HDPS-M1

OPEN

HDD

Photo Storage

Operating Instructions

Before operating the unit, please read this document

thoroughly, and retain it for future reference.

Preparations _______________

Copying data to the unit _____

Connecting to a computer ____

Additional information _______

2-022-121-12(1)

Safety regulations

WARNING

Keep away from children. If any part of the unit is swallowed, promptly see a

doctor.

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

To avoid electrical shock, do not open the cabinet. Refer servicing to qualified

personnel only.

For use only with power supply SONY, Model HDAC-M1/MCS-AC1.

Disclaimer

Sony Corporation assumes no responsibility for the loss of information stored on the hard

disk of this unit, or information transferred to a “Memory Stick” and/or CompactFlash

card with your computer.

• “Memory Stick”, , and “MagicGate Memory Stick” are trademarks of Sony Corporation.

• “Memory Stick Duo” and “ ” are trademarks of Sony Corporation.

• “MagicGate Memory Stick Duo” is a trademark of Sony Corporation.

• “Memory Stick PRO” and “ ” are trademarks of Sony Corporation.

• “Memory Stick PRO Duo” and “ ” are trademarks of Sony Corporation.

• “MagicGate” and “ ” are trademarks of Sony Corporation.

• Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States

and/or other countries.

• Mac and Macintosh are trademarks of Apple Computer Inc., registered in the U.S. and/or other

countries.

• Microdrive is a registered trademark of Hitachi Global Storage Technologies.

• Other system and product names used herein are registered trademarks or trademarks of their

respective manufacturers, although the ™ and ® marks are not used in the text.

In this manual, Microsoft®Windows®XP Professional and Microsoft®Windows®XP Home

Edition are referred to as Windows XP.

In this manual, Microsoft®Windows®2000 Professional is referred to as Windows 2000.

In this manual, Microsoft®Windows®Millennium Edition is referred to as Windows Me.

Table of contents

Safety regulations ...........................2

What you can do with the HDD Photo

Storage ............................................4

Media types that can be used with the

HDD Photo Storage ........................6

About the “Memory Stick”

media ............................................7

Recommended computer

environment ....................................8

Identifying parts and controls .........9

Preparations

Unpacking .....................................12

Powering the unit ..........................13

Charging the battery ...................13

Using the unit with the AC power

adapter ........................................14

Power save function ...................14

Using the unit abroad .................15

Copying data to the unit

Inserting and removing the “Memory

Stick” media .................................16

Inserting and removing the

CompactFlash card .......................18

Copying data to the HDD Photo

Storage ..........................................20

Connecting to a computer

Preparing the HDD Photo Storage

and computer ................................23

Copying data to a computer ..........24

With Windows 2000 or Windows

Me ...............................................24

With Windows XP ..................... 31

With a Macintosh computer ....... 34

Data storage locations and folder

names ............................................ 36

Using the unit as an external hard disk

drive or reader/writer .................... 37

Additional information

Troubleshooting ........................... 38

Precautions ................................... 40

Maintenance ................................. 41

Disposing of the unit .................... 42

Specifications ............................... 43

Meaning of the indicators ............. 44

Remaining battery/charging

indications .................................. 44

Error indications ........................ 45

What you can do with the HDD Photo Storage

OPEN

Store lots of images from a digital camera!

Simply take pictures, and then insert

the media into the HDD Photo

Storage to copy the image data to the

internalharddisk.Aftercopying,you

canreusethemediaimmediately.The

40 GB hard disk of the HDD Photo

Storage can store the equivalent of

about 620 units of 64 MB media.

Remove Copy!

Digital camera

HDD Photo Storage

OPEN

Connect to a computer!

Using the supplied USB cable, you

can easily transfer data from an

inserted media or from the hard disk

of the HDD Photo Storage to a

computer. There is no need to install

any special software or perform a

setup procedure.

USB cable

Seethenextpagefor a

step-by-step guide.

OPEN

Use as an external hard disk!

