Sony CMT-PX333 Manual de usuario

Operating Instructions

Micro Hi-Fi

Component

System

4-232-601-11(1)

CMT-PX333

Warning

To prevent fire or shock hazard, do not

expose the unit to rain or moisture.

To prevent fire, do not Cover the ventilation of the

apparatus with news papers, table-cloths, curtains,

etc. And don’t place lighted candles on the apparatus.

To prevent fire or shock hazard, do not place objects

filled with liquids, such as vases, on the apparatus.

Do not install the appliance in a confined space,

such as a bookcase or built-in cabinet.

This appliance is classified as

a CLASS 1 LASER product.

This label is located on the

rear exterior.

The following

caution label is

located inside

the apparatus.

Don’t throw a battery, dispose it as

the injurious wastes.

Table of Contents

Parts Identification

Main unit ................................................... 4

Remote Control ......................................... 5

Getting Started

Hooking up the system.............................. 6

Inserting two R6 (size AA) batteries

into the remote.................................... 7

Setting the time ......................................... 7

Saving the power in standby mode ........... 8

Loading a CD ............................................ 8

Playing a CD — Normal Play/

Shuffle Play/Repeat Play.................... 9

Programming CD tracks

— Programme Play .......................... 10

Using the CD display .............................. 11

Labelling a CD — Disc Memo ............... 12

MD – Play

Loading an MD ....................................... 13

Playing an MD — Normal Play/

Shuffle Play/Repeat Play.................. 13

Programming MD tracks

— Programme Play .......................... 14

Using the MD display ............................. 15

MD –Recording

Before you start recording....................... 16

Recording a CD on an MD

—CD-MD Synchro Recording........ 17

Recording the current track —Rec It ..... 18

Recording on an MD manually

—Manual Recording ....................... 18

Starting recording with 6 seconds of

prestored audio data

—Time Machine Recording ............ 19

Recording tips ......................................... 20

—Recording for long times/

Marking track numbers/Smart Space/

Adjusting the recording level

MD –Editing

Before you start editing........................... 24

Labelling an MD —Name Function ...... 25

Erasing recordings................................... 27

—Erase Function/Track Erase

Function/All Erase Function/

A-B Erase Function

Moving recorded tracks

—Move Function ............................ 29

Dividing recorded tracks

—Divide Function ........................... 29

Combining recorded tracks

—Combine Function ....................... 30

Undoing the last edit

—Undo Function ............................. 31

Changing the recorded level after

recording —S.F Edit Function ........ 32

Tuner

Presetting radio stations .......................... 34

Listening to the radio

—Preset Tuning............................... 35

Labelling the preset stations

—Station Name ............................... 36

Using the Radio Data System (RDS)* .... 36

Sound Adjustment

Adjusting the sound ................................ 37

Timer

Falling asleep to music

—Sleep Timer ................................. 37

Waking up to music —Daily Timer....... 38

Timer recording radio programmes ........ 39

Optional Components

Hooking up the optional components ..... 40

Additional Information

Precautions .............................................. 41

System limitations of MDs ..................... 43

Troubleshooting ...................................... 44

Self-diagnosis display ............................. 47

Specifications .......................................... 50

* European model only

Parts Identification

The items are arranged in alphabetical order. Refer to the pages indicated in parentheses for details.

Main unit

qjqk qh qg qf qd qs qa 0

2 3 4

CD disc tray 9(8)

CD SYNC HIGH 0(17)

CD SYNC NORMAL qa (17)

CD NX wa (9)

Display window 3

FUNCTION qh (9, 13, 18, 25, 41)

MD insertion slot 2(13)

MD NX 6(13)

PHONES jack qj

PLAY MODE qg (9, 13, 24)

REC/REC IT qs (18)

REC MODE qd (20)

REPEAT qf (9, 14)

STEREO/MONO qf (35)

TUNER/BAND ql (34)

TUNING MODE qg (34)

TUNING +/–w; (34)

VOLUME +/–qk

BUTTON DESCRIPTIONS

?/1 1

ZMD 4

x(MD) 5

m/M (MD) 7

./> (MD) 7

ZCD 8

m/M (CD) w;

./> (CD) w;

x(CD) ws

Parts Identification

Remote Control

w; 1

CLEAR 6(11, 15, 26, 36)

CLOCK/TIMER SELECT ql

(38)

