................................. 6
Safety Alert Symbols and Signal Words ........................................................................... 7
SAFETY PRECAUTIONS ................................................................................................ 8
INSTALLATION INSTRUCTIONS .................................................................................. 10
Inspection .......................................................................................................... 10
Removal from Pallet .......................................................................................... 10
Preparation for Use ............................................................................................ 10
Battery ................................................................................................................ 10
OPERATOR INSTRUCTIONS ....................................................................................... 11
Suggested Daily Operator Checklist................................................................... 13
BATTERY MAINTENANCE & CHARGING .................................................................... 14
MAINTENANCE ............................................................................................................ 15
TROUBLESHOOTING ................................................................................................... 16
STACKER BODY COMPONENTS................................................................................. 17
CABINET ASSEMBLY .................................................................................................... 18
MAST ASSEMBLY.......................................................................................................... 19
STEERING ASSEMBLY ................................................................................................. 20
CONTROL POD ............................................................................................................. 21
DRIVE WHEEL ASSEMBLY........................................................................................... 22
POWER UNIT ASSEMBLY............................................................................................. 23
CYLINDER ASSEMBLY ................................................................................................. 24
ELECTRICAL DIAGRAM................................................................................................ 25
BATTERY CONNECTION DIAGRAM ............................................................................ 26
LABEL LOCATION DRAWING ....................................................................................... 27
ORDERING REPLACEMENT PARTS ........................................................................... 28
WARRANTY STATEMENT ............................................................................................ 29
4 Southworth PalletPal Stack-n-Go / FPS3000-43NFO-21/27
PalletPal Stack-N-Go
Southworth PalletPal Stack-n-Go / FPS3000-43NFO-21/27 5
SOUTHWORTH
INTRODUCTION
This manual attempts to provide all of the information necessary for the safe and
proper installation, operation and maintenance of the Southworth Products battery
operated, PalletPal Stack-n-Go. It is important that all personnel involved with the
installation, maintenance or operator of the stacker read this manual. Additional
manuals are available upon request or at www.SouthworthProducts.com.
Each Southworth stacker is equipped with nameplate, serial number and model
identications. Please refer to these numbers when ordering parts or requesting
further information.
This Southworth stacker is designed for lifting, lowering and positioning a wide
variety of loads. WHERE UNIQUE SITUATIONS ARISE, WHICH ARE NOT COV-
ERED IN THIS MANUAL, CALL SOUTHWORTH PRODUCTS FOR FURTHER
INSTRUCTIONS.
The battery operated stackers are designed for dry in-plant/non-hazardous locations
only. They can be used in a 8' or larger aisle. These units are not for personnel
lifting.
6 Southworth PalletPal Stack-n-Go / FPS3000-43NFO-21/27
PalletPal Stack-N-Go
Responsibility of Owners and Users
Inspection and Maintenance
The device shall be inspected and maintained in proper working order in accordance with
Southworth’s owner’s manual.
Removal from Service
Any device not in safe operating condition such as, but not limited to, excessive leakage, miss-
ing rollers, pins, or fasteners, any bent or cracked structural members, cut or frayed electric or
hydraulic lines, damaged or malfunctioning controls or safety devices, etc. shall be removed
from service until it is repaired to the original manufacturer’s standards.
Repairs
All repairs shall be made by qualied personnel in conformance with Southworth’s instructions.
Before Operation
Before using the device, the operator shall have:
• Read and/or had explained, and understood, the manufacturer’s operating instructions
and safety rules.
• Inspected the device for proper operation and condition. Any suspect item shall be care-
fully examined and a determination made by a qualied person as to whether it con-
stitutes a hazard. All items not in conformance with Southworth’s specication shall be
corrected before further use of the equipment.
During Operation
The device shall only be used in accordance with this owner’s manual.
• Do not overload.
• Ensure that all safety devices are operational and in place.
Modications or Alterations
Modications or alterations to any Southworth industrial positioning equipment shall be made
only with written permission from Southworth.
