Sony BDX-N1000 Manual de usuario
NETWORK INTERFACE UNIT
BDX-N1000
NETWORK ADAPTER BOARD
BDKP-N1001
NETWORK ADAPTER BOARD
BDKP-N1002
NETWORK ADAPTER BOARD
BDKP-N1003
NETWORK ADAPTER BOARD
BDKP-N1004
MAINTENANCE MANUAL
1st Edition
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen.Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien.Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
BDX-N1000 Serial No.10001 and Higher
BDKP-N1001 Serial No.10001 and Higher
BDKP-N1002 Serial No.10001 and Higher
BDKP-N1003 Serial No.10001 and Higher
BDKP-N1004 Serial No.10001 and Higher
BDX-N1000
1 (P)
Attention-when the product is installed in Rack:
(For BDX-N1000)
1. Prevention against overloading of branch circuit
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
make sure that the rack does not overload the supply
circuit.
2. Providing protective earth
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
confirm that the outlet is provided with a suitable
protective earth connection.
3. Internal air ambient temperature of the rack
When this product is installed in a rack, please make
sure that the internal air ambient temperature of the
rack is within the specified limit of this product.
4. Prevention against achieving hazardous
condition due to uneven mechanical loading
When this product is installed in a rack, please make
sure that the rack does not achieve hazardous
condition due to uneven mechanical loading.
CAUTION
Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to the
manufacturer’s instructions.
Vorsicht!
Explosionsgefahr bei unsachgemäßem
Austausch der Batterie.
Ersatz nur durch denselben oder einen vom
Hersteller empfohlenen ähnlichen Typ.
Entsorgung gebrauchter Batterien nach Angaben
des Herstellers.
ATTENTION
Il y a danger d’explosion s’il y a remplacement
incorrect de la batterie.
Remplacer uniquement avec une batterie du
même type ou d’un type équivalent recommandé
par le constructeur.
Mettre au rebut les batteries usagées
conformément aux instructions du fabricant.
ADVARSEL!
Lithiumbatteri-Eksplosionsfare ved fejlagtig
håndtering.
Udskiftning må kun ske med batteri
af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandøren.
(For BDKP-N1002)
Laser Diode Properties
Material : InGaAsP
Wave length : 1300 nm
Emission duration : Continuous
Laser output power (average): 0.16 mW (max.)
CAUTION
The use of optical instruments with this product
will increase eye hazard.
This Network Interface Unit is classified as a CLASS 1
LASER PRODUCT.
The CLASS 1 LASER PRODUCT label is located on the
rear panel.
CLASS 1
LASER PRODUCT
LASER KLASSE 1
PRODUKT
BDX-N1000
1 (E)
BDX-N1000
Table of Contents
Manual Structure
Purpose of this manual ........................................................................................ 3 (E)
Related manuals................................................................................................... 3 (E)
Contents ............................................................................................................... 3 (E)
Trademarks .......................................................................................................... 4 (E)
1. Service Overview
1-1. Notes on Repair Parts............................................................................1-1 (E)
1-2. Removing the Cabinet...........................................................................1-1 (E)
1-2-1. Removing the Top Panel ......................................................1-1 (E)
1-2-2. Removing the Front Panel....................................................1-1 (E)
1-3. Locations of the Main Parts and Boards ...............................................1-2 (E)
1-4. Replacing the Main Parts ......................................................................1-3 (E)
1-4-1. Switching Regulator.............................................................1-3 (E)
1-4-2. Fan Motor .............................................................................1-4 (E)
1-4-3. Lithium Battery ....................................................................1-5 (E)
1-5. Replacing the Printed Circuit Boards....................................................1-6 (E)
1-5-1. IF-694 Board ........................................................................1-6 (E)
1-5-2. CCM-36/36A Board.............................................................1-7 (E)
1-5-3. CCM-40/40A Board.............................................................1-7 (E)
1-6. How to Use the Controller Software .....................................................1-8 (E)
1-7. Circuit Description ..............................................................................1-13 (E)
1-8. Error Message .....................................................................................1-14 (E)
2. Spare Parts
2-1. Exploded Views and Mechanical Parts List................................................2-1
2-2. Electrical Parts List .....................................................................................2-8
3. Semiconductor Pin Assignments
4. Block Diagram
Overall Block..........................................................................................................4-1
2 (E) BDX-N1000
5. Schematic Diagrams
CCM-36 ..................................................................................................................5-2
CCM-36A ...............................................................................................................5-3
CCM-40 ..................................................................................................................5-4
CCM-40A ...............................................................................................................5-6
DP-270....................................................................................................................5-8
DP-271....................................................................................................................5-8
IF-694 .....................................................................................................................5-9
Frame Wiring........................................................................................................5-35
6. Board Layouts
CCM-36/36A ..........................................................................................................6-2
CCM-40/40A ..........................................................................................................6-3
IF-694 .....................................................................................................................6-4
3 (E)
BDX-N1000
Manual Structure
Purpose of this manual This manual is the maintenance manual of the BDX-N1000 Network Interface Unit
and the BDKP-N1001/N1002/N1003/N1004 Network Adapter Boards.
This manual is intended for use by trained system and service engineers.
This manual describes information that premise the service based on component
replacement.
Related manuals Besides this Maintenance Manual, the following manuals are available for the BDX-
N1000.
..
..
.Operation Manual (Supplied with the BDX-N1000)
This manual explains the overview of the BDX-N1000, and the system configura-
tion examples.
