SSM-Q177
Black andWhite
Quad Monitor
FR
ES
US
2
English
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
Owner’s Record
The model and serial numbers are located at the rear.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your
Sony dealer regarding this product.
Model No. SSM-Q177 Serial No.
This symbol is intended to alert the user
to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
This symbol is intended to alert the user
to the presence of important operating
and maintenance (servicing) instructions
in the literature accompanying the
appliance.
CAUTION:
TO PREVENT ELECTRIC SHOCK, DO NOT USE
THIS POLARIZED AC PLUG WITH AN EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET
UNLESS THE BLADES CAN BE FULLY INSERTED
TO PREVENT BLADE EXPOSURE.
This unit is not intended to be used with computer
work stations.
3
English
US
CAUTION:
These potential hazards shall be considered common
to most rack installation.
1) Elevated Operating AmbientTemperature
After installed, the operating temperature may be
greater than room ambient.Consideration shall be
given to the environment temperature compatible
within the Manufacturer’s specified limit of Ambient
Temperature of 0°C – +35°C (32°F – 95°F).
2) Reduced Air Flow
After installed, the amount of air flow required for safe
operation of this equipment shall not be
compromised.
3) Circuit Overloading
Before installing, refer to rated current on this
equipment and make sure that no overloading to the
supply circuit on the rack.
Please confirm the rated current described on this
Operating Instructions.
4) Providing Protective Earth
When this product is installed in a rack and supplied
power from an outlet on the rack, please confirm that
the outlet is provided with a reliable protective earth
connection.
5) Prevention against achieving hazardous condition
due to uneven mechanical loading
When this product is in a rack, please make sure that
the rack does not achieve hazardous condition due to
uneven mechanical loading.
For the customers in the U.S.A.
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules.These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at his own expense.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
Table of Contens
4
Table of Contents
Features .....................................................................4
Precautions................................................................5
Location and Function of Controls .........................6
Front Panel ........................................................6
Rear Panel .........................................................8
Connections ............................................................10
Connecting a Video Camera or a VCR ...........10
MENU Operation......................................................11
Setting procedure ............................................11
Setting MENU.................................................11
Alarm Function ...............................................15
Specifications..........................................................16
Features
• Quad display enables you to simultaneously monitor input
from 4 cameras on one screen.
• Sequential Switcher function enables you to monitor
pictures from each of the 4 cameras one by one on the
screen, or to stop the picture at a particular camera, using
the unit as a high resolution black and white surveillance
monitor.
• Alarm function informs you of anomalies with a buzzer
and flashing alarm sign and switches the picture to the one
from the camera that detected the anomaly.
• In Quad mode, Freeze function enables you to stop the
picture of a selected channel. When replaying on the
VCR, Freeze function enables you to stop the picture
displayed on the screen.
• On-Screen Menu function enables you to set channel, date,
time, and alarm on the screen.
• When the picture or characters on the screen are cut off by
the side end of the screen, you can correct for it by using
the Horizontal Hold (H. Hold) function (on the front
control panel) that shifts and adjusts the picture
horizontally.
• You can set up the unit on a 19 inches rack using Rack
Mount Bracket (RMM-171), which is available as an
optional accessory.
5
Precautions
Safety
• The unit operates on 120 V AC, 50/60 Hz.
• Should any liquid or solid object fall into the cabinet,
unplug the unit and have it checked by qualified personnel
before operating it any further.
• Unplug the unit from the wall outlet if it is not going to be
used for several days or more. To disconnect the cord, pull
it out by the plug. Never pull the cord itself.
• Allow adequate air circulation to prevent internal heat
build-up. Do not place the unit on surfaces (rugs, blankets,
etc.) or near materials (curtains, draperies) that may block
the ventilation holes.
• Height and vertical linearity controls located at the rear
panel are for special adjustments by qualified personnel
only.
Installation
• Do not install the unit in an extremely hot or humid place
or in a place subject to excessive dust or mechanical
vibration.
• The unit is not designed to be waterproof. Exposure to rain
or water may damage the unit.
Cleaning
Clean the unit with a lightly damp soft cloth. Use a mild
household detergent. Never use strong solvents such as
thinner or benzine as they might damage the finish of the
unit.
If you have any question or problem concerning your unit
that is not covered in this manual, please consult your
nearest Sony dealer.
6
Location and Function of Controls
Front Panel
6POWER switch
and indicator
AUTO
SWITCHER
QUAD
CHANNEL 4SET UP
(ENTER)
321
FREEZE
8CHANNEL
select button 9SETUP
(ENTER)
button
7AUTO
SWITCHER/
QUAD select
button
5CONTRAST control
4BRIGHT (brightness) control
3V-HOLD (vertical hold) control
2H-HOLD (horizontal hold) control
1INPUT select switch
7
1INPUT select switch
Keep this switch released (øCAMERA) to monitor the
signal from the CAMERA IN connector.
Depress this switch (ØVCR) to monitor the signal from the
VCR IN connector.
2H-HOLD (horizontal hold) control
When the picture has slanting horizontal bars, turn the H-
HOLD control in either direction until a stationary picture is
obtained.
3V-HOLD (vertical hold) control
When the picture rolls up or down on the screen, turn the V-
HOLD control until a single stationary picture is obtained.
4BRIGHT (brightness) control
Turn clockwise for a brighter picture and counterclockwise
for a darker picture.
5CONTRAST control
Turn clockwise to increase picture contrast and
counterclockwise to decrease it.