Southworth PalletPal Stack-n-Go / FPS3000-43NFO-21/27 7
SOUTHWORTH
CERTIFIED OPERATOR TRAINING
You must be trained and certied to operate this powered stacker. Federal law states that only properly
trained operators are permitted to operate a powered industrial stacker and that your employer must train
you and certify that you are qualied. (OSHA 1910.178 29QFR-7-1-06 Edition)
Southworth does not offer operator training. Operator training programs may be offered by your local
Southworth dealer or obtained online. Enter, "powered industrial truck operator training" into a search
engine.
SAFETY ALERT SYMBOLS AND SIGNAL WORDS
The safety of all persons operating, maintaining, repairing, or in the vicinity of this equipment is of paramount
concern. This is a powerful machine with moving parts, and is capable of causing personal injury if proper precautions
are not taken. Therefore, throughout this manual, certain hazards have been identied which may occur in the use
of the machine, and there are appropriate instructions or precautions which should be taken to avoid these hazards.
In some cases, there are consequences which may occur if instructions or precautions are not followed. Below are
the symbols and signal words along with their denitions referenced from ANSI Z535.4 - Product Safety Signs
and Labels.
Safety Alert Symbols
These are the safety alert symbols.. They are used to alert you to potential physical injury haz-
ards. Obey all safety messages that follow this symbol to avoid possible injury or death.
For use with DANGER signal word
(Red Background)
For use with WARNING signal word
(Orange Background)
For use with CAUTION signal word
(Yellow Background)
Signal Words
The meaning of different signal words as dened by ANSI Standard Z535.4 indicates the relative
seriousness of the hazardous situation.
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION, used with the safety alert symbol, indicates a haz-
ardous situation which, if not avoided, could result in minor or
moderate injury.
NOTICE is used to address practices not related to personal
injury.
(Red Background)
(Orange Background)
(Yellow Background)
(Blue Background)
SAFETY
INSTRUCTIONS
SAFETY INSTRUCTIONS (or equivalent) signs indicate safety-
related instructions or procedures.
(Green Background)
8 Southworth PalletPal Stack-n-Go / FPS3000-43NFO-21/27
PalletPal Stack-N-Go
The battery operated stackers are very powerful lifts
capable of doing large amounts of work.
DO NOT OPERATE THESE LIFTS WITHOUT
CAREFULLY READING THIS MANUAL. In order
to provide for the safe operation of these stackers,
Southworth has identied certain hazards that may oc-
cur during the maintenance and use of these lifts. For
safety reasons these units are designed to be serviced
or repaired in the fully lowered position. If performed
properly, this will greatly reduce the possibility of
injury.
WARNING!
When servicing the unit:
1. Key should be in "OFF" position.
2. E-stop should be depressed.
3. Disconnect the batteries at the terminals.
• Do not perform any repair work on lifts if
there is a load on the forks or platform.
• Do not perform any repair work if the forks
or platform is in the raised position.
• All personnel must stand clear of the lift
while in motion.
• Do not put hands or feet under the forks or
platform.
• Do not stand underneath the forks or plat-
form.
• Do not stand in front of the stacker while in
motion.
• Do not stand, sit or climb on the lift.
• Do not use the lift on soft, uneven or unstable
surfaces.
• Do not exceed the load center or capacity.
WARNING!
You or others around you can be seriously injured
or even killed if you don't use this stacker correctly.
Read and obey all warnings and instructions in this
manual and on the stacker. It is your responsibil-
ity before starting work to make sure it is in good
working order.
Always be alert to the area around you and watch where
you are walking. Be careful that you don't get pinned
or crushed between the stacker and a xed object such
as a wall or post.
• Watch your hands and feet. A foot or hand
caught between the stacker and a xed object will
be crushed or even cut off.
• If traveling forks rst, keep both hands on
the control handle and be careful when changing
direction of travel. Keep your feet clear of the
stacker.
• Keep the stacker under control at all times.
Operate at a speed that allows you to stop safely.
Be even more careful on slippery or uneven sur-
faces. Do not run over objects on the oor.
• Perform all stacker movements smoothly and
at a speed that will give you time to react if an
emergency occurs.
Tipovers and falls are very serious accidents; you can
be crushed or even killed. To prevent injury, know
where you are at all times and follow the rules of safe
stacker operation.
• Be careful when working around docks,
dockboards and trailers. Stay away from the
edge of docks and ramps. Check to make sure the
wheels of truck or trailers are chocked.
