Sony VPL-CWZ10 Guía de referencia

Help Guide

Data Projector

VPL-CWZ10/CXZ10

This manual is for those who encounter issues or have questions when using the Data Projector.

Not all models are available in all countries and areas. Please check with your local Sony Authorized Dealer.

Before Use

Checking the Supplied Accessories

Inserting the Battery into the Remote Commander

Attaching the Air Filter (For the Customers in India only)

Parts and Controls

Parts and Controls (Main Unit)

Parts and Controls (Connection Terminals)

Parts and Controls (Remote Commander and Control Panel)

Connecting

Precautions When Connecting

Connecting to a Computer

Connecting to a Computer with an RGB Output Terminal

Connecting to a Computer with an HDMI Output Terminal
Connecting to a Computer via a Hub or Router
Connecting to Video Equipment
Connecting to a Video Device with a Video Output Terminal
Connecting to a Video Device with a Y PB PR Output Terminal
Connecting to a Video Device with an HDMI Output Terminal
Connecting to Audio Equipment
Fixing the HDMI Cable to the Projector
Projecting
Turning Power On/Off
Selecting the Menu Language
Projecting Images
Adjusting
Adjusting the Screen Focus
Adjusting the Screen Size
Adjusting the Screen Position
Changing the Screen Aspect Ratio
Correcting a Trapezoidal Screen
Correcting a Vertical Trapezoid
Correcting a Horizontal Trapezoid
Correcting Screen Distortion
Displaying Patterns
Using the Auto Adjustment Function
Useful Functions
Use the Intelligent Setting Function
Using the Digital Zoom Function
Using Eco Mode
Adjustment and Setting Menus
Navigating Menus
2

Projection Setting Menu
Menu Operation: Intelligent Setting
Menu Operation: Picture Mode
Menu Operation: Reset
Menu Operation: Contrast
Menu Operation: Brightness
Menu Operation: Color
Menu Operation: Hue
Menu Operation: Color Temp.
Menu Operation: Sharpness
Menu Operation: Light Settings
Menu Operation: Expert Setting
Screen Menu
Menu Operation: Aspect
Aspect Ratio
Menu Operation: Adjust Signal
Function Menu
Menu Operation: Presentation timer
Menu Operation: Volume
Menu Operation: Speaker
Menu Operation: Speaker Setting
Menu Operation: Smart APA
Menu Operation: CC Display
Menu Operation: Start Up Image
Operation Menu
Menu Operation: Language
Menu Operation: Status
Menu Operation: Security Lock
Menu Operation: Control Key Lock
Menu Operation: Menu Settings Lock
3

Menu Operation: Set Password
Connection/Power Menu
Menu Operation: Network Setting
Menu Operation: Communication Mode
Menu Operation: Dynamic Range
Menu Operation: Input-A Signal Sel.
Menu Operation: ECO
Menu Operation: Remote Start
Menu Operation: Standby Mode
Menu Operation: Direct Power On
Installation Menu
Menu Operation: Screen Fitting
Menu Operation: V Keystone
Menu Operation: H Keystone
Menu Operation: Corner Keystone
Menu Operation: Digital Shrink
Menu Operation: Image Flip
Menu Operation: High Altitude Mode
Information Menu
Viewing the Projector Information
Using Network Features
Uses for Network Features
Displaying the Control Window of the Projector with a Web Browser
Operating the Control Panel
Using the E-mail Report Function
Configuring the Network Settings of the Projector
Setting Projector Control Protocol
Setting Advertisement
Setting PJ Link
Setting PJ Talk
4

Setting ADCP
Setting AMX DDDP/Crestron Room View
Resetting the Network Settings
Setting the Date and Time
Using the Software Update Function
Using https Communication
Configuring https Communication
Connecting with https for the First Time
Installing a CA Certificate to Your Computer
Deleting a CA Certificate Installed to Your Computer
Precautions
Precautions
On Installation
On Cleaning the Lens and the Cabinet
On Illumination
On Heat Dissipation
On Screen
On Fan
On Inspection of Light Source Related Parts
On Disposing Used Products
On LCD Projector
On condensation
Notes on Security
Do not place this product close to medical devices
Disclaimer
Cleaning the Air Filter
Cleaning the Air Filter (For Installing to the Ceiling) (For the Customers in India only)
Updating Software
Specifications
5

Specifications
Pin Assignment
Pin Assignment (HDMI Terminal)
Pin Assignment (RGB Input Terminal)
Pin Assignment (RS-232C Terminal)
Pin Assignment (USB Terminal)
List of Compatible Signals
Compatible Signal List (Computer Signal)
Compatible Signal List (Video Signal)
Projection Distance
Projection Distance
Projection Distance/Projection Distance Formula (VPL-CWZ10)
Projection Distance/Projection Distance Formula (VPL-CXZ10)
Error Handling
Reading the Indicator
Message List
Troubleshooting
No Power
No Image is Displayed
Cannot Connect to Computer
No On-screen Display
Screen Aspect Ratio is Strange/Screen Display is Small/Part of Image Not Displayed
Trapezoidal Screen
Screen Distortion
Screen is Too Dark/Bright
Blurry Screen
Screen Noise
No Sound
Remote Commander Does Not Function
Loud Fan
6

Others

Notice on the Software

Notifications Related to GNU GPL/LGPL-applicable Software

Other Software

Trademarks

Help Guide

Data Projector

VPL-CWZ10/CXZ10

Checking the Supplied Accessories

Confirm that the following components are included. The () indicates the quantity of the component.

Remote Commander (RM-PJ8) (1)

Lithium battery (CR2025) (1)

The battery is already installed. Before using the Remote Commander, remove the insulation film.

AC power cord (1)

Mini D-sub 15-pin cable (1.8 m) (1)

(1-970-584-11/Sony)

Extension studs (4)

Air filter cover (1)*1

Dust cover assembly (1)*1

Setup Guide (1)

For the customers in India only

Help Guide

Data Projector

VPL-CWZ10/CXZ10

Inserting the Battery into the Remote Commander

The lithium battery is attached to the Remote Commander at the time of purchase. Before using the Remote

Commander, remove the insulation film.

If the Remote Commander can no longer be operated, exchange the lithium battery for a new one by the following

procedure.

Pull out the lithium battery compartment.

Pull the battery compartment toward you while releasing the lock.

Insert a lithium battery.

The lithium battery should be placed in the compartment with the plus side facing up.

Close the lithium battery compartment.

Help Guide

Data Projector

VPL-CWZ10/CXZ10

Attaching the Air Filter (For the Customers in India only)

The supplied accessories required vary depending on the installation method.

For installing to the floor

For installing to the ceiling

Attach the dust cover assembly to the unit by pushing the two levers on it. (The product is pre-fitted with a dust cover

assembly when shipped.)

Remove the air filter (B) from the dust cover assembly (A), and then attach the air filter to the air filter cover

(C).

Pull the pull stick (D) upwards when removing the air filter from the dust cover assembly.

When attaching the air filter to the air filter cover, make sure the correct side is being attached so that the pull stick

is protruding from the air filter.

Attach the air filter cover to the unit by pushing the two levers on it.
