Sony NSS-S2 Manual de usuario

MEDIA STORAGE UNIT

NSS-S2

INSTALLATION MANUAL

1st Edition (Revised 1)

Serial No. 10001 and Higher

NSS-S2

!WARNING

This manual is intended for qualified service personnel only.

To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that

contained in the operating instructions unless you are qualified to do so. Refer all servicing to

qualified service personnel.

!WARNUNG

Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.

Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die

Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei

Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben

Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung

dazu besitzen.

!AVERTISSEMENT

Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin

de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les

réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.

Pour toute réparation faire appel à une personne compétente uniquement.

WARNING

This unit has no AC power switch.

When installing the unit, incorporate a readily

accessible disconnect device in the fixed wiring, or

connect the power cord to a socket-outlet which must be

provided near the unit and easily accessible, so that the

user can turn off the power in case a fault should occur.

WARNUNG

Dieses Gerät hat keinen AC-Netzschalter.

Beim Einbau des Geräts ist daher im Festkabel ein

leicht zugänglicher Unterbrecher einzufügen, oder das

Netzkabel mu

mit einer in der Nähe des Geräts

befindlichen, leicht zugänglichen Wandsteckdose

verbunden werden, damit sich bei einer

Funktionsstörung die Stromversorgung zum Gerät

jederzeit unterbrechen lä

For safety, do not connect the connector for peripheral

device wiring that might have excessive voltage to the

following port(s).

: 100BASE-TX connector

Follow the instructions for the above port(s).

NSS-S2 1 (P)

Attention-when the product is installed in Rack:

1. Prevention against overloading of branch circuit

When this product is installed in a rack and is

supplied power from an outlet on the rack, please

make sure that the rack does not overload the supply

circuit.

2. Providing protective earth

When this product is installed in a rack and is

supplied power from an outlet on the rack, please

confirm that the outlet is provided with a suitable

protective earth connection.

3. Internal air ambient temperature of the rack

When this product is installed in a rack, please make

sure that the internal air ambient temperature of the

rack is within the specified limit of this product.

4. Prevention against achieving hazardous

condition due to uneven mechanical loading

When this product is installed in a rack, please make

sure that the rack does not achieve hazardous

condition due to uneven mechanical loading.

5. Install the equipment while taking the operating

temperature of the equipment into consideration

For the operating temperature of the equipment, refer

to the specifications of the Operation Manual.

6. When performing the installation, keep the

following space away from walls in order to

obtain proper exhaust and radiation of heat.

Rear: 10 cm (4 inches) or more

Laser Diode Properties

Wave length : 850 nm

Emission duration : Continuous

Laser output power : 0.5 mW (max.) (Specification

of an optical pickup)

CAUTION

The use of optical instruments with this product

will increase eye hazard.

CAUTION

Use of controls or adjustments or performance of

procedures other than those specified herein

may result in hazardous radiation exposure.

This Media Storage Unit is classified as a CLASS 1

LASER PRODUCT.

CLASS 1 LASER PRODUCT

LASER KLASSE 1 PRODUKT

LUOKAN 1 LASERLAITE

KLASS 1 LASER APPARAT

NSS-S2

2 (P)

PRECAUTIONS

Use the specified power cord only

Use of power cords other than the specified ones may

cause fire or electric shock.

Do not damage the power cord

A damaged power cord may cause fire or electric shock.

When mounting the unit in a rack, be careful not to

catch the power cord in the rails.

Do not install the unit in humid or dusty locations

Dust, soot, and oil particles in the ambient atmosphere

may cause fire or electric shock.

Install the dedicated circuit breaker or power switch

This unit is not equipped with an AC power switch.

Install the dedicated circuit breaker or power switch,

and/or plug the power cord in the outlet.

Do not block the ventilation slots

If the ventilation slots are blocked, overheating inside

the unit may cause fire. Observe the following points to

ensure adequate ventilation.

.Do not install in narrow or sealed locations.

.Remove dust from the fan and air filter.

Install in a stable location

Installation in an unstable place may cause the unit fall,

resulting in injury.

Do not stack the units

Do not stack two or more units on top of each other.

Mount in a rack to avoid the risk of the unit sliding and

causing injury.

Ground the unit safely

Failure to ground the unit may cause electric shock.

Handling the unit by holding the designated

positions

When handling the unit, be sure to hold the following

positions.

Otherwise, the unit may break and fall, causing injury.

.Rack angle

.Bottom case

Especially, do not hold the front panel or the handle of

the power supply unit.

