Sony SDM-P234 - PremierPro Widescreen 23" LCD... Manual de usuario

Sony's 23" Widescreen PremierPro™ Flat Panel

LCD delivers technology to the professional.

Innovative and stylish design combined with a

high resolution – brightness and color accurate

LCD delivers maximum performance.

Widescreen display easily views multi-page

layouts or additional toolbars, digital and analog

inputs provide multiple computer support.

SDM-P234/B

Display

23" Wide Screen Flat Panel LCD

Panoramic 16:10 aspect ratio makes this display a

productivity workhorse. Supports multi-page

layouts and toolbars, perfect for professionals who

require maximum screen real estate.

Slim Bezel, Innovative Design

Slim bezel combined with integrated power supply

and cable management system maximizes desktop

and provides ideal solution for financial

applications.

Color Performance Control

Color Performance Control: Expert level of gain &

bias control to maximize your color clarity to

achieve the most accurate LCD color reproduction.

Digital & Analog Input

Digital connection maximizes video performance,

dual inputs support multiple computers.

Energy Saving Eco Mode

Energy Saving Eco Mode: Lower power

consumption provides increased savings

throughout the life of the product.

Model

SDM-P234/B

Model

SDM-P234/B

Viewable Image Size

23.0"

Auto-Sensing Inputs

Black & Silver

Panel Type

Super IPS

Native Resolution

1920 x 1200

Horizontal Scan (kHz)

28-92kHz

Vertical Refresh (Hz)

48-85Hz

Pixel Pitch

0.258 mm H/V

Response Time

16ms

Luminance

250 cd/m2

Contrast Ratio

500:1

Video Input Connector

Digital (DVI-D) and Dual Analog (HD15)

Internal Power Supply

Yes

Tilt Range

-5° to +20°

Viewing Angle

170°/170°

Power Management

Max. Power -72W (max.)

Eco Mode - 61W (max.)

Sleep Mode - 1W (max.)

Main Off - 0W

Vesa Wall/Arm Mount

100mm

On Screen Control

Power

Contrast

Brightness

Input Select

Eco Mode

Color Temperature

Backlight

Auto Adjust

H/V Adjust

Power Save

Phase

Pitch

Reset

Gamma

Zoom

Smoothing

Menu Lock

OSD Position

Multi Lang. (Eng., Fr., Spa., Ital., Ger.,

Jap.)

Plug & Play

DDC 2B˝AC Power Cord

Owners Manual

Windows® Utility Files

Macintosh® Utility Files

DVI-D Video Signal Cable

HD15 Video Signal Cable

Audio Cable

Warranty Card

Regulation Compliance

UL1950, CSA 22.2, EMI CE, FCC Class B,

IC Class B; CCC, C-Tick, CB, CPA, FCC

Class B, IC Class B, TCO99, Energy Star,

Window Logo Compliance, ECO

Limited Warranty

3 years (Parts, Labor, Backlight)

Size (H x W x D)

21.0" x 16.9" x 9.8" (w/ stand base)21.0" x

13.9" x 4.4" (w/o stand base)

Weight

21.4 lbs. (w/ stand base)16.5 lbs. (w/o

stand base)

Supplied Accessories

AC Power cord (6ft. Black)

CDRom: (PDF User Manual- English,

French, Spanish, Italian, German, Russian,

Swedish, Dutch, Japanese, Chinese) (Utlity

Files- DOS, MAC, Windows) (Display

Adjustment)

HD-15 Analog Video Cable (6ft. Black)

DVI-D Digital Video Cable (6ft. Black)

Audio Cable w/ Stereo Mini Plug (6ft.

Black)

Warranty Card

Quick Setup Guide: English, French,

Spanish, Chinese

trademark of Sony. Screen Images are simulated.

1-866-357-7669

http://www.sony.com/displays

SDM-P234/B

Display