..
..
.Installation Manual (Supplied with the BDX-N1000)
This manual describes information regarding installation.
Contents The following is a summary of all the sections for understanding the contents of this
manual.
Section 1 Service Overview
Explains the removal of cabinet, how to replace the parts and boards, etc.
Section 2 Spare Parts
Describes the spare parts list.
Section 3 Semiconductor Pin Assignments
Describes the pin assignments of semiconductors.
Section 4 Block Diagram
Describes the overall block diagram.
Section 5 Schematic Diagrams
Describes the schematic diagrams of the IF-694, CCM-36/36A and CCM-40/40A
boards, and frame wiring.
Section 6 Board Layouts
Describes the board layouts of the IF-694, CCM-36/36A and CCM-40/40A boards.
4 (E) BDX-N1000
Trademarks Registered trademarks used in this manual are follows.
.Ethernet is a registered trademark of Xerox Corporation.
.Windows is a registered trademark of Microsoft Corporation.
.IBM and AT are registered trademarks of International Business Machines
Corporation.
1-1 (E)
BDX-N1000
1-1. Notes on Repair Parts
1. Safety Related Components Warning
w
Components marked !are critical to safe operation.
Therefore, specified parts should be used in the case of
replacement.
2. Standardization of Parts
Some repair parts supplied by Sony differ from those
used for the unit. These are because of parts common-
ality and improvement.
Parts list has the present standardized repair parts.
3. Stock of Parts
Parts marked with “o” at SP (Supply Code) column of
the spare parts list may not be stocked. Therefore, the
delivery date will be delayed.
4. Units Representation
The following represented units are changed or
omitted in writing.
Units Representation
Capacitance µFuF
Inductance µHuH
Resistance ZAbbreviation
Temperature dCXXX-DEG-C
5. Replacement of Optional Boards
If it is necessary to replace the optional board, please
place an order the BDKP-Nxxxx through the sales
route.
.CCM-36 board : BDKP-N1001
.CCM-36A board : BDKP-N1002
.CCM-40 board : BDKP-N1003
.CCM-40A board : BDKP-N1004
Section 1
Service Overview
Top panel
BDX-N1000
B 4x6
B 4x6
1-2. Removing the Cabinet
1-2-1. Removing the Top Panel
1. Turn off the main power and remove the AC plug from
the outlet.
2. Remove the six screws (B 4x6) and remove the top
panel.
1-2-2. Removing the Front Panel
1. Turn off the main power and remove the AC plug from
the outlet.
2. Remove the two screws (RK 3x8) and the two wash-
ers. Remove the front panel to the front.
Washer
Washer
RK 3x8
Front panel
RK 3x8
1-2 (E) BDX-N1000
1-3. Locations of the Main Parts and Boards
Circuit Configuration
Board name Main function
1IF-694 board ATM board
2DP-271 board LED board
3DP-270 board Display board
4DP-131 board Indicator light board
5CCM-36 board (BDKP-N1001) ATM interface board (Multi Mode Fiber)
6CCM-36A board (BDKP-N1002) ATM interface board (Single Mode Fiber)
7CCM-40 board (BDKP-N1003) ATM interface board (DS3)
8CCM-40A board (BDKP-N1004) ATM interface board (E3)
1-3. Locations of the Main Parts and Boards
Optional boards
5CCM-36 board
6CCM-36A board
7CCM-40 board
8CCM-40A board
4DP-131 board
3DP-270 board
2DP-271 board
1IF-694 board
Fan motor
Switching regulator
Otros manuales para BDX-N1000
2
Este manual sirve para los siguientes modelos
4
Tabla de contenidos
Otros manuales de Equipo de grabación de Sony
Sony
Sony PDW-HD1550 Manual de usuario
Sony
Sony XDCAM PDW-HR1 Manual de usuario
Sony
Sony MSU-1000 Manual de usuario
Sony
Sony HAR-LH500 Manual de usuario
Sony
Sony RCD-W2000ES - Cd/cdr Recorder Manual de usuario
Sony
Sony BDX-N1000 Manual de usuario
Sony
Sony DPS-R7 Manual de usuario
Sony
Sony SIU-100 Manual de usuario
Sony
Sony HDW-1800 Manual de usuario
Sony
Sony ICD-SX713/ICD-SX813 Manual de usuario
Sony
Sony PDW-75MD Manual de usuario
Sony
Sony PFV-D10 Manual de usuario
Sony
Sony SEQ-300 Manual de usuario
Sony
Sony Walkman PCM-M1 Manual de usuario
Sony
Sony PCM-D50 - Portable Linear Pcm Recorder Manual de usuario
Sony
Sony SIU-100 Manual de usuario
Sony
Sony DMX-R100 Manual de usuario
Sony
Sony RCD-W222ES - Cd/cdr Recorder Manual de usuario
Sony
Sony XE-90 MkII Manual de usuario
Sony
Sony BKP-7933 Manual de usuario
Manuales populares de Equipo de grabación de otras marcas
Strymon
Strymon NIGHTSKY Manual de usuario
Mitsubishi Electric
Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manual de usuario
Tews Technologies
Tews Technologies TPMC465 Manual de usuario
Honeywell
Honeywell Excel 50 Manual de usuario
SeaLevel
SeaLevel COMM+8.LPCI Manual de usuario
Arturia
Arturia AUDIOFUSE STUDIO Manual de usuario
