SOUNDMASTER SCD 6600 Manual de usuario

English - 1

1. FUNCTION SWITCH

AUX/CD/TAPE (OFF)/RADIO

2. BAND SWITCH

3. FM ANTENNA

4. CD DOOR

5. TUNING KNOB

6. BASS BOOST BUTTON

7. CD SKIP/SEARCH FORWARD

BUTTON

8. CD SKIP/SEARCH BACKWARD

BUTTON

9. CD PROGRAM BUTTON

10. CD MODE BUTTON

11. CD STOP BUTTON

12. CD PLAY/PAUSE BUTTON

13. CD LCD DISPLAY

14. STEREO HEADPHONE JACK

15. VOLUME CONTROL KNOB

16. AC SOCKET

17. BATTERY DOOR

18. FM STEREO LED INDICATOR

19. CASSETTE COMPARTMENT

20. CASSETTE RECORD BUTTON

21. CASSETTE PLAY BUTTON

22. CASSETTE REWIND BUTTON

23. CASSETTE FAST FORWARD

BUTTON

24. CASSETTE STOP/EJECT BUTTON

25. CASSETTE PAUSE BUTTON

26. SPEAKER LEFT

27. SPEAKER RIGHT

28. FOLDER UP BUTTON “”

29. FOLDER DOWN BUTTON “”

30. AUX IN JACK

English - 2

AC OPERATION

Before operation please be sure that the voltage on the set corresponds to

the voltage of your local area. Unravel the AC Line Cord, insert one end into

the AC jack on the set, and the other end into a standard AC outlet.

BATTERY OPERATION

Disconnect the AC Cord Set completely. Open the BATTERY DOOR and insert

UM-2/ “C” size x 8 batteries (not supplied) making sure that the indicated

battery polarity is observed.

RADIO OPERATION

Slide the FUNCTION SWITCH to the “RADIO” position. Slide the BAND

SWITCH to the desired waveband. Turn the TUNING KNOB to your desired

radio station. Adjust the sound level by rotating the VOLUME CONTROL KNOB.

To turn off the radio, simply slide the FUNCTION SWITCH to “TAPE (OFF)”

position.

Note : Radio frequency is shown on the TUNING KNOB.

FM STEREO INDICATOR

When tuned to a FM Stereo broadcast the “FM ST. LED INDICATOR” will light

up. In weak signal areas the FM Stereo signal may not be strong enough and

can cause excessive background noise. In this case, switch the BAND

SWITCH to “FM” position.

ANTENNAS

For best reception, fully extend the FM ANTENNA to receive FM stations. For

AM reception, the unit has a built-in antenna, turn the whole unit for best

reception.

BASS BOOST

For increased bass at all volume levels, slide the BASS BOOST BUTTON to

“ON” position to boost the low frequency tone for an emphasized bass sound.

To release the super bass, simply slide the button to “OFF” position.

AUXILIARY (AUX) MODE

1. Slide the FUNCTION SWITCH to the “AUX” position.

2. Connect the earphone socket from the Auxiliary unit (e.g. MP3 player or

MD player) into AUX-IN jack on the rear of this product via an Audio Line

Cord (3.5mm plug on both ends; not supplied).

3. Play the Auxiliary unit. Music from the Auxiliary unit can be listened

through the speaker of this product.

English - 3

STEREO HEADPHONE JACK

For private listening, insert the plug of a Stereo Headphone into the STEREO

HEADPHONE JACK and adjust the VOLUME CONTROL KNOB accordingly.

During the use of a headphone, the Speakers are automatically disconnected.

CASSETTE OPERATION

Tape Playback

Depress the STOP/EJECT BUTTON to open the cassette door. Insert a

cassette tape into the CASSETTE COMPARTMENT and push the cassette door

to close. Slide the FUNCTION SWITCH to TAPE position. Depress the PLAY

BUTTON. Adjust the VOLUME CONTROL KNOB to your desired listening level.

To stop the tape, depress the STOP/EJECT BUTTON.

Fast Forward and Rewind

The tape can be FAST FORWARDED or REWOUND by depressing the FAST

FORWARD BUTTON or REWIND BUTTON respectively.

Pause Function

During playback or recording, the tape can be stopped temporarily by

depressing the PAUSE BUTTON. To continue playback or recording, press the

PAUSE BUTTON once again.

Auto Stop System

When the tape runs to its end during playback or recording, the cassette

operation will be stopped automatically.

Caution

To avoid damage to the cassette mechanism or to the cassette tapes, always

depress the STOP/EJECT BUTTON between each operation!

Recording From The Radio

1. Tune to a desired radio program as described in the “RADIO

OPERATION” Section.

