SoundMax SM-CMD3000 Manual de usuario

SM-CMD3006

MULTIMEDIA DVD/CD/MP3 RECEIVER WITH BUILT-IN 4” TFT DISPLAY

AND TV TUNER

Instruction manual

МУЛЬТИМЕДИЙНЫЙ DVD/CD/MP3-РЕСИВЕР СО ВСТРОЕННЫМ 4” TFT-

ДИСПЛЕЕМ ИТВ-ТЮНЕРОМ

Руководство по эксплуатации

Dear customer!

Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully

before connecting, operating and/or adjusting the product and keep the manual for reference in the future.

Table of contents

Table of contents............................................................................................................................ 2

Important safeguards ..................................................................................................................... 3

Installation/connection ................................................................................................................... 4

Panel controls................................................................................................................................ 9

General operation ........................................................................................................................ 16

Digital tuner................................................................................................................................ 18

Disc operations............................................................................................................................ 20

MP3 overview .............................................................................................................................. 27

System setup menu ..................................................................................................................... 28

TV Operation ............................................................................................................................... 31

Anti-theft system ......................................................................................................................... 32

Handling discs ............................................................................................................................. 33

Troubleshooting guide................................................................................................................... 34

Specification................................................................................................................................ 35

Important safeguards

- Using the device at temperature below -10ºСmay cause the breakage of the device. BEFORE USING

PLEASE HEAT UP THE PASSENGER COMPARTMENT TO THE RECOMMENDED TEMPERATURE!

- Read carefully through this manual to familiarize yourself with this high-quality sound system.

- Disconnect the vehicle's negative battery terminal while mounting and connecting the unit.

- When replacing the fuse, be sure to use one with an identical amperage rating. Using a fuse with a

higher amperage rating may cause serious damage to the unit.

- DO NOT attempt to disassemble the unit. Laser beams from the optical pickup are dangerous to the

eyes.

- Make sure that pins or other foreign objects do not get inside the unit; they may cause malfunctions, or

create safety hazards such as electrical shock or laser beam exposure.

- If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car

becomes normal before operating the unit.

- DO NOT open covers and do not repair yourself. Consult the dealer or an experienced technician for

help.

- Make sure you disconnect the power supply and aerial if you will not be using the system for a long

period or during a thunderstorm.

- Make sure you disconnect the power supply if the system appears to be working incorrectly, is making

an unusual sound, has a strange smell, has smoke emitting from it or liquids have got inside it. Have a

qualified technician check the system.

- The unit is designed for negative terminal of the battery, which is connected to the vehicle metal.

Please confirm it before installation.

- Do not allow the speaker wires to be shorted together when the unit is switched on. Otherwise it may

overload or burn out the power amplifier.

Installation/connection

First complete the electrical connections, and then check them for correctness.

Installation way

It is an anti-theft installation way. The chassis wear a metal sliding housing. Please have the wiring

connection of the power supply, speakers and antenna as for the requirement of the manual, and then

install the metal sliding housing into the car according to the diagram.

Detachable control panel

Detaching the front panel

Press the REL button to remove the panel.

Attaching the control panel

1. Insert the left side of the control panel into the main unit.

2. Press the control panel on to the right side of middle of it until a “click” sound is heard.

Caution:

DO NOT insert the control panel from the right side. It can damage the control panel.

The control panel can easily be damaged by shocks. After removing it, place it in a protective case and be

careful not to drop it or subject it to strong shocks.

The rear connector that connects the main unit and the control panel is an extremely important part. Be

careful not to damage it by pressing on it with fingernails, pens, screwdrivers, etc.

Note:

If the control panel is dirty, wipe off the dirt with soft, dry cloth only. And use a cotton swab soaked in

isopropyl alcohol to clean the socket on the back of the control panel.

Electrical connection

Notes:

1. Only speakers with 4 ohms impedance

may be used.

2. Ensure that the blue auto antenna cable

does not make contact with any ground

connection.

Caution: Do not interchange the connection of the wiring!!!

For some car models you may need to modify wiring of the supplied power cord. Contact your authorized

car dealer before installing this unit.

Using the ISO Connector

1. If your car is equipped with the ISO connector, then connect the ISO connectors as

illustrated.

2. For connections without the ISO connectors, check the wiring in the vehicle

carefully before connecting, incorrect connection may cause serious damage to this

unit.

3. Cut the connector, connect the colored leads of the power cord to the car battery

as shown in the color code table below for speaker and power cable connections.

Function

№Connector A №Connector B

1 7 Rear Right(+)---Violet

2 8 Rear Right(-)---Violet /Black Stripe

3 9 Front Right(+)---Gray

4 Battery 12V (+)/yellow 10 Front Right(-)---Gray/Black Stripe

5 Auto Antenna/blue 11 Front Left(+)---White

6 12 Front Left((-)---White/Black Stripe

7 ACC+/red 13 Rear Left(+)---Green

8 Ground/black 14 Rear Left(-)---Green/Black Stripe

Panel controls

Front panel

1. PWR/MU button

Press PWR/MU button to turn the power on, press and hold for 2 seconds to turn the power off.

When the power is on press it to cut down the volume output, press it again to resume volume.

2. ANG button

Use it to adjust the panel angle.

3. REL button

Press it to detach the front panel.

4. MOD button

Press it to select the mode: =>TUNER (radio) => DISC (the type of disc in the unit) => USB =>

SD/MMC => AUX => TV=>.

5. In TUNER mode press the TA button to activate/deactivate the Traffic announcement function.

6. VOL knob+/-/ SEL button.

Rotate VOL knob clockwise to increase the volume level; rotate anticlockwise to decrease the volume

level.

Press SEL repeatedly to select the modes: => VOL => BAS => TRE => BAL => FAD =>.

Rotate VOL knob to adjust each mode.

7. In TUNER mode press the AF button to activate/deactivate the Alternative frequencies function.

8. TFT display

9. Infra red sensor

10. BND button

In TUNER mode press it repeatedly to select your desired radio band.

In DVD mode press it to choose TV mode: => PAL => PAL -M => PAL –N => AUTO => NTSC =>.

11. UP/DN buttons

In Disc mode press the UP/DN buttons to go to the next/previous track. Press and hold for 2 seconds to

start fast forward/backward playing.

In TUNER mode press the UP/DN buttons to start manual stations searching. Press and hold for 2

seconds the UP/DN buttons to start automatic stations searching.

12. APS button

In Tuner mode press it to scan the preset memorized stations. Press it and hold for 2 seconds to store

the programs with the best reception into preset buttons automatically.

13. EJECT button

Press it to slide the panel down and eject the disc.

14. 1/PLAY/PAUSE button

In Tuner mode use it as tuner preset button.

In Disc mode press it to start playback. Press during playback to pause it. Press again to resume.

15. 2/INT button

In Tuner mode use it as tuner preset button. In Disc mode press it to start Intro playing.

16. 3/RPT button

In Tuner mode use it as tuner preset button. In Disc mode press it to start repeat playing.

17. 4/RDM button

In Tuner mode use it as tuner preset button. In Disc mode press it to start random playing.

18. 5/-10 button

In Tuner mode use it as tuner preset button. In MP3/WMA mode, long press it to go to the last 10

track.

19. 6/+10 button