The HDD Photo Storage can function

as a USB 2.0-compatible external

hard disk, to provide data storage

capacity to a computer. There is no

need to install a dedicated driver,

which is great for quick copying of

data in a temporary setup.

THE HDD Photo Storage can also be used as a

card reader/writer.

Take it anywhere!

Thanks to its extremely compact dimensions and 300 g (10.6 oz.), the HDD Photo

Storage is eminently portable, making it the ideal companion on any trip, long or

short.

Copying images to your computer

Prepare the HDD Photo

Storage and your

computer (page 23).

Copyimagefilestoyour

computer (page 24).

View images on your

computer.

Media types that can be used with the

HDD Photo Storage

The following storage media can be used with the HDD Photo Storage.

“Memory Stick” media

*1 Read/write of data that requires the MagicGate function is not possible.

*2 High-speed transfer using the parallel interface is supported only with the “Memory Stick

PRO”. Transfer speed and available functions differ depending on the specifications of

the respective equipment.

CompactFlash cards (CF cards)

•Type I, II

•Microdrive

Notes

•There is no guarantee that the unit can use all “Memory Stick”, CompactFlash cards, or

Microdrives.

•The unit supports “Memory Stick” and Microdrives of up to 1 GB. Operation with

“Memory Stick PRO” or Microdrives of higher capacities is not guaranteed.

•Do not insert any media or devices other than those outlined above into the unit.

“Memory Stick” types Read/write on HDD

Photo Storage

“Memory Stick”

“Memory Stick” (with the Memory Select function)

“Memory Stick Duo” Yes

“Memory Stick”

(MagicGate/High-speed transfer compatible)

“Memory Stick Duo”

(MagicGate/High-speed transfer compatible)

Yes*1*2

“MagicGate Memory Stick”

“MagicGate Memory Stick Duo” Yes*1

“Memory Stick PRO”

“Memory Stick PRO Duo” Yes*1*2

The “Memory Stick” is a small, lightweight IC type storage media that can

hold considerably more data than a conventional floppy disk. It can serve not

only to exchange data between two devices with “Memory Stick” slots, but it

is also convenient as a removable external media for data storage.

The “Memory Stick” comes in two formats: the standard size “Memory Stick”

and the smaller “Memory Stick Duo”. The unit is compatible with both

formats.

“Memory Stick” types

There are six different types of “Memory Stick” designed for various

applications.

“Memory Stick PRO”

This “Memory Stick” can only be used in equipment compatible with

“Memory Stick PRO”. It incorporates a copy protection technology called

MagicGate.

“Memory Stick”

This is the regular “Memory Stick”. It can store all kinds of data, except data

that requires MagicGate copy protection.

“Memory Stick” (MagicGate/High-speed transfer compatible)

This type of “Memory Stick” incorporates the MagicGate copy protection and

supports high-speed transfers. It can be used in all devices that support the

“Memory Stick”. The unit does not support high-speed transfers.

“MagicGate Memory Stick”

This type of “Memory Stick” incorporates the MagicGate copy protection.

“Memory Stick-ROM”

This is a read-only type of “Memory Stick” that contains prerecorded data that

cannot be deleted or overwritten.

“Memory Stick” (with the Memory Select function)

This “Memory Stick” has a number of separately addressable internal memory

blocks (128 MB). The Memory Select switch at the rear of this type of

“Memory Stick” lets you select the desired memory. It is not possible to use

multiple blocks simultaneously or continuously.

What is MagicGate?

MagicGate is a copyright protection technology that must be present in the “Memory Stick”

and on the device where it is to be used. MagicGate incorporates two security features:

encryption of copy-protected data, and mutual verification of the “Memory Stick” and reader

device. This serves to prevent the unauthorized copy and playback of copyrighted material.

Because the HDD Photo Storage does not come with MagicGate, it cannot use data encrypted

with MagicGate.

About the “Memory Stick” media

When you attempt to copy music files from a MagicGate device to a “Memory Stick”, the

device and“Memory Stick” verify whether the other is MagicGate-compliant. Music files are

only encrypted and copied if the verification is successful. Similarly, when attempting to play

back encrypted files from the “Memory Stick”, playback only starts if the verification

between the device and “Memory Stick” is successful.