2. Insert a blank cassette tape into the CASSETTE COMPARTMENT.

3. Press the PAUSE BUTTON.

4. Press the RECORD BUTTON. The PLAY BUTTON is engaged

simultaneously to start recording. With the built-in Automatic Level

Control (ALC), the best recording quality is automatically adjusted.

Changing the volume level will not affect the recording. Release the

PAUSE BUTTON to begin recording.

5. To stop recording temporarily, press the PAUSE BUTTON. To continue

the recording, press the PAUSE BUTTON once again.

English - 4

6. Press the STOP/EJECT BUTTON to stop recording.

7. When the tape runs to its end, the cassette operation will be stopped

automatically.

CD OPERATION

PLAYING COMPACT DISC (CD-R/RW PLAYBACK COMPATIBLE)

Getting Started

Note: Should skipping of tracks occur during CD playing, try turning the

volume down.

When CD is playing, do not open the CD DOOR.

1. Open the CD DOOR by pull up the CD DOOR. Put a CD disc into the CD

Compartment and close the CD DOOR. Set the FUNCTION SWITCH to

“CD” position.

Note : Ensure the CD DOOR is closed properly

and locked in place.

2. When the CD DOOR is closed with a CD inside,

total number of the tracks in the disc will be shown

on the CD LCD DISPLAY and will go to stop mode.

(ex. Total 17 tracks inside the disc).

3. If there is no disc inside, the LCD DISPLAY will

show “ ” and go to stop mode.

4. If the CD DOOR is not closed, the DISPLAY will

show “ ”.

Play/Pause Mode

1. When the PLAY/PAUSE BUTTON is pressed during

CD stop mode, the first track will be played. The

Play Indicator “” will be shown on the LCD

DISPLAY. The CD LCD DISPLAY will show the

specific number of track being played.

2. For interruption while the CD is playing, press the

CD PLAY/PAUSE BUTTON once. The Play Indicator

“” will blink continuously on the LCD DISPLAY.

3. Though the sound stops, the disc will continue to

spin. To re-start playing, press the CD PLAY/PAUSE

BUTTON once again. The music will start from the

exact position where it was interrupted.

4. To stop the CD, press the CD STOP BUTTON once

whether the CD is in Play or Pause mode. The LCD DISPLAY will show the

total number of tracks of the disc again.

English - 5

5. To turn off the unit, slide the FUNCTION SWITCH to “TAPE (OFF)”

position.

Skip And Search Mode

1. During play or pause mode, when CD SKIP/SEARCH or CD

SKIP/SEARCH BUTTON is pressed once, it will go to the next track or

go back to the beginning of the track.

2. During play mode, when CD SKIP/SEARCH or CD SKIP/SEARCH 

BUTTON is pressed and held, it will search the track with audible high-

speed forward or backward playback.

Repeat Mode

1. Repeat 1 :

When the MODE BUTTON is pressed once, the

Repeat Indicator “ ” will be shown on the LCD

DISPLAY. This single track of music will be repeated.

2. Repeat All:

When the MODE BUTTON is pressed twice, the

Repeat All Indicator “ ” will be shown on the

LCD DISPLAY. The whole disc can be played

continuously.

3. To cancel the Repeat Function

Press the MODE BUTTON repeatedly until the

Repeat Indicator disappears from the LCD

DISPLAY.

Random Play Mode

This feature allows the track on the disc to be played in a random order.

1. During the CD stop mode, press the MODE BUTTON three times, the

“” indicator will be shown on the LCD DISPLAY and all music will

play in random order automatically.

2. To cancel the random play function, press the

MODE BUTTON again, “ ” Indicator will

disappear from the LCD DISPLAY.

Program Mode

1. During the CD stop mode, press the PROGRAM BUTTON once. The

Program Indicator “ ” and the number of Program to be memorized

starts from the first program “ ” will light up

and blink continuously.

Press the CD SKIP/SEARCH or SKIP/SEARCH 

BUTTON to your desired musical track, the CD LCD

English - 6

DISPLAY will show the appropriate track number. Press the PROGRAM

BUTTON to store this track in memory.

2. Repeat above procedure until all desired tracks have been programmed.

A total of 20 tracks can be stored in memory.

Remarks:

Whenever CD SKIP/SEARCH FORWARD or

BACKWARD BUTTON is pressed, it will always show

the last programmed track first to recall your

memory.

After complete programming, LCD DISPLAY will show “ ” and

flash continuously.

3. Press the CD PLAY/PAUSE BUTTON once to start

the program playback and the CD Play Indicator

“” will light up.

4. To check the program you have stored after

complete programming, press the PROGRAM BUTTON once during CD

stop mode, then press the CD SKIP/SEARCH FORWARD BUTTON once,

the LCD DISPLAY will show the first programmed track number. Repeat

above procedure to read all the programmed memory.

5. To cancel the programmed memory:

¾During the CD stop mode, press the CD STOP BUTTON once.

