Sony BRAVIA XBR-65X850F Manual de usuario

SERVICE MANUAL (UNIQUE)

Version Date Subject

1 02/2018 1st Issue

2 03/2018 Add Model for 85inch (pg. 64)

ORIGINAL MANUAL ISSUE DATE: 02/2018

GN4TR CHASSIS

Segment : CHH

HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

LCD TV

9-888-744-A2

For SM - Common , please refer :

9-888-744-01

SYSSET

2018/04/0323:38:31(GMT+09:00)

SERVICE MANUAL (UNIQUE)

LCD TV

GN4TR CHASSIS

Segment : CHH

SYSSET

2018/04/0323:38:31(GMT+09:00)

MODEL LIST

MODEL

REMOTE DESTINATION

XBR

-65X850F RMF-TX310U

UC2

XBR

-65X851F RMF-TX310U

LA1

XBR

-65X856F RMF-TX310B

LA8

XBR

-65X858F RMF-TX310B

CO1

XBR

-75X850F RMF-TX310U

UC2

, LA1

XBR

-75X855F RMF-TX310B

LA8

XBR

-75X857F RMF-TX310B

CO1

XBR

-85X850F RMF-TX310U

UC2

, LA1

XBR

-85X855F RMF-TX310B

LA8

SYSSET

2018/04/0323:38:31(GMT+09:00)

Section Title

Page

SAFETY NOTES

-1.

How to Remove Rear Cover ..………………………...…..

DIAGRAMS

-1.

Circuit Board

Location …..………………...…………….. 12

-2.

Wire

Dressing ………………………………………………. 14

EXPLODED VIEWS AND PARTS List

-1.

XBR

-65X85*F

……….……………………………………………...

-2.

XBR

-75X85*F ……………..

……………………………….……...

-3.

XBR

85X85*F……………………………………………………….

-4.

Smart Core………………………………………………………….

TABLE OF CONTENTS

Please refer Service Manual –Common for below information :

General Safety Notes

Self Diagnostic Function

Triage Chart

Troubleshooting, Troubleshooting reference

Adjustments

Diagrams : Block Diagram , Connector Diagram

Note: Pictures provided in all this manual might have slight difference from

the actual sets

SYSSET

2018/04/0323:38:31(GMT+09:00)

SECTION 1

DISSASSEMBLY AND REMOVAL CAUTION

Rear Cover Disassemble Method & Caution Notes 55”/65”/75”

RC disassembly procedure

①

②

①Push down Cover card tab.

②Pull out Cover card

Cover Card disassemble guide (before removing rear cover (RC)) ※EU/JP only

5 SYSSET

2018/04/0323:38:31(GMT+09:00)

Remove screw

Screw type and quantity to dissemble RC

55 65 75 Remarks

(Except EU/JP) 7

(EU/JP) 8 (Except EU/JP) 7

(EU/JP) 8 (Except EU/JP) 11

(EU/JP) 12 SCREW M3X3.0 STEP

4 4 4 SCREW, ORNAMENTAL

M6X12

6 SYSSET

2018/04/0323:38:31(GMT+09:00)

Remove AC Cover Release slider HOOK

①Pull outAC cover.

②Pull outAC connector.

①

②

Press by Plus driver to push SLIDER to down side.

RC released position

About 10mm

7 SYSSET

2018/04/0323:38:31(GMT+09:00)

RC disassemble

①

②

Top hook area

Catcher Position

①①

②

①Pull RC bottom area until back of SP. and confirm release catcher

②Slide up RC (release top hook)

8 SYSSET

2018/04/0323:38:31(GMT+09:00)

1. Remove the screw of Rear Cover and UNDER-Cover.

2. Pull up at Screw area on RC and unhook on RC.

(please see next page for the position of hook)

3. You can disassemble RC by sliding down.

Unhook at top

side

Unhook both

side and

terminal area

Screw

area

Rear Cover Disassemble Method & Caution Notes 85”

SYSSET

2018/04/0323:38:31(GMT+09:00)

Sharp Edge Information

Caution point:

Please wear glove while removing rear cover to avoid sharp edge at bottom

area and hook area as shown in figure below.

Sharp edge corner

Sharp edge area

10 SYSSET

2018/04/0323:38:31(GMT+09:00)