6POWER switch and indicator
To turn on the monitor, depress this switch. The green
indicator lights up.
To turn off the monitor, press the switch again.
7AUTO SWITCHER / QUAD select button
Press this button to choose AUTO SWITCHER mode or
QUAD mode.
8CHANNEL select button
If you have chosen AUTO SWITCHER mode above, the
screen shows pictures from each of the cameras, one at a
time in sequence starting from CH1, and repeats the
sequence over and over. To stop the sequence at a particular
channel, press the button for that channel, the sequence will
stop and the picture stays. To restart the sequence, press the
button again.
If you have chosen QUAD mode, the screen shows
4 channels at the same time. If you press a CHANNEL
button, the channel you have selected shows a FREEZE
picture.
9SET UP (ENTER) button
Press this button to go to MAIN MENU display. To proceed
to SUB MENU or to select an item, press the same button.
8
CH1
GND
CH2 CH3 CH4
CAMERA IN
CH1 CH2 CH3 CH4 OUT TRG
IN OUT
ALARM
VCR IN VIDEO OUT
VCR OUT
Rear Panel
1CAMERA IN (BNC) connector
To see a picture from a camera, connect to a video output
connector of a black and white video camera and keep the
INPUT select switch released on the front panel to select
CAMERA.
2VCR IN (BNC) connector
To see a replay on the VCR, connect to a video output
connector of a VCR and press the INPUT select switch on
the front panel to select VCR.
To see a FREEZE picture (still picture), press either of the
four CHANNEL select buttons on the front panel during a
replay. Press the button again to exit FREEZE picture.
3VIDEO OUT (BNC) connector
Connect to a video input connector (VCR or another
device’s video input connector). Outputs a picture that is
currently on the screen selected by operating the AUTO
SWITCHER / QUAD button.
4VCR OUT (BNC) connector
Connect to a video input connector. Outputs quad display
only.
Location and Function of Controls
1CAMERA IN
(BNC) connector 2VCR IN (BNC)
connector
3
VIDEO
OUT (BNC)
connector
5ALARM connector 4
VCR OUT
(BNC)
connector
9
Notes
• When the display shows freeze picture in Quad mode,
VCR OUT (BNC) connector will also output freeze
picture.
• When playing back on the VCR (when the INPUT select
switch is down), VCR OUT (BNC) connector outputs
nothing.
5ALARM connector
IN ALARM mode starts by short-circuiting between
connectors of each channel. Connect to external sensors
such as infrared sensors or door sensors. Each of the
connectors corresponds to No. 1, 2, 3, and 4 of the
CAMERA IN connectors respectively. The monitor
display switches to a picture from the camera that has
sent the alarm signal.
OUT During the ALARM mode, the output voltage is
LOW (0V).
Trigger OUT When the ALARM mode is activated,
starts an output at LOW (0V) for 100ms, then switches
to HIGH (5V) output.
Other functions
If there is no incoming video signal for a channel before and
after turning on the main power, the channel will show
flashing “NO VIDEO” display on a black background.
If an incoming video signal stops after the main power is
turned on, the screen will display the last video input in a
FREEZE picture with the flashing “NO VIDEO” display.
After a while, the display stops flashing.
To exit FREEZE picture, reestablish signal input or turn off
the monitor and restart.
10
Connections
Connecting a Video Camera or a VCR
Connect the VCR connector to the video output of a video
camera or a VCR.
GND
CH1 CH2 CH3 CH4 OUT TRG
IN OUT
ALARM
CH1 CH2 CH3 CH4
CANERA IN VCR IN VIDEO OUT
VCR OUT
Camera 4 Camera connection 4
Camera 3
Camera
connection 3
Camera 2
Camera
connection 2
Camera 1
Camera
connection 1
Infrared sensor
or Door sensor
VCR IN
VCR OUT
to ALARM IN
connector
VCR OUT,
etc.
VCR IN,
etc.
VCR
Otros manuales para SSM-Q177
1
Tabla de contenidos
Idiomas:
Otros manuales de Monitor de Sony
Sony
Sony LMD-1410/1420 Manual de usuario
Sony
Sony TRINITRON KX-14CP1 Manual de usuario
Sony
Sony Trimaster PVM-X300 Manual de usuario
Sony
Sony PFM-32C1 Manual de usuario
Sony
Sony Trinitron CPD-G420 Manual de usuario
Sony
Sony LMD-3250MD Manual de usuario
Sony
Sony FW-85BZ40H Manual de usuario
Sony
Sony Multiscan CPD-420GS Manual de usuario
Sony
Sony SDM-X52 - DELUXEPRO - 15" LCD Monitor Manual de usuario
Sony
Sony FWD-50PX1 (English: pgs. 52-97) Manual de usuario
Sony
Sony KV-36XBR800 - 36" Trinitron Color Flat Tv Wega... Manual de usuario
Sony
Sony BVME170A Manual de usuario
Sony
Sony Multiscan CPD-E100 Manual de usuario
Sony
Sony LUMA LMD-2450W Manual de usuario
Sony
Sony GDM-200PS Manual de usuario
Sony
Sony TRINITRON PVM-1942Q Manual de usuario
Sony
Sony FWD-32LX2 Manual de usuario
Sony
Sony LMD1751WCC Manual de usuario
Sony
Sony Trinitron CPD-G220S Manual de usuario
Sony
Sony PFM-50C1 Manual del propietario
