INSTALLATION MANUAL
1st Edition
Serial No. 10001 and Higher: DNW-A28
Serial No. 40001 and Higher: DNW-A28P
DIGITAL VIDEOCASSETTE RECORDER
DNW-A28
DNW-A28P
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
Attention-when the product is installed in Rack:
1. Prevention against overloading of branch circuit
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
make sure that the rack does not overload the supply
circuit.
2. Providing protective earth
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
confirm that the outlet is provided with a suitable
protective earth connection.
3. Internal air ambient temperature of the rack
When this product is installed in a rack, please make
sure that the internal air ambient temperature of the
rack is within the specified limit of this product.
4. Prevention against achieving hazardous
condition due to uneven mechanical loading
When this product is installed in a rack, please make
sure that the rack does not achieve hazardous
condition due to uneven mechanical loading.
DNW-A28
DNW-A28P
CAUTION
Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to the
manufacturer’s instructions.
Vorsicht!
Explosionsgefahr bei unsachgemäßem
Austausch der Batterie.
Ersatz nur durch denselben oder einen vom
Hersteller empfohlenen ähnlichenTyp.
Entsorgung gebrauchter Batterien nach Angaben
des Herstellers.
ATTENTION
Il y a danger d’explosion s’il y a remplacement
incorrect de la batterie.
Remplacer uniquement avec une batterie du
même type ou d’un type équivalent recommandé
par le constructeur.
Mettre au rebut les batteries usagées
conformément aux instructions du fabricant.
ADVARSEL!
Lithiumbatteri-Eksplosionsfare ved fejlagtig
håndtering.
Udskiftning måkun ske med batteri
af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandøren.
Voor de klanten in Nederland
Dit apparaat bevat een (CF)n-Li batterij voor memory
back-up.
Raadpleeg uw leverancier over de verwijdering van de
batterij op het moment dat u het apparaat bij einde
levensduur afdankt.
Gooi de batterij niet weg. maar lever hem in als KCA.
Bij dit produkt zijn batterijen geleverd.
Wanneer deze leeg zijn, moet u ze niet
weggooien maar inleveren als KCA.
1 (P)
DNW-A28
DNW-A28P
1
DNW-A28
DNW-A28P
Table of Contents
Manual Structure
Purpose of this manual .............................................................................................. 2
Related manuals......................................................................................................... 2
1. Installation
1-1. Installation Procedure..................................................................................1-1
1-2. Supplied Accessories ..................................................................................1-1
1-3. Operating Conditions ..................................................................................1-2
1-4. Power Supply ..............................................................................................1-3
1-5. Installation Space ........................................................................................1-4
1-5-1. Outside Dimensions ...................................................................1-4
1-5-2. Notes on Installation ..................................................................1-5
1-5-3. Rack Mounting...........................................................................1-7
1-6. Connectors/Cables.......................................................................................1-8
1-7. Signal Inputs and Outputs ...........................................................................1-9
1-8. Setup Extended Menu ...............................................................................1-12
1-9. Settings for External Editors .....................................................................1-13
1-9-1. Time Code Settings for Recorder.............................................1-13
1-9-2. VTR Constant Settings for External Editors ............................1-13
1-9-3. System Phase Adjustment ........................................................1-14
1-9-4. Setup Menu Setting of ITEM-701............................................1-14
2DNW-A28
DNW-A28P
Manual Structure
Purpose of this manual This manual is the installation manual of digital videocassette recorder DNW-A28/
A28P.
This manual is intended for use by trained system and service engineers, and
provides the information that is required to install (environment, connection infor-
mation, initial setting, etc.) .
Related manuals Besides this “installation manual”, the following manuals are available for digital
videocassette recorder DNW-A28/A28P.
..
..
.Operation Manual (Supplied with the unit.)
This manual is necessary for application and operation (and installation) of the unit.
..
..
.Maintenance Manual (available on request)
Volume-1 : Service Instruction
Volume-2 : Parts List, Diagrams
These manuals describe the maintenace and service information (service over-
view, adjustments, board layouts, schematic diagrams, detailed parts list, etc.) for
this unit. If these manuals are required, please contact your local Sony Sales
Office/Service Center.
..
..
.Protocol Manual of Remote (9-pin) Connector (available on request)
This manual explains the protocol for controlling the VTR via the RS-422A (9-pin
serial remote). If this manual is required, please contact your local Sony Sales
Office/Service Center.