CLOCK/TIMER SET ql (7, 38)

DBFB qa (37)

DISPLAY qj (8, 11, 15)

ENTER/YES qg (7, 10, 14, 23,

25, 34, 38)

FUNCTION qf (9, 13, 18, 25, 41)

Letter/Number buttons 5(10, 14,

25)

MD zREC qs (18)

MENU/NO qg (11, 23)

NAME EDIT 8(12, 25, 36)

PLAY MODE qk (9, 13, 24)

PRESET EQ qa (37)

REPEAT qk (9, 14)

SCROLL 4(12, 26)

SELECT 8(12, 25)

SLEEP w; (37)

STEREO/MONO 2(35)

TIME qj (8, 11, 15)

TIME MACHINE REC qs (19)

TUNER/BAND 9(34)

TUNING MODE 3(34)

VOLUME +/– 0

BUTTON DESCRIPTIONS

@/1 1

M/CURSORt7

>/+ 7

N(MD) qd

N(CD) qd

Xqd

xqd

m/TCURSOR qh

./– qh

Getting Started

AM loop aerial

Right speaker

FM aerial

Left speaker

1Connect the speakers.

Connect the speaker cords to the SPEAKER

terminals on the unit and to the terminals on

the speakers as the following.

Black (#)

White (3)

Insert this portion

2Connect the FM/AM aerials.

Set up the AM loop aerial, then connect it.

Jack type A

AM loop aerial

Extend the FM lead aerial

horizontally

Hooking up the system

Perform the following procedure 1to 3to hook up your system using the supplied cords and

accessories.

Getting Started

AM loop aerial

Extend the FM lead aerial

horizontally

Jack type B

COAXIAL

3Connect the mains lead to the mains.

If the plug of the mains lead does not fit

your mains, attach the supplied adaptor on

to the plug (for models with a plug adaptor).

To turn on the system, press ?/1.

Inserting two R6 (size AA)

batteries into the remote

Tip

When the remote no longer operates the system,

replace both batteries with new ones.

Note

If you do not use the remote for a long period of time,

remove the batteries to avoid possible damage from

battery leakage.

Setting the time

1Turn on the system.

2Press CLOCK/TIMER SET on the

remote.

Proceed to step 5 when you set the clock for

the first time.

3Press .or >on the remote to

select “CLOCK SET?”.

4Press ENTER/YES on the remote.

5Press + or –on the remote to set the

day.

6Press ENTER/YES or Mon the

remote.

The hour indication flashes.

7Press + or –on the remote to set the

hour.

8Press ENTER/YES or Mon the

remote.

The minute indication flashes.

9Press + or –on the remote to set the

minute.

Press ENTER/YES on the remote.

The clock starts working.

If you made a mistake

Press mor Mon the remote repeatedly

until the incorrect item flashes, then set it

again.

To change the preset time

Start over from step 1.

When you play a CD single (8 cm CD),

place it on the inner circle of the tray.

3Press ZCD again to close the disc tray.

Loading a CD

1Press ZCD.

The disc tray opens.

2Place a CD with the label side up on the

disc tray.

Saving the power in

standby mode

Press DISPLAY or TIME on the remote

repeatedly when the system is off.

Each time you press the button, the system

switches cyclically as follows:

Clock display yPower Saving Mode

To cancel the Power Saving Mode

Press DISPLAY or TIME on the remote to

show the clock display.

Tip

?/1 indicator lights up even in the Power Saving

Mode.

Getting Started/CD

Playing a CD

— Normal Play/Shuffle Play/Repeat

Play

This system lets you play the CD in different

play modes.Track number Playing time

1Press FUNCTION repeatedly to switch

the function to CD.

2Press PLAY MODE repeatedly in stop

mode until the mode you want appears

in the display.

Select To play

The CD in the original

order.

All tracks on the CD in

random order.

The tracks on the CD in the

order you want (see

“Programming CD tracks”

on the next page).

3Press CD NX (or CD Non the

remote).

Blank (no PLAY

MODE indication)

(Normal Play)

SHUFFLE

(Shuffle Play)

PROGRAM

(Programme Play)

Other Operations

To Do this

Press REPEAT during play until

“REPEAT” or “REPEAT 1”

appears.

REPEAT: For all the tracks on the

CD up to five times.