¾Open the CD DOOR during the CD stop mode.

The Program Indicator “ ” will disappear from the LCD DISPLAY.

PLAYING MP3 DISC

Getting Started

Note: Should skipping of tracks occur during MP3 Disc playing, try turning

the volume down.

When MP3 disc is playing, do not open the CD DOOR.

1. Open the CD DOOR by pull up the CD DOOR. Put a MP3 disc into the CD

compartment and close the CD DOOR. Set the FUNCTION SWITCH to

“CD” position.

Note : Ensure the CD DOOR is closed properly and locked in place.

2. When the CD DOOR is closed with a MP3 disc inside,

total number of the tracks in the disc will be shown

on the CD LCD DISPLAY and go to stop mode.

3. If there is no disc inside, the DISPLAY will show

“” and go to stop mode.

4. If the CD DOOR is not closed, the DISPLAY will

show “ ”.

English - 7

Play/Pause Mode

1. When the PLAY/PAUSE BUTTON is pressed during CD stop mode, the first

track will be played. The Play Indicator “”will be

lighted. The “ ” Indicator will be shown as well

to indicate MP3 Disc is being played. The LCD

DISPLAY will show the specific track number being

played.

2. To select the specific musical tracks inside the MP3 Disc.

MP3 music can be stored into CD Disc with or without folders according to

your “MP3 burning method”.

a. If the MP3 disc is downloaded without dividing into folder, all track

number will be shown

directly in the LCD

DISPLAY. The Album

number will only show

after pressing the

FOLDER UP or DOWN

BUTTON.

b. If the music is stored into different folders, then you’ve to select the

specific Album number first by pressing the FOLDER UP or DOWN

BUTTON; afterwards press the CD SKIP/SEARCH FORWARD or

BACKWARD BUTTON to select the specific Track number music inside

this Album.

example: To select Album # 4, track # 3.

STEP – 1: Press the FOLDER UP or DOWN

BUTTON to select the Album # 4.

STEP – 2: Press the CD SKIP/SEARCH

FORWARD or BACKWARD BUTTON

to select the Track # 3 inside this

Album # 4.

3. For interruption while MP3 disc is playing, press the

CD PLAY/PAUSE BUTTON once. The Play Indicator “” will blink

continuously on the LCD DISPLAY.

4. Though the sound stops, the disc will continue to spin. To re-start playing,

press the CD PLAY/PAUSE BUTTON once again. The music will start from

the exact position where it was interrupted.

5. To stop the MP3 disc, press the CD STOP BUTTON once whether the MP3

disc is in Play or Pause mode.

English - 8

6. To turn off the unit, slide the FUNCTION SWITCH to “TAPE (OFF)”

position.

Repeat Mode

1. Repeat 1:

When the MODE BUTTON is pressed once, the

Repeat Indicator “ ” will light. This single track

of music will be repeated.

2. Repeat Folder:

When the MODE BUTTON is pressed twice, the

“” and “ ” indicator will be shown. This

specific folder will be played repeatedly.

Remarks: The folder number and the track number

will be shown every 2 seconds alternatively.

3. Repeat All:

When the REPEAT BUTTON is pressed three times,

the Repeat All Indicator “ ” will be shown. The

whole disc can be played continuously.

4. To cancel the Repeat Function

Press the MODE BUTTON repeatedly until the

Repeat Indicator disappears from the LCD DISPLAY.

Random Play Mode

This feature allows the tracks on the disc to be played in a random order.

1. During the CD Stop mode, press the MODE

BUTTON four times, the “ ” Indicator will

show on the LCD DISPLAY and all music will be

played in random order automatically.

2. To cancel the Random Play function, press the

MODE BUTTON again, “ ” Indicator will disappear from the LCD

DISPLAY.

Skip And Search

1. During play or pause mode, when CD SKIP/SEARCH or CD

SKIP/SEARCH BUTTON is pressed once, it will go to the next track or

go back to the beginning of the track.

2. During play mode, when CD SKIP/SEARCH or CD SKIP/SEARCH 

BUTTON is pressed once and held, it will search the track with audible

high speed forward or backward playback.

English - 9

Program Mode

1. During the CD stop mode, press the PROGRAM BUTTON once. The

Program Indicator “ ” and the number of

Program to be memorized starts from the first

program “ ” will light up and blink continuously.

Press the FOLDER UP or DOWN BUTTON, then

press CD SKIP/SEARCH FORWARD or BACKWARD

BUTTON to select your desired musical track, CD LCD DISPLAY will show

the track number of this specific Album to be programmed. Press the

PROGRAM BUTTON to store this track in memory.

2. Repeat above procedure until all desired tracks have been programmed.

Remarks: Whenever the FOLDER UP or DOWN BUTTON is pressed, it

will always show the last programmed Album number first

to recall your memory.