Carry the unit with more than two persons

The total weight of this unit is 32 kg.

Carrying the unit with less than two persons may cause

injury.

Mount with more than two persons

The total weight of this unit is 32 kg.

Mounting the unit with less than two persons may cause

injury.

Mount only with the specified rack mount rails

Rack mount rails other than those specified for this unit

may not be strong enough to support the unit, risking

possible collapse and injury.

Secure the unit to a rack with the screws

If the unit is not secured completely, this may cause the

unit fall off, resulting in injury. Be sure to secure the unit

with the screws when mounting to the rack. (Refer to

“1-6. Rack Mounting”)

Plug and connector of the power cord must be

inserted as far as they can go

Plug and connector of the power cord must be inserted

into the AC inlet as far as they can go.

1 (E)

NSS-S2

Table of Contents

Manual Structure

Purpose of this manual ........................................................... 3 (E)

Related manuals ..................................................................... 3 (E)

Contents .................................................................................. 3 (E)

Trademark .............................................................................. 3 (E)

1. Installation

1-1. Cautions before Installation ..................................... 1-1 (E)

1-2. Installation Procedure .............................................. 1-2 (E)

1-3. Operating Conditions and Installation Space .......... 1-2 (E)

1-4. Power Supply ........................................................... 1-4 (E)

1-4-1. Information for Power Supply ........................ 1-4 (E)

1-4-2. Recommended Power Cord ............................ 1-4 (E)

1-5. Setting the Switch for the Backup Battery .............. 1-5 (E)

1-6. Rack Mounting ........................................................ 1-6 (E)

1-7. Installing the HDD Unit ........................................... 1-8 (E)

1-8. Signal Input and Output ........................................... 1-9 (E)

1-9. Connecting Connectors and Cables ......................... 1-9 (E)

1-10. Connection ............................................................. 1-10 (E)

1-11. Checks after Connection ........................................ 1-11 (E)

1-12. Menu Settings ........................................................ 1-13 (E)

1-12-1. Displaying of Menus .................................... 1-13 (E)

1-12-2. Setting of Device Name ............................... 1-14 (E)

1-12-3. Setting of Network ....................................... 1-15 (E)

1-12-4. Executing of Logical Formatting ................. 1-16 (E)

1-13. SNMP .................................................................... 1-17 (E)

1-13-1. Setting of Community Name ........................ 1-17 (E)

1-13-2. Setting of TRAP IP ...................................... 1-18 (E)

1-14. Setting of FAN MODE .......................................... 1-18 (E)

2. Service Overview

2-1. Cleaning the Air Filter ............................................. 2-1 (E)

2-2. Functional Descriptions of Board Switches

and LEDs ................................................................. 2-2 (E)

2-2-1. PU-124 Board ................................................. 2-2 (E)

2-2-2. MPU-136 Board ............................................. 2-8 (E)

2-2-3. DP-405 Board ............................................... 2-10 (E)

3 (E)

NSS-S2

Purpose of this manual

This manual is the installation manual of Media Storage Unit NSS-S2.

This manual is intended for use by trained system and service engineers, and

describes the information regarding installation.

Related manuals

Besides this Installation Manual, the following manuals are available for the

NSS-S2.

.NSS-S2 Operation Manual (supplied with the NSS-S2)

This manual describes the application and operation of the NSS-S2.

Part number: 3-903-843-XX

.NSS-S2 Maintenance Manual (available on request)

This manual describes the information that premise the service based on main

parts replacement (service overview, maintenance functions, replacement of the

parts and boards, circuit descriptions and block diagram, etc.).

If this manual is required, please contact your local Sony Sales Office/Service

Center.

Part number: 9-968-191-XX

Contents

The following is a summary of all the section for understanding the contents of this

manual.

Section 1 Installation

Explains the operating conditions, installation space, power supply, rack mounting,

installing the HDD unit, connection, and checks after connection.

Section 2 Service Overview

Explains the cleaning procedure of the air filter, the function and factory setting of

the switches and LEDs on the board.

Trademark

Trademarks and registered trademarks used in this manual are follows.

.Ethernet is a registered trademark of Xerox Corporation.

Manual Structure

1-1 (E)

NSS-S2

1-1. Cautions before Installation

The Hard Disk Drives (HDD) are installed in this unit. The HDD is a precision part. The causes such as

shock, vibration and static electricity to the unit, and the conditions of temperature and humidity may

damage HDD or its data.