Recommended computer environment

The unit can be used with computers that run the following preinstalled

operation systems and come with USB ports.

Windows

•Windows XP Professional

•Windows XP Home Edition

•Windows 2000 Professional (Service Pack 4 or later)

•Windows Me

Notes

•Even if the operating system is one of the above, operation is not guaranteed in a multiboot

environment or if the operating system is an upgraded version.

•Operation is not guaranteed when you use USB interface cards or USB CardBus cards

added afterwards.

Macintosh

•Mac OS X (10.3 or later)

Identifying parts and controls

A1e(power) indicator

When the unit is on, this indicator lights or flashes. Depending on the

remaining battery capacity, the indicator pattern changes. (page 14)

B(“Memory Stick”) indicator (page 16)

When you use the unit stand-alone and the “Memory Stick” is inserted, this

indicator lights green. During copy, the indicator flashes.

CCF (CompactFlash) indicator (page 18)

When you use the unit stand-alone and a CompactFlash card is inserted,

this indicator lights green. During copy, the indicator flashes.

D(hard disk) indicator (page 20)

Flashes green while the hard disk is being accessed.

ECOPY button (page 20)

Serves to copy data from a “Memory Stick” or CompactFlash card to the

internal hard disk. When the unit is ready to copy, the button lights green.

FPort cover (page 10)

G!(DC In) connector (page 13)

Serves to connect the supplied AC power adapter.

H(USB) port (page 23)

Serves to connect the supplied USB cable.

8 79

ICANCEL/HDD CAPA. button (page 21)

Serves to cancel an ongoing copy and verify the remaining hard disk

capacity.

JEject button (page 18)

Serves to eject the CompactFlash card.

KSlot cover (page 10)

LCompactFlash slot (page 18)

Serves to insert a CompactFlash card.

M“Memory Stick” slot (page 16)

Serves to insert a “Memory Stick”.

N?/1 (power) switch (page 20)

Serves to turn the unit on and off.

OHand strap hook

Serves to attach the hand strap.

Opening/closing the covers

You can open/close the port and slot covers the same way.

To open the covers

Lightly push down the top part of the cover to open it, as illustrated.

HDD

Otros manuales para HDPS-M1

Tabla de contenidos

Otros manuales de Almacenamiento de Sony

Sony

Sony Memory Stick PRO Duo MS-MT Series Manual de usuario

Sony

Sony WALKMAN SUP-NWE020 Manual de usuario

Sony

Sony Personal Content Station LLS-201 Manual de usuario

Sony

Sony XQD QD Series Manual de usuario

Sony

Sony HD-B1 Manual de usuario

Sony

Sony SF Series Manual de usuario

Sony

Sony MS-MT1G Manual de usuario

Sony

Sony RMO-S551 Manual de usuario

Sony

Sony VPCL135FX Guía

Sony

Sony VAIO VGP-UHDP04 Manual de usuario

Sony

Sony SDX-250V Manual de usuario

Sony

Sony CDL1100 Manual de usuario

Sony

Sony VGN-BZ Series Guía

Sony

Sony PDW-1 Manual de usuario

Sony

Sony AIT-SDX560 Instrucciones de instalación

Sony

Sony Vaio VGP-UHDM10 Manual de usuario

Sony

Sony CompactFlash NCFB1G Manual de usuario

Sony

Sony MSAC-US40 - MemoryStick Flash Memory Card USB 2.0... Manual de usuario

Sony

Sony USM128C Manual de usuario

Sony

Sony MSMT16G Manual de usuario

Sony

Sony MSA-16A Manual de usuario

Sony

Sony MSAC-US40 - MemoryStick Flash Memory Card USB 2.0... Manual de usuario

Sony

Sony Memory Stick PRO MSX-4GN Manual de usuario

Sony

Sony MSAC-US20 Manual de usuario

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