• Travel with the load or forks close to the
ground. Watch for overhead obstructions. Per-
form all stacker movements smoothly and at a
speed that will give you time to react in an emer-
gency.
• Keep your hands and feet away from all mov-
ing parts such as masts, chains, forks or wheels.
• Never stand on or under the forks, or allow
anyone else to stand on or under them. Never ride
on the stacker or allow anyone else to ride. There
is no safe place to sit or stand.
• Before you leave your stacker, be sure to
lower the forks to the oor. Shut the stacker off
with the key.
Southworth PalletPal Stack-n-Go / FPS3000-43NFO-21/27 9
SOUTHWORTH
WARNINGS
DO NOT use this stacker until you have been trained
and authorized to do so.
DO NOT operate until you have read all warnings and
instructions.
DO NOT exceed load center or load weight capacities
(check capacity plate).
DO NOT operate until you have checked the conditions
of the stacker: lift systems, forks, chains, and cables.
DO NOT use if any part is damaged, worn or not work-
ing properly.
DO NOT use on ramps or inclines. Only smooth level
surfaces.
DO NOT use for lifting or carrying people.
DO NOT handle unbalanced, unstable or loosely
stacked loads.
DO NOT travel with forks or platform in an elevated
position.
DO NOT handle tall, unsecured or unstable loads that
could fall.
DO NOT allow people to stand or pass under forks or
platform with or without load.
DO NOT operate when parts of anyone’s body may be
close to mast structure or any moving parts.
DO NOT drop loads on platform or forks.
DO NOT alter or modify this stacker in any way.
10 Southworth PalletPal Stack-n-Go / FPS3000-43NFO-21/27
PalletPal Stack-N-Go
INSTALLATION
A. INSPECTION:
Upon receipt of the stacker, inspect the equipment com-
pletely to determine if there is any shipping damage, and
that the lift is complete. Southworth tests and inspects
every piece of equipment prior to shipment. If damage
is apparent, a freight claim must be led with the freight
company. Do not use the stacker if there appears to be
any damage. With the stacker in a lowered position,
check the following:
• Check for signs of damage especially to the
back cabinet that houses the battery, electrical/
hydraulic power pack.
• Check all electrical and hydraulic connec-
tions for tightness.
• Remove back panel.
1. Turn key switch to "OFF" position.
2. Push in E-stop and unscrew the red knob,
3. Lift off back panel. There is enough wire
to the key switch to allow the panel to be set
aside.
• Inspect for any bent or damaged parts.
B. REMOVING FROM PALLET
Each of the Southworth stackers is shipped out on a
pallet or skid. Prior to removing the unit from the pal-
let or skid, remove all tie down straps and packaging.
Visually inspect the unit as closely as possible.
With an overhead hoist or forklift, carefully pick up the
unit taking into consideration the center of gravity of the
unit. If you choose to pick the unit with an overhead
hoist, use a nylon sling and hoist with a minimum of
2,000-lb. capacity. The nylon sling will not do any dam-
age to the steel construction of stacker. Pick the unit
up. On conventional masts use the top crossmember of
the lift. On narrow masts the cover must be removed
to access lifting equipment. Be careful of the stacker
swinging once fully lifted off the pallet or skid. Have
all personnel completely cleared from the area.
Pick the unit up approximately six inches above the
pallet or skid. Once raised, remove the pallet or skid
from below the lift. Do not move the lift around in the
air. Lower the stacker on the ground.
C. PREPARATION FOR USE
This stacker left our factory in new condition. It has been
inspected and weight tested to assure all performance
standards have been met.
Visually inspect the stacker for damage. Check for at-
tachments and accessories that may have been ordered.
If there is any damage or missing parts, report it to your
carrier and your Southworth dealer immediately.
Remove all metal/plastic bands, cardboard and other
material used for shipping purposes.
Check to see if chains are in place, and that the lift sys-
tem is in working order. Inspect for oil leaks.
Connect battery cable. Check cables and wires on bat-
tery charger as well as battery.
Figure 1: Operational buttons BELLY BUTTON SWITCH
LIFT UP
LIFT DOWN
HORN
SPEED CONTROL
DIRECTION CONTROL
