SERVICE MANUAL

Published by Sony EMCS (Malaysia) PG Tec

Sony Corporation

SPECIFICATIONS

SPEAKER SYSTEM

9-890-532-04

2010L08-1

US Model

Canadian Model

AEP Model

UK Model

E Model

Australian Model

Chinese Model

PX Model

Ver. 1.3 2010.12

Design and speciﬁcations are subject to change without notice.

SS-CTB101/TSB101/WSB101

Photo: SS-CTB101 Photo: SS-TSB101 Photo: SS-WSB101

• SS-CTB101 is the center speaker in BDV-E370/E470/E570/E670W/E770W/E870/E970W/HZ970W/IZ1000W/T57/HT-AF5/AS5/SS370.

• SS-TSB101 are the front speaker in BDV-E370/E470/E570/E670W/E770W/T57/HT-AS5/SS370 and surround speaker in BDV-E370/E470/

E570/E770W/E670W/E870/HZ970W/T57/HT-AF5/AS5/SS370/WAHT-SBP2.

• SS-WSB101 is the subwoofer speaker in BDV-E370/E870 and HT-SS370.

• Front/Surround speaker (SS-TSB101)

• Center speaker (SS-CTB101)

Front/Surround speaker

Full range

Center speaker Full range, magnetically shielded

Speaker unit

Front/Surround speaker

2 1/4 in × 3 1/4 in (55 mm × 80 mm), cone type

Center speaker 1 3/16 in × 2 3/8 in (30 mm × 60 mm), cone type

Enclosure type

Front/Surround speaker

Bass reﬂex

Center speaker Acoustic suspension

Rated impedance 3 ohms

Dimension (w/h/d) (Approx.)

Front/Surround speaker

3 in × 8 7/8 in × 2 7/8 in (75 mm × 225 mm ×

71 mm) (with foot)

Center speaker 11 1/2 in × 1 15/16 in × 1 15/16 in (290 mm ×

49 mm × 49 mm) (with foot)

Mass (Approx.)

Front/Surround speaker

1 lb (0.45 kg) (with foot)

Center speaker 0 lb 10 oz (0.28 kg) (with foot)

• Subwoofer (SS-WSB101)

Speaker unit 6 3/8 in (160mm), cone type

Enclosure type Bass reﬂex

Rated impedance 3 ohms

Dimensions (w/h/d) (Approx.)

10 1/4 in × 12 5/8 in × 10 1/4 in

(260 mm × 320 mm × 260 mm) (with foot)

Mass (Approx.) 11 lb 8 oz (5.2 kg) (with foot)

SS-CTB101/TSB101/WSB101

PARTS LIST

A-1746-073-A SS-TSB101 (Front speaker: L-CH) (AEP,UK)

A-1746-074-A SS-TSB101 (Front speaker: L-CH) (SP/RU)

A-1746-075-A SS-TSB101 (Front speaker: L-CH) (MX,E32)

A-1746-077-A SS-TSB101 (Front speaker: R-CH) (AEP,UK)

A-1746-078-A SS-TSB101 (Front speaker: R-CH) (SP/RU)

A-1746-079-A SS-TSB101 (Front speaker: R-CH) (MX/E32)

A-1746-080-A SS-TSB101 (Surround speaker: L-CH) (AEP,UK)

A-1746-085-A SS-TSB101 (Surround speaker: L-CH) (SP/RU)

A-1746-207-A SS-TSB101 (Surround speaker: L-CH) (MX/E32)

A-1746-208-A SS-TSB101 (Surround speaker: R-CH) (AEP,UK)

A-1746-298-A SS-TSB101 (Surround speaker: R-CH) (SP/RU)

A-1746-310-A SS-TSB101 (Surround speaker: R-CH) (MX/E32)

A-1746-720-A SS-WSB101 (Subwoofer speaker) (AEP,UK)

A-1746-721-A SS-WSB101 (Subwoofer speaker) (SP/RU)

A-1746-728-A SS-WSB101 (Subwoofer speaker) (MX/E32)

A-1748-419-A SS-TSB101 (Front speaker: L-CH)

(US,CND,AUS,TW,TH,PX)

A-1748-420-A SS-TSB101 (Front speaker: R-CH)

(US,CND,AUS,TW,TH,PX)

A-1748-421-A SS-TSB101 (Surround speaker: L-CH)

(US, CND,AUS,TW,TH,PX)

A-1748-422-A SS-TSB101 (Surround speaker: R-CH)

(US,CND,AUS,TW,TH,PX)

A-1748-423-A SS-CTB101 (Center speaker)

(US,CND,AUS,EA,TW,TH,PX)

A-1748-424-A SS-WSB101 (Subwoofer speaker)

(US,CND,AUS,TW,TH,PX)

A-1748-537-A SS-CTB101 (Center speaker) (AEP,UK)

A-1748-538-A SS-CTB101 (Center speaker) (SP/RU)

A-1748-539-A SS-CTB101 (Center speaker) (MX/E32)

A-1763-521-A SS-CTB101 (Center speaker) (CH)

A-1769-746-A SS-TSB101 (Front speaker: L-CH) (AR)

A-1769-747-A SS-TSB101 (Front speaker: R-CH) (AR)

A-1769-748-A SS-TSB101 (Surround speaker: L-CH) (AR)

A-1769-749-A SS-TSB101 (Surround speaker: R-CH) (AR)

A-1769-750-A SS-CTB101 (Center speaker) (AR)

A-1769-751-A SS-WSB101 (Subwoofer speaker) (AR)

Ref. No. Part No. Description Remark

• Abbreviation

AR : Argentina model

AUS : Australian model

CH : Chinese model

E32 : 110-240V AC area in E model

EA : Saudi Arabia model

MX : Mexican model

RU : Russian model

SP : Singapore model

TH : Thai model

TW : Taiwan model

Ver. 1.3

SS-CTB101/TSB101/WSB101

REVISION HISTORY

Checking the version allows you to jump to the revised page.

Also, clicking the version at the top of the revised page allows you to jump to the next revised page.

Ver. Date Description of Revision

1.0 2010.01 New

1.1 2010.02 Additional for model BDV-E370, BDV-E470, BDV-E570, BDV-E770W, BDV-E870 and BDV-T57.

1.2 2010.03 Additional for model BDV-E670W/E970W/HT-AF5/AS5/WAHT-SBP2, version E, Australian and PX.

1.3 2010.12 Additional for model BDV-HZ970W/IZ1000W and Chinese version.