A total of 20 tracks can be stored in memory. After complete

programming, LCD DISPLAY will show “ ” and blink

continuously.

3. To start the Programmed playback, press the CD PLAY/PAUSE BUTTON

once and the CD Play Indicator “”, “ ” and the track number of

the specific Album will light up.

Example: Album # 3, Track # 2.

4. To check the program you have stored after complete programming,

press the PROGRAM BUTTON once during the CD Stop mode. The LCD

DISPLAY will show “ ” and blink continuously. Press the FOLDER UP

or DOWN BUTTON to read the Album number, then press the CD

SKIP/SEARCH FORWARD or BACKWARD BUTTON to read the specific

track number of said Album. Press the PROGRAM BUTTON again, LCD

DISPLAY will show “ ” and blink continuously. Repeat above

procedure to check all programs being stored.

5. To cancel the programmed memory:

¾During the CD stop mode, press the CD STOP BUTTON once.

¾Open the CD Door during the CD stop mode.

English - 10

The Program Indicator “ ” will disappear from the LCD DISPLAY.

Recording From CD Player

1. Slide the FUNCTION SWITCH to “CD” position.

2. Put a CD into the CD compartment with the label side upward.

3. Insert a cassette into the cassette compartment and press PAUSE

BUTTON of the cassette deck.

4. Press RECORD BUTTON and PLAY BUTTON simultaneously for recording

stand-by. With the built-in ALC, the best recording quality is adjusted

automatically.

5. Activate the CD player, playing in a desired track as described in the

COMPACT DISC PLAYER OPERATION section. Release the PAUSE

BUTTON of the cassette deck to start recording.

6. To stop recording temporarily, press the PAUSE BUTTON. To continue

recording, press the PAUSE BUTTON again.

7. Press STOP/EJECT BUTTON of the cassette deck to stop recording. Then

stop CD playback by pressing the CD STOP BUTTON of the CD player.

MAINTENANCE

CLEANING THE TAPE HEADS

Clean the heads frequently to remove dust and tape residue. Dirt on the

heads will impair the sound quality of both recording and playback.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE APPLIANCE TO RAIN

OR MOISTURE. DO NOT REMOVE COVER, PILOT LAMPS SOLDERED IN PLACE. NO

USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

Tabla de contenidos

Otros manuales de Reproductor de CD de SOUNDMASTER

SOUNDMASTER

SOUNDMASTER SCD-6300MP3 Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD 2600 Manual de usuario

SOUNDMASTER

SOUNDMASTER CD9250 Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD-5600 Manual de usuario

SOUNDMASTER

SOUNDMASTER RCD5000 Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD6450 Manual de usuario

SOUNDMASTER

SOUNDMASTER High line SCD 2700USB Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD5750 Manual de usuario

SOUNDMASTER

SOUNDMASTER CD9290SW Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD2350 Manual de usuario

SOUNDMASTER

SOUNDMASTER CD9180 Manual de usuario

SOUNDMASTER

SOUNDMASTER CD9110 Manual de usuario

SOUNDMASTER

SOUNDMASTER KCD1600 Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD 5400 Manual de usuario

SOUNDMASTER

SOUNDMASTER URD-800 Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD 5850MP3 Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD5410 Manual de usuario

SOUNDMASTER

SOUNDMASTER CD9220 Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD5701 Manual de usuario

SOUNDMASTER

SOUNDMASTER CD9180 Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD-3700 Manual de usuario

SOUNDMASTER

SOUNDMASTER RCD 1100 Manual de usuario

SOUNDMASTER

SOUNDMASTER SCD5405 Manual de usuario

SOUNDMASTER

SOUNDMASTER DISC 4011 Manual de usuario

Manuales populares de Reproductor de CD de otras marcas

RCA

RCA RP-7923 Manual de usuario

Pioneer

Pioneer DEH-P3550MP XM Manual de usuario

Philips

Philips AZ1207 Manual de usuario

Philips

Philips CD582 Manual de usuario

Philips

Philips AZ 6821 Manual de usuario

Lasonic

Lasonic MSU-2020 Manual de usuario

THOMSON

THOMSON RCD150 Manual de usuario

Denon

Denon DCD-1420 Manual de usuario

Panasonic

Panasonic SJ-MR100 Manual de usuario

Onkyo

Onkyo DX-7210 Manual de usuario

Sony

Sony MZ-R3 Manual de usuario

Denon

Denon DVM-4800 Manual de usuario

JBL

JBL MR-32 Manual de usuario

RCA

RCA RCD152 Manual de usuario

Technics

Technics SL-PS770A Manual de usuario

Clarion

Clarion compact disc Manual de usuario

Sony

Sony MZ-M10 Manual de usuario

Philips

Philips Expanium AZ 1538 Manual de usuario