Before installation, read fully the following cautions, and perform the installation with extra care.

Cautions about shock and vibration

When transporting and moving;

.Pack the unit using the packaging materials specified by the manufacturer.

.Use a proper cart.

.Avoid rough routes, and manage the cart gently.

When placing on a floor or table;

.Put a cushion on stable and horizontal place, and put the unit on it gently.

.Do not place the unit near vibrating equipments.

For the unit;

.Never hit the unit, and drop the tool on the unit.

Take extra care;

.Never give vibration or shock to the unit while the power is turned on, or within about 30 seconds after

turning off the power.

.Be extremely careful when removing and/or installing the HDD unit or power supply unit while the unit

is in live state.

Cautions about rack mounting the unit

.Mount in the rack after removing all built-in HDD from the unit.

.Never give shock to all the rack mounted unit which has a HDD.

Caution about static electricity

.Keep static-producing items such as plastics (air caps or others) away from the working area.

.When touching the HDD unit, be sure to wear a grounded earth-band to protect against static electricity.

Cautions about temperature and humidity

.Temperature and humidity of storage and operating condition must be kept within the correct specified

range.

.Never turn on the power with the cabinet is removed in consideration of the air-cooling effect.

Cautions when an error appears in a HDD

.Treat this unit conform to the above cautions, even when an error appeared.

.Keep the unit in the condition in which the error appeared, and record the details of the error.

Section 1

Installation

1-2 (E) NSS-S2

1-2. Installation Procedure

Keep the packing materials, such as carton, cushion, and so

on after unpacking.

When the unit is transported, pack the unit using the

supplied materials.

The following flowchart shows the installation procedure

of this unit.

Refer to each item in this manual for details.

1-3. Operating Conditions and

Installation Space

1. Set the operating temperature and humidity

within the following conditions.

Operating temperature +5 dC to +40 dC

Operating humidity +20 % to +90 %

(No condensation)

Storage temperature _20 dC to +60 dC

2. Do not install this unit in the following

locations.

.Areas where the unit will be exposed to direct

sunlight or any other strong lights

.Dusty areas or areas where is subjected to vibration

.Areas with strong electric or magnetic fields

.Areas near heat sources

.Areas where is subjected to electrical noise

.Areas where is subjected to static electricity noise

.Unstable and unbalanced areas

3. To prevent the internal temperature rise, pay

attention to circulation of air in the place

where this unit is installed.

The rear side of this unit should be 10 cm away from

the walls for ventilation.

Start

Determination

of installation place

Switch setting

Rack mounting

Installing the

HDD unit

Connection

Checks after connection

End

1-3. Operating Conditions

and Installation Space

1-4. Power Supply

1-5. Setting the Switch for

the Backup Battery

1-6. Rack Mounting

1-7. Installing the HDD Unit

1-8. Signal Input and Output

1-9. Connecting Connectors

and Cables

1-10. Connection

1-11. Checks after Connection

Tabla de contenidos

Otros manuales de Almacenamiento de Sony

Sony

Sony USM16SA3 Manual de usuario

Sony

Sony StorStation LIB-D81 Manual del operador

Sony

Sony AIT-SDX450 Instrucciones de instalación

Sony

Sony MSX-M1GS Operating Instructions (Memory Stick... Manual de usuario

Sony

Sony SR16A4 Manual de usuario

Sony

Sony USM4GR Manual de usuario

Sony

Sony MSH-128S2 Operating Instructions (primary... Manual de usuario

Sony

Sony AITi200STS Manual de usuario

Sony

Sony SDT-S9000 - DDS Tape Drive Manual

Sony

Sony SDX-500V Manual de usuario

Sony

Sony Microdrive RHMD2G Manual de usuario

Sony

Sony VGN-NW Series Guía

Sony

Sony MSX-M256S Manual de usuario

Sony

Sony PXU-MS240 Manual de usuario

Sony

Sony VGN-CS320J Manual de usuario

Sony

Sony StorStation AITi260 Manual de usuario

Sony

Sony SDX-870V Serie Manual de usuario

Sony

Sony MS-MT16G Manual de usuario

Sony

Sony BKMA-U55 Manual de usuario

Sony

Sony TSL-S11000 Manual de usuario

Sony

Sony HD-E1 Manual de usuario

Sony

Sony MicroVault USM4GP Manual de usuario

Sony

Sony SDX-700C Instrucciones de instalación

Sony

Sony SR Series Manual de usuario

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
