Sony PMC-DR45L Manual de usuario

Personal

Component

System

Operating Instructions page 2GB

Manual de instrucciones página 2ES

3-044-713-13 (1)

PMC-DR45L

Introduction2GB

Warning

To prevent fire or shock hazard, do

not expose the player to rain or

moisture.

To avoid electrical shock, do not open

the cabinet. Refer servicing to

qualified personnel only.

Information

For customers in Europe

This Compact Disc player is classified as a

CLASS 1 LASER product.

The CLASS 1 LASER PRODUCT label is

located at the rear of the player.

Warning

Do not install the appliance in a confined

space, such as a bookcase or built-in cabinet.

Notice for customers in the United

Kingdom

A moulded plug complying with BS 1363 is

fitted to this equipment for your safety and

convenience.

Should the fuse in the plug supplied need to

be replaced, same rating fuse approved by

ASTA or BSI to BS 1362, (i.e. marked with

or mark) must be used.

If the plug supplied with this equipment has

a detachable fuse cover, be sure to attach the

fuse cover after you change the fuse. Never

use the plug without the fuse cover. If you

should lose the fuse cover, please contact

your nearest Sony service station.

CAUTION

• You can use this player on AC power

source only. You cannot use it on batteries.

When you use this player for the first time,

or when you have not used it for a long

time, leave it connected to AC power

source for about one hour to charge the

built-in backup battery for the clock, timer,

preset radio stations, etc. You can use the

player during charging. The player will

charge the battery automatically as long as

it is connected to a power source.

When you disconnect the mains lead after

charging, be sure to turn the power off

first. Once fully charged, the backup

battery will last for about 30 minutes

without being connected to any power

sources.

If the stored data are erased, reenter them

when you use the player again.

• The speakers and player are designed to be

used as a single unit. Never connect the

speakers and player to different

equipment. Doing so may cause the

connected equipment to malfunction.

Basic Operations

3GB

Introduction

Table of contents

Basic Operations

4Playing a CD

6Listening to the radio

8Playing a tape

10 Recording on a tape

The CD Player

13 Using the display

14 Locating a specific track

15 Playing tracks repeatedly

(Repeat Play)

16 Playing tracks in random order

(Shuffle Play)

17 Creating your own programme

(Programme Play)

The Radio

19 Presetting radio stations

20 Playing preset radio stations

21 Using the Radio Data System

(RDS)

The Tape Player

27 Finding the beginning of a track

The Audio Emphasis

28 Selecting the audio emphasis

(SOUND/MEGA BASS)

The Timer

29 Setting the clock

31 Waking up to music

34 Timer-recording radio

programmes

37 Falling asleep to music

Setting Up

38 Hooking up the system

43 Saving power

44 Connecting optional components

Additional Information

47 Precautions

49 Troubleshooting

52 Maintenance

53 Specifications

54 Index

Basic Operations4GB

Playing a CD

Basic Operations

For hookup instructions, see pages 38 - 42.

1Press ZCD OPEN/CLOSE

(direct power-on) and place the

CD on the CD tray.

2Press u.

(On the remote, press Non the

CD section.)

The CD tray closes and the player

plays all the tracks once.

With the label side up

Display

Playing timeTrack number

Basic Operations

5GB

Use these buttons for additional operations

Tip

Next time you want to

listen to a CD, just press

u. The player turns on

automatically and starts

playing the CD.

To Press

adjust the volume VOLUME +, –

(VOL +, – on the remote)

stop playback x

pause playback u

(Xon the remote)

Press again to resume play

after pause.

go to the next track >

go back to the previous track .

remove the CD ZCD OPEN/CLOSE

turn on/off the player OPERATE

u., >

ZCD

OPEN/CLOSE

VOLUME +, –

OPERATE

Basic Operations6GB

Listening to the radio

For hookup instructions, see pages 38 - 42.

1Press BAND•AUTO PRESET

until the band you want appears

in the display (direct power-on).

2Hold down TUNE TIME SET + or

– (TUNE + or – on the remote)

until the frequency digits begin to

change in the display.

The player automatically scans

the radio frequencies and stops

when it finds a clear station.

If you cannot tune in a station,

press the button repeatedly to

change the frequency step by

step.

Display

Indicates an FM

stereo broadcast.

Basic Operations

7GB

Use these buttons for additional operations

Tips

• The “FM1” and “FM2”

bands have the same

functions. You can store

the stations you want

separately in “FM1” and

“FM2”.

• If the FM broadcast is

noisy, press MODE until

“MONO” appears in the

display and the radio

will play in monaural.

• Next time you want to

listen to the radio, just

press the BAND•AUTO

PRESET button. The

player turns on

automatically and starts

playing the previous

station.

To Press

adjust the volume VOLUME +, –

(VOL +, – on the remote)

turn on/off the radio OPERATE

To improve broadcast reception

FM:

Keep the FM lead aerial as horizontal as possible and

reorient it.

If the FM broadcast is still noisy, disconnect the FM

lead aerial and connect the FM outdoor aerial

(not supplied) (page 42).

MW/LW:

Keep the MW/LW loop aerial as far as possible from

the player and reorient it.

VOLUME +, –

MODE

OPERATE

Basic Operations8GB

Playing a tape

For hookup instructions, see pages 38 - 42.

1Press ZPUSH OPEN/CLOSE to

open the tape compartment and

insert a recorded tape. Use TYPE I

(normal), TYPE II (high position)

and TYPE IV (metal) tapes.

2Press ZPUSH OPEN/CLOSE to

close the compartment.

3Press N.

(On the remote, press TAPE N.)

The player turns on (direct

power-on) and starts playing.

Display

1, 2

With the side you want

to play facing up

Tape counter

Basic Operations

9GB

Use these buttons for additional operations

To Press

adjust the volume VOLUME +, –

(VOL +, – on the remote)

stop playback x

play the reverse side n

fast-forward or rewind the tape TAPE Mor m

eject the cassette ZPUSH OPEN/CLOSE

turn on/off the player OPERATE

To select the direction mode of the tape

Press DIR MODE repeatedly.

To play Display shows

one side of the tape

both sides of the tape

from the upper side to reverse

side only

both sides of the tape repeatedly

Tips

• Press COUNTER RESET

to reset the counter to

“000”.

• Next time you want to

listen to a tape, just

press Nor n. The

player turns on

automatically and starts

playing the tape.

DIR MODE

VOLUME +, –

TAPE m, M

COUNTER RESET

OPERATE Z PUSH OPEN/CLOSE

Basic Operations10GB

Recording on a tape

For hookup instructions, see pages 38 - 42. To record on a

MiniDisc or DAT recorder, connect the component (see

page 44).

1Press ZPUSH OPEN/CLOSE to

open the tape compartment, and

insert a blank tape. Use TYPE I

(normal) tape only.

Press ZPUSH OPEN/CLOSE

again to close the compartment.

2Select the programme source you

want to record.

To record from the CD player:

Insert a CD (see page 4) and press

xon the CD section.

To record from the radio:

Tune in the station you want (see

page 6).

With the side you want

to record on facing up

Display

3 3