1-1
DNW-A28
DNW-A28P
Section 1
Installation
1-1. Installation Procedure
Installation procedure of this unit is shown on the following flowchart.
Refer to each section about detail of each flow.
The operation manual is also reqruired to do *-marked flow.
1-2. Supplied Accessories
Cap, BNC ........................................................................ 11
Cap, DC OUT .................................................................... 2
Cap, XLR (F)..................................................................... 2
Cap, XLR (M) ................................................................... 5
Cap, DUST ........................................................................ 1
Operation manual .............................................................. 1
Installation manual ............................................................ 1
n
After installation, be sure to use the supplied cap for protecting unused connector.
1-3. Operating Conditions
1-4. Power Supply
1-6. Connectors / Cables
1-7. Signal Inputs and Outputs
1-8. Setup Extended Menu
1-9. Settings for External Editors
Start
Determination of
installation place
Unpacking
*Connection
*Initial setup
*Operation check
End
n
When the unit is transported, it is required to pack the unit into the specified new packing materials.
Do not reuse the packing materials.
1-5. Installation Space
Installation
1-2 DNW-A28
DNW-A28P
1-3. Operating Conditions
1-3. Operating Conditions
c
Do not block an air vent. If ventilation is not enough, the unit may be damaged due to increase the
internal temperature of the unit.
.Do not shove the unit into cramped place with poor ventilation.
.Be sure to make cleaning if a cooling fan is covered with dust.
.Replace a cooling fan periodically.
.Do not place the unit on a longhaired carpet.
.Do not cover the unit with cloth.
n
Good air circulaiton is essential to prevent internal heat build-up. Place the unit in location with sufficient
air circulation.
Do not block the ventilation holes of the cabinet and the front and rear panels.
Operating temperature: 0dC to 40dC
Operating humidity: 25% to 80% (Condensation not allowed)
Storage temperature: _20dC to 60dC
Locations to avoid:
.Areas where the unit will be exposed to direct sunlight of any other strong lights.
.Areas near heat sources.
.Dusty areas or areas subject to vibration.
.Areas with strong magnetic field.
.Areas with much electrical noise.
.Areas with much static electricity.
.Areas that is impossible to find a specified room for installation.
(Refer to Section “1-5. Installation Space” .)
.Areas windtight.
1-3
DNW-A28
DNW-A28P
1-4. Power Supply
The unit works either on the AC adaptor or battery. When repairing or checking the unit, AC adaptor
operation is recommended.
Power Voltage: DC 11 to 17 V
Power Consumption : 58 W
m
.The AC adaptor AC-DN1 cannot be used to derive power.
.While the unit is battery-operated, the remaining battery capacity is displayed on the FL display panel.
When the battery is nearly dead, the WARNING indicator on the upper left side of the front panel will
blink. For details, refer to the operation manual supplied with the unit.
1-4. Power Supply
DC IN
DNW-A28/A28P
Rear View
DC power cord
AC adaptor
AC-DN2A
AC adaptor
AC-550/550CE
Lithium-ion battery
BP-L60(A)/L90(A)
Battery adaptor
BKP-L551
DC OUT
DC OUT
(DC cable)
1-4 DNW-A28
DNW-A28P
1-5. Installation Space
1-5-1. Outside Dimensions
Unit : mm
1-5. Installation Space
WARNING
DNW-A28
OVER OVER
EMPH
0
10
30
20
40
PEAK
dB
1/3
1
3
12 3
REC
PB 4
2
REC
PB
REC
PB
4
2/4
PAGE F1 F2
STOP
STANDBY
SERVO REC
INHI
DATA PLAY SEQ REC
REW F
FWD SEARCH
EDIT PRESET
EDIT PAUSE
SHIFT
PRESET
VAR
PRESET
VAR
PRESET
VAR
PRESET
VAR
VIDEO CHROMA
SET UP/BLACK LEVEL CHROMA PHASE
TC GENERATOR
REMOTE EXT REGEN R-RUN PB/EE
LOCAL INT PRESET F-RUN PB
PRESET
VAR
PRESET
VAR
F3 F4 DOWN
LIST UP
EJECT
CTL/TC/U-BIT
HOLD
SET
MENU
ON
OFF
POWER
PUSH
RESET
MARK
∞
REC INHI
METER
MONITOR
1/2
1/2
MIX
PHONES
2/1
3/4
ON
OFF
333
443.6
424.5
28.1
41
174
13212
21
153.5
210