REPEAT 1: For a single track

only.

To cancel playing repeatedly, press

REPEAT until “REPEAT” or

“REPEAT 1” disappears.

continued

Find a point in

a track Keep pressing mor Mfor the

CD during play and release it at

the desired point.

Press xfor the CD.

Pause Press CD NX (or Xon the

remote). Press again to resume

play.

Stop play

Select a track Press .or >for the CD.

Remove a CD Press ZCD.

Play repeatedly

(Repeat Play)

Programming CD tracks

—Programme Play

You can make a programme of up to 25 tracks.

1Press FUNCTION repeatedly to switch

the function to CD.

2Press PLAY MODE repeatedly until

“PROGRAM”appears.

3Press .or >for the CD until the

desired track number appears.

Tip

You can also select the desired track using the

remote.

Press the number buttons. The playback automatically

starts.

To enter track number over 10

(on the remote only)

1Press >10.

2Enter the corresponding digits.

To enter 0, press 10/0 instead.

Example:

To enter track number 30, press >10, then 3 and 10/0.

Notes

• The play mode cannot be changed while playing a

disc.

• If you press ZCD to open or close the disc tray

while listening to the radio, the CD icon lights even

if there is no CD in the tray.

To turn off the CD icon, press FUNCTION

repeatedly to switch the function to CD.

Playing a CD (continued)

Selected

track number Playing time of the

selected track

4Press ENTER/YES on the remote.

The track is programmed.

“Step” appears, followed by the number of

the track in the programmed sequence. The

number of the last programmed track

appears, followed by the total playing time

of the programme.

Last programmed

track number Total playing time

Tabla de contenidos

Otros manuales de Sistema estéreo de Sony

Sony

Sony 3-300-703-11(2) Manual de usuario

Sony

Sony LBT-XGR66 Manual de usuario

Sony

Sony WX-GT90BT Manual de usuario

Sony

Sony MHC-W77AV Manual de usuario

Sony

Sony CMT-GP6V Manual de usuario

Sony

Sony HCD-EX5 - Micro Hi-fi Component System Manual de usuario

Sony

Sony HCD-FX300i US Manual de usuario

Sony

Sony XO-D301 Manual de usuario

Sony

Sony CDP-SP55 Manual de usuario

Sony

Sony SRS-XB3 Manual de usuario

Sony

Sony CMT-DH7BT - Micro Hi Fi Component System Manual de usuario

Sony

Sony CAS-1 Manual de usuario

Sony

Sony CMT-X5CD Manual de usuario

Sony

Sony HCD-ZX9 - Receiver Cd Manual de usuario

Sony

Sony DHC-MD555 - Mini Hi Fi Component System Manual de usuario

Sony

Sony HCD-CP1 Manual de usuario

Sony

Sony HCD-V5900 Manual de usuario

Sony

Sony HCD-GN660 Manual de usuario

Sony

Sony DMXWL1 - BRAVIA Wireless HD Link Manual de operación y mantenimiento

Sony

Sony HCD-DX80 Manual de usuario

Sony

Sony PMC-DR45 - Personal Component System Manual de usuario

Sony

Sony MHC-V71 Manual de usuario

Sony

Sony Giga Juke NAS-E300HD Manual de usuario

Sony

Sony HCD-EP505 Manual de usuario

Manuales populares de Sistema estéreo de otras marcas

LG CM3330B Manual de usuario

Cetacea Sound

Cetacea Sound CVS-II Manual de usuario

Aiwa

Aiwa XR-H66MD Manual de usuario

Denon

Denon UCD-250 Manual de usuario

Sanyo

Sanyo DC-MX41i Manual de usuario

Sharp

Sharp CD-ES600V Manual de usuario

Exibel

Exibel BDX600-UK Manual de usuario

Sanyo

Sanyo DC-F320 Manual de usuario

Philips

Philips FWM583X Manual de usuario

Sharp

Sharp CD-C462 Manual de usuario

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Manual de usuario

Aiwa

Aiwa XR-EM70 Manual de usuario

Cyrus

Cyrus Lyric Manual de usuario

Philips

Philips MCM159/98 Manual de usuario

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Manual de usuario

RCA

RCA RS3965SB Manual de usuario

Sharp

Sharp XL-UH240 Manual de usuario

Philips

Philips FW 690 Manual de usuario
